MacroAir Technologies EnergyLogic AVD3 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation
Manual
AVD3
5901 Crossings Blvd
Antioch, TN 37013
www.energylogic.com
(800) 311-8828
© 2019 EnergyLogic, LLC
Toll Free: 800 311 8828
Fax: 615 471 5202
w w w.energylogic.com
i
Rev. Date 040819

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EnergyLogic AVD3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MacroAir Technologies EnergyLogic AVD3

Summary of Contents for MacroAir Technologies EnergyLogic AVD3

  • Page 1 Installation Manual AVD3 5901 Crossings Blvd Antioch, TN 37013 www.energylogic.com (800) 311-8828 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 2: Table Of Contents

    Table of Contents Caution & Safety ..........................2 Fusing Chart ............................5 Fan Placement & Clearance ......................6 Fan Dimensions ..........................9 Network Wiring ........................... 10 Components (Fixed Angle Mount) ..................... 11 Components (Universal Mount) ......................12 Fan Components & Tools ........................13 Mounts ..............................

  • Page 3: Caution & Safety

    Caution & Safety This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 Caution & Safety HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH. Read and understand this manual before installing or operating a fan unit. Installation, adjustment, repair, or maintenance must be performed by qualified personnel. The user is responsible for compliance with all international and National Electrical Code requirements with respect to the grounding of all equipment.
  • Page 5 Caution & Safety Key Safety System Components EnergyLogic fans are engineered with key safety features to prevent pieces of the fan from falling in the unlikely event of a catastrophic failure. Used together, these features provide comprehensive protection of people, equipment and property. Follow the detailed instructions precisely when installing fans, including the following: •...

  • Page 6: Fusing Chart

    Fusing Chart BRANCH CIRCUIT PROTECTION IS REQUIRED TO PROTECT THE ELECTRICAL COMPONENTS AND COMPLY WITH UL 507. Use the table below to select the correct fast acting fuse size for your application. The optional fuse disconnect switch provided by EnergyLogic uses class gG fast acting fuses. Fuses must be purchased separately.

  • Page 7: Fan Placement & Clearance

    Fan Placement & Clearance Sprinkler Systems and Fan Placement In any installation where fire sprinklers are in place, fans should not interfere with their correct operation. Fans should be located no less than 3 feet below a sprinkler, and placed centrally to each sprinkler quadrant.
  • Page 8 HVAC Diffuser with airflow ABOVE fan space from diffuser at least 2 x diameter away from intake/discharge © 2017 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 w w w.macroairfans.com Rev. Date 060319...
  • Page 9 Fan Placement & Clearance WARNING: FANS ARE NOT MEANT TO BE OPERATED IN WINDY CONDITIONS. The Fixed Angle Mount should only be used if the mounting surface is not a compound angle (sloping in multiple directions). The Universal Mount should be used for all compound angle surfaces.

  • Page 10: Fan Dimensions

    PROPRIETARY AND CONFIDENTIAL TOLERANCING PER: COMMENTS: THE INFORMATION CONTAINED IN THIS MATERIAL DRAWING IS THE SOLE PROPERTY OF MacroAir TECHNOLOGIES. ANY FINISH REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MacroAir TECHNOLOGIES IS PROHIBITED. DO NOT SCALE DRAWING ©...

  • Page 11: Network Wiring

    Network Wiring (Optional) Please refer to the appropriate Network manual (AirLynk, Controller 4, Controller 10/20/30) for all network wiring instructions. Only use the green CAT5e cable provided by EnergyLogic. CAT5e Cable CAT5e Cable (100ft / 30.5m) (100ft / 30.5m) Controller Wall Plug ©...

  • Page 12: Components (Fixed Angle Mount)

    Components (Fixed Angle Mount) Airfoil (3) Fixed Angle Mount Parts Extension Tube (1) Top Mount Plate (1) Guy Wire Bracket (2) AVD 3 Motor Fixed Angle Mount Bracket (2) Unit (1) Stranded Shielded CAT5e (1) I-Beam Clamp (2) RJ45 Pin-Out Type “B”...

