Summary of Contents for Matador Supernova 4
-
Page 2: Table Of Contents
CONTENTS FEATURES IMPORTANT GAS AND SAFETY INSTRUCTIONS OPERATING PROCEDURE COOKING TIPS CARE AND MAINTENANCE BARBEQUE ASSEMBLY INSTRUCTIONS PARTS DIAGRAM ASSEMBLY INSTRUCTIONS WARRANTY CONTACT INFORMATION For spare parts order from your nearest Burnings Warehouse. For service and warranty queries please call Australia: service@genesiscorp.com.au 08 9248 9822 or email:... -
Page 3: Features
Warming rack ■ stainless steel hood Control knobs stainless steel control plate for eash burner Side burner BARBEQUE DIMENSIONS Length Width Height 840 mm 650 mm 300 mm Hood Cabinet 1460 mm 650 mm 1205mm MATADOR INSTRUCTION MANUAL... -
Page 14: Barbeque Assembly Instructions
BARBEQUE ASSEMBLY INSTRUCTIONS TOOLS NEEDED FOR ASSEMBLY 1 x Screwdriver • 1 x Adjustable Spanner • B.Bolt M4 x 10mm A.Bolt M6 x 15mm Liquid Nails (not included) • 4 pieces 74 pieces Note: Please use “Liquid Nails” to bond the granite top and the BBQ body. -
Page 15: Parts Diagram
1 piece 9. Body asm 10.side burner 11.knob support 12.knob 1 piece 1 piece 1 piece 1 piece 13.side burner 14. side grid 15. cooking plate 16.cooking grid 1 piece 1 piece 1 piece 1 piece MATADOR INSTRUCTION MANUAL 15... - Page 16 17.cart connect 18.body table 19. body table 20. body table pipe RF plate-L plate-R plate-B 1 piece 1 piece 1 piece 1 piece...
-
Page 17: Assembly Instructions
Bolt A, lock washer C, Flat washer D and tighten. STEP 2 Assemble Cart connect pipe LD (part 4) to the Cart connect pipe L as shown. Use the Bolt A, lock washer C, Flat washer D and tighten. MATADOR INSTRUCTION MANUAL 17... - Page 18 STEP 3 Assemble the Cart connect pipe L (Part 2) to the Cart leg asm LR (Part1) and Cartleg asm M (Part3) as shown.Use the Bolt A,lock washer C, Flat washer D and tighten. ...
- Page 19 STEP 6 Assemble the cart table support plate ( part 7 ) to the cart asm as shown. Use the Bolt A, lock washer C, Flat washer D and tighten. MATADOR INSTRUCTION MANUAL 19...
- Page 20 STEP 7 Take out the side burner asm ( part 10) from body asm as shown. STEP 8 Assemble the body table plate-L( part 18) and body table plate-R( part 19) to the body asm as shown. Use the Bolt A and tighten.
- Page 21 (part 20) to the body asm as shown. Use the Bolt A and tighten. STEP 10 Place the body asm into the cart asm, make sure the regulator asm through the cart asm, as shown,. MATADOR INSTRUCTION MANUAL 21...
- Page 22 STEP 11 Assemble the body asm to the cart asm as shown. Use the Bolt A and tighten. STEP 12 Place the side burner asm (part 10) into the cart asm as shown. Please check that the side valve and side burner control ...
- Page 23 STEP 13 Please insert the ignition wire into the side valve. STEP 14 Assemble the side burner asm to the cart asm.Use the Bolt A and tighten. MATADOR INSTRUCTION MANUAL 23...
- Page 24 STEP 15 Assemble the side burner (part 13) to the side burner asm as shown. Use the BoltB, Flat washer E and tighten. Place the side grid (part 14) into the side burner asm. Please check that the side burner and side valve are well connected .
- Page 25 STEP 17 Assemble the warming grid (part 8) into the body as shown. Use the cotter G fixation. FULLY ASSEMBLED MATADOR INSTRUCTION MANUAL 25...
- Page 27 MATADOR INSTRUCTION MANUAL 27...
