INSTALLATION INSTRUCTIONS
CITIE
QUESTIONS OR CONCERNS CONTACT CANARM AT:
1-800-265-1833 (ENGLISH)
1-800-567-2513 (FRENCH)
Monday through Friday 8:00 a.m. to 5:00 p.m. EST
IMPORTANT
FOR YOUR RECORDS, RECORD AND KEEP
THE FOLLOWING INFORMATION
Date of purchase:
Place of purchase:
Model on carton:
I.D.# (bottom of carton):
UPC (bottom of carton):
NOTE: FOR OPTIMUM QUIETNESS, FULLY ASSEMBLE FAN AND RUN FOR 24 HOURS
Advertisement
Table of Contents
Related Manuals for Canarm CITIE
Summary of Contents for Canarm CITIE
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS CITIE QUESTIONS OR CONCERNS CONTACT CANARM AT: 1-800-265-1833 (ENGLISH) 1-800-567-2513 (FRENCH) Monday through Friday 8:00 a.m. to 5:00 p.m. EST IMPORTANT FOR YOUR RECORDS, RECORD AND KEEP THE FOLLOWING INFORMATION Date of purchase: Place of purchase: Model on carton: I.D.# (bottom of carton):... -
Page 2: Safety Precautions
SAFETY PRECAUTIONS 1. Turn off power at main electrical service box before starting installation. 2. Electrical connections must comply with local code ordinances or national electrical codes. 3. Make sure the installation site you choose allows the fan blades to rotate freely without any obstructions. -
Page 3: Assembly Drawing
ASSEMBLY DRAWING 1. wooden joist 2. metal outlet box (not provided) 3. ceiling 4. mounting bracket 5. outlet box screws 6. wood screws & flat washers 7. downrod WITH DOWNROD 8. canopy 9. canopy cover 10. yoke cover 11. bolt 12. -
Page 4: Installation
INSTALLATION 1. MOUNTING *NOTE: all set screws must be checked and re-tightened where necessary after installation. DOWNROD MOUNT • obtain fan motor • remove cotter pin and bolt from yoke • loosen jam screw in yoke until it is flush with the inside surface •... -
Page 5: Install Mounting Bracket
INSTALLATION 2. INSTALL MOUNTING BRACKET • secure rubber gasket and mounting bracket to metal outlet box using outlet box screws • secure once more by placing two wood screws and flat washers (supplied) through outer slots of mounting bracket and into the wood joist. Leave one of the wood screws sufficiently loose to allow the safety cable to be looped around before final tightening. - Page 6 INSTALLATION 3. HOOKING UP SAFETY CABLE (DOWNROD MOUNT) • obtain fan and place hemisphere of downrod into mounting bracket • rotate fan until the slot in the hemisphere locks into the tab of the mounting bracket • place looped end of safety cable over the wood screw and flat washer not previously tightened (in Step 3) •...
- Page 7 INSTALLATION 4. PREPARING THE RECEIVER AND REMOTE CONTROL This remote control unit is equipped with 16 code combinations to prevent possible interference from or to other remote units. The frequency switches on your receiver and remote control have been preset at the factory. Please recheck to make sure the switches on the remote control and the receiver are set to the same position.
-
Page 8: Making The Electrical Connections
There are several different wiring combinations that can be used in controlling your ceiling fan to meet your specific requirements. Should the following method not meet your requirements call or visit your nearest Canarm distributor for a full list of fan accessories. - Page 9 INSTALLATION 6. SECURING THE FAN MOTOR ASSEMBLY TO THE MOUNTING BRACKET mounting bracket screw canopy screw canopy cover Remove one screw from the mounting bracket and loosen the other screw approximately 1/4 turn. Carefully raise the canopy up to the mounting bracket, and ensure the loosened screw is inserted into the key hole on the canopy.
-
Page 10: Blade Installation
INSTALLATION 7. BLADE INSTALLATION Fan motor assembly Blade Fiber washer Blade screw Insert the blades through the slots on the fan motor assembly. Attach the fan blades to the fan motor assembly using the blade screws and fiber washer and tighten them securely. Repeat this step for the other blades. -
Page 11: Installing The Light Kit
INSTALLATION 7. INSTALLING THE LIGHT KIT Mounting ring Light kit plate Black wire Light kit plate White wire Light kit plate Light kit Glass shade Halogen bulb Screw Screw ATTENTION: The Energy Policy Act of 2005 requires this fan to be equipped with a 190 watt limiting device, If lamping exceeds 190watts, the ceiling fan’s light kit will shut off automatically. -
Page 12: Cold Weather
CEILING FAN OPERATION WARM WEATHER COLD WEATHER DOWNDRAFT UPDRAFT reverse rotation forward rotation INSTRUCTIONS Restore power to the ceiling fan and test for proper operation. “ , ” buttons: Sets the fan speed. “ ” button: Turns the fan off. “... -
Page 13: Troubleshooting
• some fan motors are sensitive to signals from solid state variable controls. If solid state controller is used, change to alternative control (See a Canarm representative for a list of available controls.) • allow a 24 hour break in period to eliminate noises Fan wobbles or •... - Page 16 FX: 450-665-0910 CANARM 5 YEAR LIMITED WARRANTY “THANK YOU” for purchasing a Canarm product. It is our policy to furnish you with high quality products at a fair price. With proper installation your fan should provide you with years of money saving comfort.
