5.4 Serial Ports
5.4.1 Copper Ports
Parameter
Baud Rate
Connector
Isolation
Table 7: Copper Port Specification
5.4.2 Fiber Optic Ports
Parameter
Mode
Connector
Typical Dist. (km)
Optical Wavelength (nm)
Cable Size
Core/Cladding (um)
Table 8: Fiber Optic Port Specification
NOTES:
1. Maximum segment length is greatly dependent on factors such as fiber quality, and
number of patches and splices. Please consult RuggedCom sales associates when
determining maximum segment distances.
©
2007 RuggedCom Inc. All rights reserved
Specifications
300 bps – 230 kbps
DB9 or RJ45
2.5 kV
Specifications
Multimode
ST
5
820
50/125
62.5/125
22
Notes
RMS 1-minute
Rev100
