- Page 1 SPECTRACOOL™ Slim Fit Air ConditionerS (SurFACe-mount unitS only) QUICK START OPERATION GUIDE Rev. B © 2014 Pentair Equipment Protection www.pentairprotect.com P/N 89113978 89113977...
-
Page 2: Electrical Installation
5. Tighten the screw on the strain relief to secure the supply wire, see Figure 2. 6. For optional 3-phase operation, ensure the proper phase connection order by observing the phase monitor green light. Figure 1 Figure 2 - 2 - © 2014 Pentair Equipment Protection www.pentairprotect.com 89113977... -
Page 3: Door Switch
Adjust the controller to the desired cabinet temperature. The factory default cooling differential for controllers that are set-up for °C, or for °F, are as follows: Cooling Set-point Turn-on Turn-off 35°C 35°C 30°C 80°F 87°F 80°F - 3 - © 2014 Pentair Equipment Protection www.pentairprotect.com 89113977... - Page 4 S06 300W Surface-Mount Cutout Dashed Lines Represent the Air Conditioner 10.50 8.00 20.94 21.65 7.40 12.05 7.56 10.32 .315 11.02 Figure 6 S06 500W Surface-Mount Cutout Dashed Lines Represent the Air Conditioner - 4 - © 2014 Pentair Equipment Protection www.pentairprotect.com 89113977...
- Page 5 Dashed Lines Represent the Air Conditioner 14.00 14.96 12.44 21.65 25.63 62.19 1580 12.80 12.19 9.44 21.83 10.82 11.02 .375 (10) 15.75 Figure 8 S16 2000/2500W Surface-Mount Cutout Dashed Lines Represent the Air Conditioner - 5 - © 2014 Pentair Equipment Protection www.pentairprotect.com 89113977...
- Page 6 17.94 12.44 14.96 19.68 27.30 62.19 1580 14.77 16.13 6.46 19.66 10.82 14.96 .375 19.69 (10) Figure 9 S16 4000W Surface-Mount Cutout Dashed Lines Represent the Air Conditioner - 6 - © 2014 Pentair Equipment Protection www.pentairprotect.com 89113977...
