INSTALLATION INSTRUCTIONS
NOUVEAU
QUESTIONS OR CONCERNS CONTACT CANARM AT:
1-800-265-1833 (ENGLISH)
1-800-567-2513 (FRENCH)
Monday through Friday 8:00 a.m. to 5:00 p.m. EST
IMPORTANT
FOR YOUR RECORDS, RECORD AND KEEP
THE FOLLOWING INFORMATION
Date of purchase:
Place of purchase:
Model on carton:
I.D.# (bottom of carton):
UPC (bottom of carton):
NOTE: FOR OPTIMUM QUIETNESS, FULLY ASSEMBLE FAN AND RUN FOR 24 HOURS
Advertisement
Table of Contents
Related Manuals for Canarm NOUVEAU
Summary of Contents for Canarm NOUVEAU
-
Page 1: Installation Instructions
12/09 INSTALLATION INSTRUCTIONS NOUVEAU QUESTIONS OR CONCERNS CONTACT CANARM AT: 1-800-265-1833 (ENGLISH) 1-800-567-2513 (FRENCH) Monday through Friday 8:00 a.m. to 5:00 p.m. EST IMPORTANT FOR YOUR RECORDS, RECORD AND KEEP THE FOLLOWING INFORMATION Date of purchase: Place of purchase: Model on carton: I.D.# (bottom of carton):... -
Page 2: Safety Precautions
SAFETY PRECAUTIONS 1. Turn off power at main electrical service box before starting installation. 2. Electrical connections must comply with local code ordinances or national electrical codes. 3. Make sure the installation site you choose allows the fan blades to rotate freely without any obstructions. - Page 3 CEILING FAN OPERATION ASSEMBLY DRAWING WARM WEATHER COLD WEATHER 1. wooden joist 2. metal outlet box (not provided) 3. ceiling 4. rubber gasket 5. mounting bracket 6. outlet box screws 7. wood screws & flat washers WITH DOWNROD WITHOUT DOWNROD 8.
-
Page 4: Installation
INSTALLATION INSTALLATION 1. MOUNTING (CONTINUED) 1. MOUNTING B. FLUSH MOUNT *NOTE: all set screws must be checked and re-tightened where • remove rubber ring from canopy. necessary after installation. • place canopy on fan housing by aligning 3 larger holes of canopy over 3 existingscrews on the motor housing. -
Page 5: Electrical Hook-Up
INSTALLATION INSTALLATION 3. HOOKING UP SAFETY CABLE 4. ELECTRICAL HOOKUP A. DOWNROD MOUNT This fan is equipped with a canopy type remote control unity for controlling the fan speeds and light kit. Please refer to the instruction sheet packed with the •... - Page 6 INSTALLATION INSTALLATION 6. MOUNTING BLADE BRACKETS TO BLADES 5. MOUNTING FAN ASSEMBLY A. “DIECAST” BLADE BRACKETS • loosen two screws and washers (B) on mounting bracket which correspond • obtain hardware package containing blade bracket screws and washers. with the slots in the canopy •...
- Page 7 INSTALLATION INSTALLATION 8. DETACHABLE LIGHT KITS (FIXED STYLE SWITCH HOUSING) 7. MOUNTING BLADE BRACKETS TO BLADES TO MOTOR • loosen all 3 screws, removing only one NOTE: Choice of 4 or 5 blades (option on some fans) • align 2 remaining screws with keyhole slots in metal pan of light kit Some fans offer the option of four or five blade operation.
-
Page 8: Troubleshooting
• some fan motors are sensitive to signals from solid state variable controls. If solid state controller is used, change to alternative control (See a Canarm representative for a list of available controls.) • allow a 24 hour break in period to eliminate noises Fan wobbles or •... - Page 9 FX: 450-665-0910 ROYAL COLLECTION FANS LIMITED LIFETIME WARRANTY “THANK YOU” for purchasing a Canarm product. It is our policy to furnish you with high quality products at a fair price. With proper installation your fan should provide you with years of money saving comfort.