  • Page 13: Components (Universal Mount)

    Components (Universal Mount) Airfoil (3) Universal Mount (1) Guy Wire Bracket (2) AVD 3 Motor Extension Tube (1) Unit (1) Stranded Shielded CAT5e (1) I-Beam Clamp (2) RJ45 Pin-Out Type “B” I-Beam Shim (2) Touchpad Digital Remote (1) Guy Wire Assembly Safety Cable Parts Wire Rope (4) 19ft (A), 23ft (B),...

  • Page 14: Fan Components & Tools

    Fan Components and Tools Tools Required: 3/4" 9/16" 1/2" 7/32" Allen Wrench (Provided) (Fixed Angle Mount Only) Note: A drill and drill bits will also be required when mounting to Glulams © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.

  • Page 15: Mounts

    Mounts Fixed Angle Mount Universal Mount Turn to page 15 Turn to page 32 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 16: 1- Fixed Angle Mount 1.1 Fixed Angle Mount - Mounting Bolt Kits

    1. All Fixed Angle Mounts 1.1 Mounting Bolt Kits The I-Beam Bolt Kit is included in the shipment of all fans. Additional parts must be purchased if mounting to a I-Beam Bolt Kit Glulam or Unistrut. 1/2"-13 Nylon Lock Nut (4) For mounting to steel trusses over 3 inches in width, use the I-Beam mounting.

  • Page 17: Fixed Angle Mount I-Beam (Steel Truss Mounting)

    1.1.1 Fixed Angle Mount I-Beam (Steel Truss Mounting) Use this method for steel trusses and I-Beams over 3” in width. Fixed Angle Mount Bolt Kit 3/8"-16 Nylon Lock Nut (4) 3/8" Washer (4) 3/8" Washer (4) Hand Tighten 3/8"-16 x 1/2" Serrated Flange Hex Head bolt (4) 3/8"-16 x 1 1/4"Countersunk 3/8"-16 x 1 1/4"Countersunk...
  • Page 18 1.1.1 Fixed Angle Mount I-Beam © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...
  • Page 19 1.1.1 Fixed Angle Mount I-Beam Hand Tighten Center the mount Center the Mount 75 ft-lbs 75 ft-lbs [102 N-m] 3/4” Complete I-Beam mount installation and turn to page 25 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.

  • Page 20: Fixed Angle Mount Glulam

    1.1.2 Fixed Angle Mount Glulam This method is recommended for Glulams or wood beams 5-1/8” or wider. For narrower beams, span across two or more beams using the Unistrut mounting method. Use the two holes closest to the center line of the glulam. 3/16"...
  • Page 21 1.1.2 Fixed Angle Mount Glulam Fixed Angle Mount Bolt Kit 3/8"-16 Nylon Lock Nut (4) 3/8" Washer (4) 3/8" Washer (4) Hand Tighten 3/8"-16 x 1/2" Serrated Flange Hex Head bolt (4) 3/8"-16 x 1 1/4"Countersunk 3/8"-16 x 1 1/4"Countersunk Socket Head Cap Screw (4) Socket Head Cap Screw (4) 7/32”...
  • Page 22 1.1.2 Fixed Angle Mount Glulam 3/4” 75 ft-lbs [102 N-m] Complete Glulam mount installation and turn to page 25 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 23: Fixed Angle Mount Unistrut

    1.1.3 Fixed Angle Mount Unistrut This method is used to span components of a building structure. Attachment points to the building structure can vary greatly, so we recommend contacting Unistrut so they can recommend the best method for attaching the Unistrut (www.unistrut.us).
  • Page 24 1.1.3 Fixed Angle Mount Unistrut Fixed Angle Mount Bolt Kit 3/8"-16 Nylon Lock Nut (4) 3/8" Washer (4) 3/8" Washer (4) Hand Tighten 3/8"-16 x 1/2" Serrated Flange Hex Head bolt (4) 3/8"-16 x 1 1/4"Countersunk 3/8"-16 x 1 1/4"Countersunk Socket Head Cap Screw (4) Socket Head Cap Screw (4) 7/32”...
  • Page 25 1.1.3 Fixed Angle Mount Unistrut 12-7/8” Minimum 1-5/8” Unistrut Unpierced Channels (P1000 or P1001B) Loctite 243 Loctite 243 recomended recomended 3/4” 50 ft-lbs 50 ft-lbs [68 N-m] Complete Unistrut mount installation and turn to page 25 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com...

