This process calibrator/meter is a hand-held, battery-operated instrument for testing and
troubleshooting power electronic systems. This device can be used not only for instrument
system maintenance, but also for maintaining, servicing industrial meters, testing electronic
circuits and electronic equipments. The meter can also be used to measure or calibrate
sensors or transmitters in automotive or automatic control system.
The meter generates a high precision constant voltage, constant current and square wave
output and includes a full feature, high accuracy multimeter. The precision source and the
measurement functions can perform simultaneously.
Main Features:
•
Generates and Measures Signal simultaneously
•
1,200Ω drive capability with special yellow lead for 20mA simulation
•
High precision Constant voltage, Constant Current and Square wave outputs
•
Intelligent Output and Standby control
•
Built-in Ni-MH rechargeable battery
•
Smart Charger design without battery removal
•
Brightness EL backlight
•
Coarse or Fine output adjust
•
The % scale readout for 4-20mA or 0-20mA
•
Adjustable steps and time interval for Auto Scan
•
Adjustable resolutions and start for linear Ramp output
•
1ms Peak hold to capture inrush voltage and current easily
•
Temperature test with the option of 0°C compensation
•
Frequency, Duty cycle and Pulse width measurements
•
Dynamic Recording for MIN/MAX/AVG
•
Data Hold with Manual or Auto Trigger and Relative modes
•
Diode and Audible Continuity test
•
Bi-directional optical computer interface with SCPI commands
•
Safe, precise and fast closed-case calibration
•
50,000 count precision True-RMS digital multi-meter and designed to meet IEC-1010
CAT. II 250V standards
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX 781.665.0780 - TestEquipmentDepot.com
Introduction
