INSTALLATION INSTRUCTIONS
BUILDER - ENERGY STAR
QUESTIONS OR CONCERNS CONTACT CANARM AT:
1-800-265-1833 (ENGLISH)
1-800-567-2513 (FRENCH)
Monday through Friday 8:00 a.m. to 5:00 p.m. EST
IMPORTANT
FOR YOUR RECORDS, RECORD AND KEEP
THE FOLLOWING INFORMATION
Date of purchase:
Place of purchase:
Model on carton:
I.D.# (bottom of carton):
UPC (bottom of carton):
NOTE: FOR OPTIMUM QUIETNESS, FULLY ASSEMBLE FAN AND RUN FOR 24 HOURS
Advertisement
Table of Contents
Related Manuals for Canarm BUILDER
Summary of Contents for Canarm BUILDER
-
Page 1: Installation Instructions
12/09 INSTALLATION INSTRUCTIONS BUILDER - ENERGY STAR QUESTIONS OR CONCERNS CONTACT CANARM AT: 1-800-265-1833 (ENGLISH) 1-800-567-2513 (FRENCH) Monday through Friday 8:00 a.m. to 5:00 p.m. EST IMPORTANT FOR YOUR RECORDS, RECORD AND KEEP THE FOLLOWING INFORMATION Date of purchase: Place of purchase: Model on carton: I.D.# (bottom of carton):... -
Page 3: Safety Precautions
ASSEMBLY DRAWING SAFETY PRECAUTIONS 1. wooden joist 1. Turn off power at main electrical service box before starting installation. 2. metal outlet box (not provided) 3. ceiling 2. Electrical connections must comply with local code ordinances or 4. rubber gasket national electrical codes. -
Page 4: Installation
INSTALLATION INSTALLATION 2. INSTALL MOUNTING BRACKET 1. MOUNTING • secure rubber gasket and mounting bracket to metal outlet box using outlet box screws *NOTE: all set screws must be checked and re-tightened where • secure once more by placing two wood screws and flat washers (supplied) necessary after installation. -
Page 5: Electrical Hook-Up
Should the following method mounting bracket not meet your requirements call or visit your nearest Canarm distributor for a full • place looped end of safety cable over the wood screw and flat washer list of fan accessories. - Page 6 INSTALLATION INSTALLATION 4. ELECTRICAL HOOKUP (CONTINUED) 5. MOUNTING FAN ASSEMBLY • loosen two screws and washers (B) on mounting bracket which correspond B. CONNECTING BLACK, WHITE & (BLUE OR RED) WIRES with the slots in the canopy • remove two screws and washers (A) on the mounting bracket which correspond with the oblong holes in the canopy.
- Page 7 INSTALLATION INSTALLATION 6. MOUNTING BLADE BRACKETS TO BLADES 6. MOUNTING BLADE BRACKETS TO BLADES TO MOTOR A. “DIECAST” BLADE BRACKETS NOTE: Choice of 4 or 5 blades (option on some fans) • obtain hardware package containing blade bracket screws and washers. Some fans offer the option of four or five blade operation.
-
Page 8: Troubleshooting
• some fan motors are sensitive to signals from solid state variable controls. If solid state controller is used, change to alternative control (See a Canarm representative for a list of available controls.) • allow a 24 hour break in period to eliminate noises Fan wobbles or •... - Page 9 FX: 450-665-0910 CANARM 30 YEAR LIMITED WARRANTY “THANK YOU” for purchasing a Canarm product. It is our policy to furnish you with high quality products at a fair price. With proper installation your fan should provide you with years of money saving comfort.
