n Supplied Accessories
Microphone
Microphone hanger
and screw set
DC power cable Key caps
Mounting bracket
Flat washers
Spring washers
Nuts
* 1 10-key type only
* 2
Used for labelling the program-
mable function keys according
to their assinged functions.
• Function name stickers
Speaker* 1
There are no names on the programmable function keys
since the functions can be freely assigned to these keys.
Attach the supplied function name stickers as below to the
appropriate keys for easy recognition of that key's assigned
function.
Then, protect the attached stickers from unsticking with the
Function name
supplied key cap as below.
stickers* 2
KEY-STICKER
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
CONNECTION AND MAINTENANCE
