Z-Wave Switches; Z-Wave Thermostats; Z-Wave Door Locks; Testing Scenes - Go!Control 2GIG-CNTRL2 Operation & User’s Manual

Z-Wave Switches

7A. Use the ← or → arrows to choose a switch
device (if there is more than one device), then
select an ON, OFF, or a dimming level for the
switch. Press OK.

Z-Wave Thermostats

7B. Use the ← or → arrows to choose a thermostat
device (if there is more than one device), then
select a mode, setpoint, and fan setting for the
thermostat. Press OK.

Z-Wave Door Locks

7C. Use the ← or → arrows to choose a door lock
device (if there is more than one device), then
select a UN-LOCKED or LOCKED. Press OK.
✓ NOTE: The device will not activate while
setting Steps 7A, 7B, & 7C. The scene must
be "run" or triggered by an event with a
"rule".

Testing Scenes

8. The assigned action(s) for the Scene will be
displayed. Repeat Steps 5 through 7 to add
additional actions to the Scene. Press BACK
when fi nished.
✓ NOTE: Only one action per device can be
assigned per Scene.
9. Test the Scene by pressing RUN. A Scene
execution confi rmation screen will be displayed,
press OK.
Scenes & Rules
Choose a device, then
set the action
New Switch Action Screen
Choose setpoint and
modes
New Thermostat Action Screen
Select action for
door lock
New Door Lock Action Screen
New Scene with Set Actions
Press to test
the scene
Scenes Screen with RUN Button
13
