6.2 IEEE 1613 Type Tests

Test
IEEE C37.90.3
IEEE C37.90.2 Radiated RFI
IEEE C37.90.1 Fast Transient
IEEE C37.90.1 Oscillatory
IEEE C37.90 H.V. Impulse
Dielectric
IEEE C37.90
Strength

Table 14 - IEEE 1613 Type Tests

NOTE:
•
If the unit contains copper ports the IEEE 1613 conformance is Class 1 (During disturbance errors may occur
but recovery is automatic).
• If the unit contains all fiber ports the IEEE 1613 conformance is Class 2 (During disturbance no errors will
occur).

6.3 IEC Environmental Type Tests

Test
IEC 60068-2-1 Cold Temperature
IEC 60068-2-2
Humidity (Damp Heat,
IEC 60068-2-30
IEC 60255-21-1
IEC 60255-21-2

Table 15 - Environmental Type Tests

©
2007 RuggedCom Inc. All rights reserved
Description
Enclosure Contact
ESD
Enclosure Air
Enclosure ports
Signal ports
D.C. Power ports
A.C. Power ports
Earth ground ports
Signal ports
D.C. Power ports
A.C. Power ports
Signal ports
D.C. Power ports
A.C. Power ports
Signal ports
D.C. Power ports
A.C. Power ports
Description
Test Ad
Dry Heat Test Bd
Test Db
Cyclic)
Vibration Tests Fc
Shock Tests Ea
+/- 4kV @ 2.5kHz
2.5kV common mode @ 1MHz
2.5kV common & differential mode @ 1MHz
2.5kV common & differential mode @ 1MHz
5 kV (Failsafe Relay)
2kVac (Failsafe Relay)
Test Levels
-40 deg. C, 16 Hours
+85 deg. C, 16 Hours
95% (non-condensing), 55 deg C, 6 cycles
2g @ (10-150) Hz
30g @ 11ms
26
Test Levels
+/- 8kV
+/- 15kV
35 V/m
+/- 4kV
+/- 4kV
+/- 4kV
5 kV
5 kV
2kVac
2kVac
Severity
Levels
N/A
N/A
N/A
Class 2
Class 2
