Basic Operation

Viewing Thermostats

Z-Wave compatible thermostats can be
controlled using the Services feature.
✓ NOTE: Several types of Z-Wave compatible
thermostats are available. Each type
provides different features. All thermostat
Z-wave features are supported, except for
scheduling.
To view the thermostat control, use the
following steps:
1. From the Home Screen press the SERVICES
button.
2. From the Manage Z-Wave Devices Screen, press
the THERMOSTATS button.
3. A list of all installed thermostats will be
displayed. If there are more than three
thermostats, use the ↑ or ↓ arrows to scroll the
list.
4. Press the display where the thermostat is listed
to display the control buttons for the thermostat.
5. The display shows the current temperature, the
thermostat setpoint, the thermostat's battery
status, the thermostat mode, and the fan
mode. When the thermostat mode is "auto",
2 setpoints are displayed, "heat" and "cool".
All thermostat indications that are available
through Z-wave are supported.
✓ NOTE: Thermostats can be powered by the
HVAC system's 24-volt AC power source
(called a C-wire or common wire system) or
be independently powered by batteries. To
save power, battery powered thermostats
send signals to the Control Panel at
intervals and may not update the Control
Panel's display for a short period of time.
8
Press
THERMOSTATS
button
Manage Z-Wave Devices Screen
Press
thermostat's
device button
Thermostat Select Screen
Current temperature
Battery Status
Current setpoint Current mode
Thermostat Settings Screen
