- Page 1 Copyright 2012 MacroAir AirStar Installation Manual...
- Page 2 Copyright 2012 MacroAir AirStar Installation Manual...
- Page 3 TABLEOFCONTENTS Page 4 - Cautions And Safety Page 5 - Package Contents Page 6 - Tools Needed Page 7 - Fan Clearance / Placement Page 8 - I-beam Mounting Page 9 - Glulam Mounting Page 10 - Spanning Mount / Mount Assembly Page 11 - Extention Assembly Page 12 - Blades/ Blade Retainers Page 13 - Blade Retainer Assembly Page 14 - Wiring guide/ Cat5 B Copyright 2012 MacroAir AirStar Installation Manual...
-
Page 4: Damaged Equipment
Read these safety practices before installing, operating or servicing the fan. failure to follow these safety practices could result in death or serious injury. Be certain to follow the instructions in this manual. If you do not understand the instructions please call our Technical department for help. DAMAGED EQUIPMENT HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Do not operate or install any fans or fan Accesory that appears to be damaged. - Read and understand this manual before Failure to folow these instruction can result in death, serious injury, or equipment installing or operating. Installation, adjustment, damage. reapair, maintenance must be performed by qualified personel. MAINTENANCE AND SERVICE: - The user is responcable for compliance with If the fan does not operate properly useing the procedures in this manual, BE CERTAIN all international and national electrical code TO REMOVE ALL POWER TO THE UNIT and contact our technical department for futher requirements with respect to grounding of all assistance. equipment. Keep all body clear of moving part at all times. - Many of the part of this unit operat at line voltage. DO NOT TOUCH. All electrical troubleshooting and repair must be done by a qualified technician and meet all applicable codes. -Install all covers before applying power or starting and stopping the unit. Copyright 2012 MacroAir AirStar Installation Manual... -
Page 5: Package Contents
PACKAGE CONTENTS Image of Hardware and Mount Power Unit Remote Control Copyright 2012 MacroAir AirStar Installation Manual... -
Page 6: Tools Required
TOOLS REQUIRED 1. Socket set and ractchet (deep and short wall) 2. 3/8 allen key 3. Magnetic level 4. Phillips and Flat Head Screw driver 5. Network crimping tool (if standard connection will not work.) 6. Torque Wrench (Not Shown) Copyright 2012 MacroAir AirStar Installation Manual... - Page 7 Copyright 2012 MacroAir AirStar Installation Manual...
- Page 8 I-BEAM MOUNTING For installations with I-beams use MacroAir I-beam Kit (PN 60-50106-00). To properlly install mount be sure to use hang mount along slope of the roof. I-Beam Assembly Exploded View For ease of installation the Unistrut for our I-beam mount can be installed in two different configurations. Refer to images above for examples. Copyright 2012 MacroAir AirStar Installation Manual...
- Page 9 GLULAM MOUNTING Installation on Glulam beams will use MacroAir Glulam Mounting Kit (PN 60-50108- 00). Installing the mount alonge the slope of the roof will allow the proper leveling of the fan. Glulam Assembly Exploded View Glulam Installation utilizes unistrut in conjunction with our Glulam bracket for installations containing glulam beams. Copyright 2012 MacroAir AirStar Installation Manual...
- Page 10 GLULAM MOUNTING Spanning Mount also utilizes Unistrut for spanning mount installations. Power Unit Mount Exploded View Loosely install the mount hardware prior to installing fan. Once the fan is installed and level, tighten mount hardware down. Copyright 2012 MacroAir AirStar Installation Manual...
- Page 11 GLULAM MOUNTING Extension Assembly Exploded View When Extension is needed assemble between mount and power unit with provided hardware. (refer to chart on pg 4 for size recomendations) Copyright 2012 MacroAir AirStar Installation Manual...
- Page 12 BLADE RETAINER LINKS While installing blades be sure to install the blade reatainer links by over lapping the reatainers. Refer to image above for exploded view. Blade bolts must be torqued to 23 ft lbs. Copyright 2012 MacroAir AirStar Installation Manual...
-
Page 13: Blade Assembly
BLADE ASSEMBLY This image represents the correct installation of the Blade and Blade reatainer links. Copyright 2012 MacroAir AirStar Installation Manual... - Page 14 WIRING The Image above show how to The Image above shows the cable from the top of route cables through extension. the Fan A coulpler may also be use When useing an extension route cables to extend the length of the through extension. refer to the images above remote cable connection. In the case where a long CAT5 cable is required please follow the Cat5 B standard. Copyright 2012 MacroAir AirStar Installation Manual...
- Page 15 MacroAir 794 South Allen Street San Bernardino, CA 92408 macroairfans.com p 909.890.2270 Copyright 2012 MacroAir AirStar Installation Manual...