  • Page 26: Fixed Angle Mount Extension Tube

    1.2 All Fixed Angle Mounts Extension Tube Before Continuing: 1. Run the power cable to the mounting location. 2. Run the shielded CAT5e cable from the controller to the mount. 3. The communications cable MUST be routed at least 1 foot away from power cables, high voltage power wires, and fluorescent lighting.

  • Page 27: Fixed Angle Mount Motor Unit

    1.3 All Fixed Angle Mounts Motor Unit Warning: The fan must be lifted by the struts. Do NOT lift the fan by the drive. Remove six (6) screws and the bottom cover. Be careful not to damage the electrical components with the cover removed. Must use Guy Wire Brackets when installing the Fixed Angle Mount Two people can lift the fan if a lift is not available.
  • Page 28 1.3 All Fixed Angle Mounts Motor Unit Carefully guide the motor shaft into the extension tube. CAUTION: Do not put force onto the building with the lift. 9/16” 30 ft-lbs Be careful of wires [41 N-m] © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com...
  • Page 29 1.3 All Fixed Angle Mounts Motor Unit WARNING: Do not put too much tension on the safety cable. This will deform the rubber boot and hinder the proper cooling of the motor. Do not bend rubber boot Ensure the 9/16” fan is level Universal Mount I-Beam safety cable starts on page 29 Universal Mount Glulam safety cable starts on page 30...

  • Page 30: Fixed Angle Mount I-Beam Safety Cable

    1.4.1 Fixed Angle Mount I-Beam Safety Cable WARNING: Do not put too much tension on the safety cable. There needs to be a small amount of slack present in the safety cable for proper functioning. Avoid sharp edges. Run safety Run safety cable around cable around...

  • Page 31: Fixed Angle Mount Glulam Safety Cable

    1.4.2 Fixed Angle Mount Glulam Safety Cable Run safety cable though hole Tighten both nuts 7 1/2 ft-lbs [10.2 N-m] Complete safety cable installation and turn to page 47 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.

  • Page 32: Fixed Angle Mount Unistrut Safety Cable

    1.4.3 Fixed Angle Mount Unistrut Safety Cable The safety cable must be securely attached to the building structure and NOT the unistrut. It can be attached to I-beams, steel trusses, or Glulams as shown in sections 1.4.1 and 1.4.2. Avoid sharp edges.

  • Page 33: Universal Mount - Mounting Bolt Kits

    2. All Universal Mounts 2.1 Mounting Bolt Kits The I-Beam Bolt Kit is included in the shipment of all fans. Additional parts must be purchased if mounting to a I-Beam Bolt Kit Glulam or Unistrut. 1/2"-13 Nylon Lock Nut (4) For mounting to steel trusses over 3 inches in width, use the I-Beam mounting.

  • Page 34: Universal Mount

    2.1.1 Universal Mount I-Beam (Steel Truss Mounting) Use this method for steel trusses and I-beams over 3” in width. Hand Tighten © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...
  • Page 35 2.1.1 Universal Mount I-Beam Hand Tighten Center the Mount 3/4” 75 ft-lbs [102 N-m] Complete I-Beam mount installation and turn to page 39 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 36: Universal Mount Glulam

    2.1.2 Universal Mount Glulam This method is recommended for Glulams or wood beams 5-1/8” or wider. For narrower beams, span across two or more beams using the Unistrut mounting method. Use the two holes closest to the center line of the glulam. 3/16"...
  • Page 37 2.1.2 Universal Mount Glulam 3/4” 75 ft-lbs 75 ft-lbs [102 N-m] Complete Glulam mount installation and turn to page 39 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 38: Universal Mount Unistrut

