Installation
2.6 Serial Ports
The RS400 Series can be equipped with four RS232 DB9 ports, four RS485 Phoenix
ports, four RS232/RS485/RS422 DB9 ports or four RS232/RS485/RS422 RJ-45 ports.
When the RS400 Series is equipped with four RS232 DB9 ports it is physically
indistinguishable than when it is equipped with four RS232/RS485/RS422 DB9 ports.
Check the product label on the back of the unit or the ROS firmware and review the table
below in order to determine the type of serial ports on your RS400 Series. The italicized
letters in the order code represent options specific to your order.
Ports
4 x RS232 via DB9
4 x RS485 via Phoenix
4 x RS232/RS485/RS422 via DB9
4 x RS232/RS485/RS422 via RJ-45
Figure 13: Serial Port Options
®
RuggedCom
Order Code
RS40X-PS-M-E1E2-2-MP
RS40X-PS-M-E1E2-4-MP
RS40X-PS-M-E1E2-3D-MP
RS40X-PS-M-E1E2-3R-MP
18
RuggedServer™ RS400 Family Installation Guide rev109
