SPECIFICATIONS

D General
• Frequency range
• Channel spacing
• Frequency stability
• Operating temperature
• Antenna impedance
• Number of memory channels : 10 memory channels
• Mode
• Power supply requirement : 13.80 V / 27.50 V DC
(negative ground)
• Dimensions
(projections not incl.)
• Weight
*U.S.A. version only, receiving only.
30
: 118.000 to 136.975 MHz
161.650 to 163.275 MHz*
: 25 kHz
: ±5 ppm
: –20˚C to +55˚C
–4˚F to +131˚F
: 50 Ω
200 group channels
10 history channels
10 GPS channels
10 weather channels*
: AM (6K00A3E)
: 160 (W)34 (H)271 (D) mm
6 5 / (W)1 11 / (H)10 21 / (D) in
16 32 32
: approx 1.0 kg; 2.2 lb
D Transmitter
• Mode
• Output power
• Spurious emissions
• Microphone impedance
• Modulation limiting
D Receiver
• Receive system
• Intermediate frequencies
•Sensitivity
• Selectivity
• Spurious response rejc.
• Audio output power
Measurements made in accordance with RTCA DO-186B for
U.S.A. version. All stated specifications are subject to change
without notice or obligation.
: A3E
: 8 W (Carrier power)
: –60 dBc
: 600 Ω
: 70% (Max 98%)
: Double conversion
superheterodyne
: 1st 38.85 MHz
2nd 450 kHz
: (AM) Less than 2 µV (pd)
at 6 dB S/N
(FM) Less than 1.4 µV
at 12 dB SINAD*
: 6 dB ±3 kHz
60 dB ±22 kHz
: More than 74 dBµ
: 5 W with a 4 Ω load (External
speaker)
60 mW with a 500 Ω load
(Headphone)