    2.1.3 Universal Mount Unistrut This method is used to span components of a building structure. Attachment points to the building structure can vary greatly, so we recommend contacting Unistrut so they can recommend the best method for attaching the Unistrut (www.unistrut.us). If the spanning distance is greater than 8 feet, please consult a Structural Engineer.
  • Page 39 2.1.3 Universal Mount Unistrut 12-7/8” Minimum 1-5/8” Unistrut Unpierced Channels (P1000 or P1001B) Loctite 243 Loctite 243 recomended recomended 3/4” 50 ft-lbs 50 ft-lbs [68 N-m] Complete Unistrut mount installation and turn to page 39 © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.

  • Page 40: Universal Mount Extension Tube

    2.2 All Universal Mounts Extension Tube Before Continuing: 1. Run the power cable to the mounting location. 2. Run the shielded CAT5e cable from the controller to the mount. 3. The communications cable MUST be routed at least 1 foot away from power cables, high voltage power wires, and fluorescent lighting.
  • Page 41 2.2 All Universal Mounts Extension Tube Be careful of wires 30 ft-lbs [41 N-m] NOTE: Power cable must be opposite from safety cable and CAT5e cable © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.

  • Page 42: Universal Mount Motor Unit

    2.3 All Universal Mounts Motor Unit WARNING: The fan must be lifted by the struts. Do NOT lift the fan by the drive. Remove six (6) screws and the bottom cover. Be careful not to damage the electrical components with the cover removed. Must use Guy Wire Brackets when installing the Universal Mount Two people can lift the fan if a lift is not available.
  • Page 43 2.3 All Universal Mounts Motor Unit Carefully guide the motor shaft into the extension tube. Caution: Do not put force onto the building with the lift. 9/16” 30 ft-lbs Be careful of wires [41 N-m] © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.
  • Page 44 2.3 All Universal Mounts Motor Unit WARNING: Do not put too much tension on the safety cable. This will deform the rubber boot and hinder the proper cooling of the motor. Do not bend rubber boot Ensure the fan is level Universal Mount I-Beam safety cable starts on page 44 Universal Mount Glulam safety cable starts on page 45 Universal Mount Unistrut safety cable starts on page 46...

  • Page 45: Safety Cable Installation

    2.4.1 Universal Mount I-Beam Safety Cable WARNING: Do not put too much tension on the safety cable. There needs to be a small amount of slack present in the safety cable for proper functioning. Avoid sharp edges. Run safety cable around I-Beam 7 1/2 ft-lbs [10.2 N-m] Complete safety cable installation and turn to page 47...

  • Page 46: Universal Mount Glulam Safety Cable

    24.2 Universal Mount Glulam Safety Cable WARNING: Do not put too much tension on the safety cable. There needs to be a small amount of slack present in the safety cable for proper functioning. Avoid sharp edges. Run safety cable Run safety cable though hole Tighten both nuts...

  • Page 47: Universal Mount Unistrut Safety Cable

    2.4.3 Universal Mount Unistrut Safety Cable The safety cable must be securely attached to the building structure and NOT the unistrut. It can be attached to I-beams, steel trusses, or Glulams as shown in sections 2.4.1 and 2.4.2. Avoid sharp edges.

  • Page 48: Guy Wire Installation

    3. Guy Wire Installation Required for both the Fixed Angle Mount and the Universal Mount. Guy Wire Assembly Wire Rope (4) 19ft (A), 23ft (B), or 33ft (C) 1/4" Quicklink (4) Wire Rope Clamp (8) Turn Buckle (4) 45° © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com...
  • Page 49 3. Guy Wire Installation Note: Guy wires need to be securely mounted to the building. You can use generic beam clamps when mounting to I-Beam or steel truss. Lag I-Bolts can be used when mounting to wood Glulams. Do not wrap guy wires around the building structure.
  • Page 50 3. Guy Wire Installation Hand Tighten ONLY Note: Make sure the Tighten the jam nuts fan remains level NOTE: Do not use tools to tighten the turnbuckles; only use tools to tighten the jam nuts. The guy wires MUST be taut so that there is no movement in the motor or extension tube.
  • Page 51 3. Guy Wire Installation Bend Cord Through Clip Note: The cord is cut to a predetermined length for proper tension. DO NOT excessively stretch the cord. © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.

