Printed: 24.03.2014 | Doc-Nr: PUB / 5174889 / 000 / 00
SF 2-A /
SFD 2-A
Bedienungsanleitung
Operating instructions
Mode d'emploi
Istruzioni d'uso
Manual de instrucciones
Manual de instruções
Gebruiksaanwijzing
Οδηγιες χρησεως
Használati utasítás
Instrukcja obsługi
Инструкция по зксплуатации
Návod k obsluze
Návod na obsluhu
Upute za uporabu
Navodila za uporabo
Ръководство за обслужване
Instrucţiuni de utilizare
de
en
fr
it
es
pt
nl
el
hu
pl
ru
cs
sk
hr
sl
bg
ro

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFD 2-A and is the answer not in the manual?

Questions and answers

Related Manuals for Hilti SFD 2-A

Summary of Contents for Hilti SFD 2-A

  • Page 1 SF 2-A / SFD 2-A Bedienungsanleitung Operating instructions Mode d’emploi Istruzioni d’uso Manual de instrucciones Manual de instruções Gebruiksaanwijzing Οδηγιες χρησεως Használati utasítás Instrukcja obsługi Инструкция по зксплуатации Návod k obsluze Návod na obsluhu Upute za uporabu Navodila za uporabo Ръководство...
  • Page 2 Printed: 24.03.2014 | Doc-Nr: PUB / 5174889 / 000 / 00...
  • Page 3 Printed: 24.03.2014 | Doc-Nr: PUB / 5174889 / 000 / 00...

  • Page 4: Table Of Contents

    Keep these pages open while studying the operating instructions. In these operating instructions, the designation “power tool” always refers to the SF 2-A or SFD 2-A cordless drill / driver, with battery fitted. Parts, operating controls and indicators Keyless chuck (SF 2-A)

  • Page 5: General Information

    Forward / reverse switch & Grip Lamp Belt hook (optional) Charging status indicator § Release button Control switch (with electronic speed control) 1 General information 1.1 Safety notices and their meaning DANGER Draws attention to imminent danger that will lead to serious bodily injury or fatality.
  • Page 6 Make a note of this data in your operating instructions and always refer to it when making an enquiry to your Hilti representative or service department. Type: Generation: 01 Serial no.:...

  • Page 7: Description

    The working environment may be as follows: construction site, workshop, renovation, conversion or new construction. 2.2 Chuck The SF 2-A has a keyless chuck and the SFD 2-A features a hex. socket drive. 2.3 Switches Control switch with electronic speed control...

  • Page 8: Insert Tools, Accessories

    2.6 The items supplied include (cardboard box versions): 1 Power tool 1 Operating instructions 2.7 Additional items required for operating the tool: B 12/2.6 Li-Ion battery and C4⁄12­50 charger. 2.8 Li­ion battery charge status display LEDs light constantly LEDs blink Charge status C LED 1, 2, 3, 4 C ≧...

  • Page 9: Technical Data

    Drilling diameter range in metal ∅ 0.8…6 mm Wood screws (max. length 80 mm) ∅ 3…6 mm 4 Technical data Right of technical changes reserved. Power tool SF 2-A SFD 2-A Rated voltage (DC 10.8 V 10.8 V voltage) Weight in accordance 1.1 kg 1.0 kg...

  • Page 10: Safety Instructions

    Uncertainty (K) 1.5 m/s² Triaxial vibration values (vibration Measured in accordance with vector sum) EN 60745­2­1 For the SF 2­A/SFD 2-A: Drilling in 1.9 m/s² metal, a Uncertainty (K) for triaxial vibration 1.5 m/s² measurements Battery B 12/2.6 Li­Ion...
  • Page 11 5.1 General power tool safety warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 12 or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
  • Page 13 before use. Many accidents are caused by poorly maintained power tools. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.
  • Page 14 To achieve a high level of dust collection, use a suitable vacuum cleaner of the type recommended by Hilti for wood dust and/or mineral dust together with this tool. Ensure that the workplace is well ventilated. The use of a dust mask of filter class P2 is recommended.
  • Page 15 Place the tool in a location where it can be kept under observation, well away from flammable materials, and allow it to cool down. Contact Hilti Service after the battery has been allowed to cool. 5.3.4 Electrical safety Before beginning work, check the working area (e.g. using a metal detector) to ensure that no concealed electric cables or gas and water pipes are present.