  • Page 52: Drive Installation 4.1 Drive Installation

    4.1 Drive Installation Low Voltage Drive High Voltage Drive WARNING: POWER ABOVE 252 VAC WILL DESTROY A LOW VOLTAGE DRIVE Note: Model numbers ending with an “H” are high voltage while model numbers ending with an “L” are low voltage. Ground Wire CAUTION: RISK OF ELECTRIC SHOCK.

  • Page 53: Drive Installation (Low Voltage)

    4.1.1 Drive Installation Low Voltage Single Phase Low Three Phase Low Voltage Voltage L1 L2 L3 L1 L2 L3 Model AVD3 430 Model AVD3 430 Low Voltage: Low Voltage: 208-240 VAC 208-240 VAC WARNING: Keep hands away from components. CAUTION: RISK OF ELECTRIC SHOCK. The bus capacitors discharge to a level below 50V DC in 1 minute.

  • Page 54: Drive Installation High Voltage

    4.1.2 Drive Installation High Voltage Three Phase High Voltage Model AVD3 430 High Voltage: 380-480 VAC WARNING: Keep hands away from components. CAUTION: RISK OF ELECTRIC SHOCK. The bus capacitors discharge to a level below 50V DC in 1 minute. WHEN CYCLING INCOMING POWER, WAIT ONE (1) MINUTE BEFORE TURNING THE POWER BACK ON! Note: Make sure the fan is run only when the cover is reinstalled.

  • Page 55: Control Wiring

    4.2 Control Wiring There are two versions of the 430 drive. If your drive has a terminal block (shown below), connect the CAT5e cable to the terminal block following the wiring diagram (also shown below). If your drive does not have a terminal block, connect your CAT5e cable to the RJ45 port present on the drive.

  • Page 56: Airfoil Installation

    5. Airfoil Installation WARNING: To reduce the risk of personal injury, do not bend the airfoils or airfoil struts when installing the airfoils, balancing the airfoils, or cleaning the fan. Do not insert foreign objects in between rotating fan airfoils. 3 Blade Bolt Kit 5/16"-24 Nylon Lock Nut (6)
  • Page 57 5. Airfoil Installation 20 ft-lbs 20 ft-lbs [27 N-m] © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...
  • Page 58 5. Airfoil Installation © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 59: Disconnect Switch

    6.1 Fuse Disconnect Switch Installation (Recommended but optional) Service Disconnect (Required per NEC, OSHA, IEC, CE and UL compliance). Not Included - Optional Add-On Components: A - Fuse Block (Optional Add-On) B - Disconnect Switch (Optional Add-On) C - Class gG Fast Acting Fuses (Not Provided) - refer to the fuse chart on page 5 NOTE: Ensure that there is no power when installing this component.

  • Page 60: Emergency Disconnect Schematic

    THE INFORMATION CONTAINED IN THIS MATERIAL SIZE DWG. NO. DRAWING IS THE SOLE PROPERTY OF A-02 MacroAir TECHNOLOGIES. ANY FINISH REPRODUCTION IN PART OR AS A WHOLE 6.3 Enable (ON)/Disable (OFF) WITHOUT THE WRITTEN PERMISSION OF MacroAir TECHNOLOGIES IS Not to Scale WEIGHT: SHEET 1 OF 1 PROHIBITED.

  • Page 61: Touchpad Remote Mounting

    7.1 Touchpad Remote Mounting Place anchors into wall Remove plastic punchouts Flush Mounting is also available with a standard electrical box (not provided). © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...
  • Page 62 7.1 Touchpad Remote Mounting Note: 100 feet of shielded stranded CAT5e cable is provided standard. Up to 400 feet of cable can be ordered, and 400 feet is the maximum distance allowed. © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev.
  • Page 63 7.1 Touchpad Remote Mounting The provided shielded stranded CAT5e cable from the fan is plugged into the top of the enclosure. © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 64: Touchpad Remote Navigation

    7.2 Touchpad Remote Navigation Buttons: A - Forward / Reverse: Select fan rotational direction B - Power Button: Turn the fan on or off (forward or reverse must be chosen to start the fan) C - Speed Up / Speed Down: Increase or decrease the speed of the fan D - Speed Box: Real-time indication of fan speed E - Navigation: Navigate to the next screen F - Settings: Displays settings and information about the fan...

  • Page 65: Touchpad Remote Operations

    7.2 Touchpad Remote Operation Screens: A - Home Screen B - Fault Code Screen C - Operating Hours Screen D - Fan Diameter Selection Screen Instructions: 6.2.1: Once the fan is powered on, click the forward button and increase the speed by clicking the up button.

  • Page 66: Maintenance Information

    Maintenance Information Guy Wire Check (if applicable): Checking a EnergyLogic fan’s guy wires for tension and inspecting for frayed sections could mitigate a problem before it occurs. The guy wires should be under enough tension to prevent any movement in the motor unit or the extension tube. If the motor can be moved by pushing on it, the guy wires need to be tightened.

  • Page 67: Mounting Plate Dimensions

    Mounting Plate Dimensions Fixed Angle Mount Universal Mount © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 68: Mounting Bracket Dimensions

    Mounting Bracket Dimensions I-Beam Bracket Glulam Bracket © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 69: Touchpad Dimensions

    Touchpad Remote Dimensions Remote Enclosure Remote LCD Display © 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 w w w.energylogic.com Rev. Date 040819...

  • Page 70: Troubleshooting

    Troubleshooting It is recommended to wire the fan and the touchpad remote prior to turning on the power to the fan. If the fan is not operable, but the touchpad remote is lighting up, cycle power to the fan. If cycling the power did not resolve this issue, go to the fault code screen (reference page 64) and check to see if there is a code present.
  • Page 71 Troubleshooting Code Factory Code Name Description Symptoms Troubleshooting Tips Type Setting Phase Current A Auto- 1. Turn incoming power off for two 1004 High Fault Reset minutes, turn back on Intermittent/ No Operation 2. Confirm power is within fan’s Phase Current B Auto- 1005 specifications...
  • Page 72 Troubleshooting Code Factory Code Name Description Symptoms Troubleshooting Tips Type Setting 1. Confirm that heatsink temperature Is below 110C 2. Confirm that end caps are open and there is no blockage in the blades (AVD3) Heatsink 3. Confirm that the quick link on the Auto- Fan Stopping 1010...
  • Page 73 Troubleshooting Code Factory Code Name Description Symptoms Troubleshooting Tips Type Setting 1. Confirm whether touchpad was unplugged or not 2. A 1018 is most commonly seen if the touchpad is unplugged. In this case, pressing the reset button should clear the code and allow the fan to operate Fan Stops normally.
  • Page 74 Troubleshooting Code Factory Code Name Description Symptoms Troubleshooting Tips Type Setting Fan Will Not Start Fan Will Not Complete Blade Confirm that hall sensor is properly 1028 Hall Error Detect plugged into the drive Fan “Twitches” Fan Runs Irregularly 1. Confirm whether touchpad was unplugged or not 2.

  • Page 75: Warranty And Technical Support

    Warranty and Technical Support To register the installed fans for the 50,000 hour warranty, go to macroairfans.com/register. What does the 50,000-hour warranty cover? This warranty covers any part or component of the AirVolution-D shipped by EnergyLogic that is found to contain a manufacturing defect. EnergyLogic will repair or replace such part, component, or the entire fan free of charge.
  • Page 76 energy/ogi� IT'S WHAT GOOD ™ FEELS LIKE Energylogic, LLC 5901 Crossings Blvd., Antioch, TN 37013 Energylogic.com This document contains privileged and confidential information. Energylogic LLC submits this document with the understanding that it will be held in strict confidence. No part of the document may be circulated, quoted, or reproduced for distribution without the express written permission of Ener gylogic, LLC.