  • Page 16: Before Use

    5.3.5 Work area a) Ensure that the workplace is well lit. b) Ensure that the workplace is well ventilated. Exposure to dust at a poorly ventilated workplace may result in damage to the health. 5.3.6 Personal protective equipment The user and any other persons in the vicinity must wear suitable eye protection, a hard hat, ear protection, protective gloves and breathing protection while the tool is in use.
  • Page 17 CAUTION Before fitting the battery, check that the power tool is switched off and that the safety lock is engaged (forward/reverse switch in the middle position). Use only the Hilti batteries approved for use with this power tool. CAUTION Before inserting the battery in the tool, check to ensure that the battery terminals and the contacts in the tool are free from foreign objects.

  • Page 18: Operation

    6.5 Transport and storage of battery packs Remove the battery from the tool before transport or storage. Make sure that the battery contacts are not short-circuited. Remove loose metal items such as screws, nails, clamps, loose screwdriving bits, wires or metal cuttings and chips from the toolbox or transport container, or prevent these items from coming into contact with the battery.
  • Page 19 NOTE The gear selector switch can be used to select the speed range. Speed range for the SF 2-A/SFD 2-A with a fully charged battery: 1st gear: 0­400/min, 2nd gear: 0­1500/min. NOTE The gear selector switch can be operated only when the motor is at a standstill.
  • Page 20 2. Open the keyless chuck. 3. Pull the insert tool out of the chuck. 7.4.2 Changing bits with the SFD 2-A NOTE The power tool is equipped with a ¹/₄" hex. socket with locking sleeve that accepts various accessories such as drill bits, screwdriving bits and bit holders.

  • Page 21: Care And Maintenance

    2. Set the forward / reverse switch to the desired direction of rotation. 7.7 Reading the charge status LED display on Li­ion batteries NOTE The charge status cannot be indicated while the tool is in operation. NOTE The charge status display LEDs may light briefly while the battery is being fitted to the tool.
  • Page 22 NOTE If use continues, further battery discharge will be stopped automatically before the battery cells suffer damage. Charge the battery using an approved charger from Hilti designed for use with Li-ion batteries. NOTE –...

  • Page 23: Troubleshooting

    The battery runs Battery condition is not Have battery condition down more quickly optimal. diagnosed by Hilti Ser- than usual. vice or replace with a new battery. The battery does The retaining lugs on the Clean the retaining lugs not engage with an battery are dirty.

  • Page 24: Manufacturer's Warranty - Tools

    Dispose of the batteries in accordance with national regulations or return them to Hilti. Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements for taking back your old power tools or appliances for recycling.

  • Page 25: Ec Declaration Of Conformity (Original)

    We declare, on our sole responsibility, that this product complies with the following directives and standards: 2006/42/EC, 2004/108/EC, 2006/66/EC, 2011/65/EU, EN 60745­1, EN 60745­2­1, EN 60745­2­2, EN ISO 12100. Hilti Corporation, Feldkircherstrasse 100, FL­9494 Schaan Paolo Luccini Tassilo Deinzer Head of BA Quality and Process Management Executive Vice President Business Area Electric Tools &...
  • Page 26 Tel.: +423 / 234 21 11 Fax: +423 / 234 29 65 www.hilti.com Hilti = registered trademark of Hilti Corp., Schaan W 4334 | 0314 | 00-Pos. 1 | 1 Printed in China © 2014 Right of technical and programme changes reserved S. E. & O.
