Page 1: Air Conditioner
PROAIR Air Conditioner Cr29 Model INSTRUCTION MANUAL © 2014 Pentair Equipment Protection 89104461 Rev. C P/N 89104461... -
Page 2: Table Of Contents
Refrigerant Loss ...................................... 16 TROUBLE SHOOTING .................................18 Basic Air Conditioning Trouble Shooting Check List ..........................18 Symptoms and Possible Causes: ................................19 WARRANTY ....................................22 RETURN AND REPAIR POLICY ................................22 LIMITATION OF LIABILITY..................................23 © 2014 Pentair Equipment Protection 89104461 - 2 -... -
Page 3: Receiving The Air Conditioner
Damage evident upon receipt should be noted on the freight bill. Damage should be brought to the attention of the delivering carrier -- NOT to Pentair Equipment Protection -- within 15 days of delivery. Save the carton and packing material and request an inspection. Then file a claim with the delivering carrier. -
Page 4: Installation Instructions
The Level II and III controller mounted on the air conditioner front panel is factory set for standard operation. All operating parameters are programmable for custom applications. Refer to the Level II and III programming and Operating Instruction Manual, 10-1008-161. © 2014 Pentair Equipment Protection 89104461 - 4 -... -
Page 5: Technical Information
2400/2800 4.1/4.2 131/55 118/54 -XXX will be replaced with a three-digit number designating all desired options. Consult the factory for specific model numbers. DIMENSION DRAWING CR29 MODELS 2700-4000 BTU/HR. (791-1172 WATT) © 2014 Pentair Equipment Protection 89104461 - 5 -... -
Page 6: Mounting Gasket Kit
Allow 20 inch above filter for removal. Mounting gasket kit part no. 29-4100-02 as applied to rear of CR29. Cutout Instructions NOTE: 1. DASHED LINES REPRESENT OUTSIDE OF AIR CONDITIONER © 2014 Pentair Equipment Protection 89104461 - 6 -... -
Page 7: Components List
Relay, compressor, start (CR290426 and CR290446 See Components List units only) Relay, compressor (CR2902XX and See Components List CR290416GXXX units only) Mounting gasket kit 29-4100-02 Capacitor, Compressor, Run See Components List © 2014 Pentair Equipment Protection 89104461 - 7 -... -
Page 8: Wire Diagrams And Schematics
WIRE DIAGRAMS AND SCHEMATICS WIRE DIAGRAM, LEVEL 1, 2000 BTU 89111534 A SCHEMATIC, LEVEL 1, 2000 BTU © 2014 Pentair Equipment Protection 89104461 - 8 -... -
Page 9: Wire Diagram, 115V, Level 1, 4000 Btu
WIRE DIAGRAM, 115V, LEVEL 1, 4000 BTU SCHEMATIC, 115V, LEVEL 1, 4000 BTU NOTE: For voltage, hertz, and options not shown in this manual, refer to the wiring diagram attached to the unit. © 2014 Pentair Equipment Protection 89104461 - 9 -... -
Page 10: Wire Diagram, 230V, Level 1, 4000 Btu
WIRE DIAGRAM, 230V, LEVEL 1, 4000 BTU SCHEMATIC, 230V, LEVEL 1, 4000 BTU NOTE: For voltage, hertz, and options not shown in this manual, refer to the wiring diagram attached to the unit. © 2014 Pentair Equipment Protection 89104461 - 10 -... -
Page 11: Wire Diagram, Level Ii And Iii, 2000 Btu
WIRE DIAGRAM, LEVEL II AND III, 2000 BTU © 2014 Pentair Equipment Protection 89104461 - 11 -... -
Page 12: Schematic, Level Ii And Iii, 2000 Btu
SCHEMATIC, LEVEL II AND III, 2000 BTU © 2014 Pentair Equipment Protection 89104461 - 12 -... -
Page 13: Wire Diagram, 115 Vlevel Ii And Iii, 4000 Btu
WIRE DIAGRAM, 115 VLEVEL II AND III, 4000 BTU SCHEMATIC, 115 V LEVEL II AND III, 4000 BTU NOTE: For voltage, hertz, and options not shown in this manual, refer to the wiring diagram attached to the unit. © 2014 Pentair Equipment Protection 89104461 - 13 -... -
Page 14: Wire Diagram, 230 V Level Ii And Iii, 4000 Btu
WIRE DIAGRAM, 230 V LEVEL II AND III, 4000 BTU SCHEMATIC, 230 V LEVEL II AND III, 4000 BTU NOTE: For voltage, hertz, and options not shown in this manual, refer to the wiring diagram attached to the unit. © 2014 Pentair Equipment Protection 89104461 - 14 -... -
Page 15: Temperature Control
Continued operation under the above conditions can and will damage and shorten compressor life. The air conditioner is available with an easily removable inlet filter to facilitate necessary cleaning. There should be no reason to neglect this necessary maintenance. © 2014 Pentair Equipment Protection 89104461 - 15 -... -
Page 16: How To Remove, Clean Or Install A New Inlet Air Filter
CAUTION Operation of the air conditioner in areas containing airborne caustics or chemicals can rapidly deteriorate filters, condenser coils, blowers and motors, etc. Contact Pentair Equipment Protection for special recommendations. REFRIGERANT LOSS Each air conditioner is thoroughly tested prior to leaving the factory to insure against refrigeration leaks. Shipping damage or microscopic leaks not found with sensitive electronic refrigerant leak detection equipment during manufacture may require repair or recharging of the system. - Page 17 NOTES © 2014 Pentair Equipment Protection 89104461 - 17 -...
-
Page 18: Trouble Shooting
(replace control box cover for safety). This will bypass the switch in the thermostat. Turn on the power. If both blowers and the compressor come on, the thermostat needs to be replaced. © 2014 Pentair Equipment Protection 89104461 - 18 -... -
Page 19: Symptoms And Possible Causes
Short in system Drain plugged Getting water in enclosure Drain tube kinked Enclosure not sealed (allowing humidity in) For additional technical support (amp draw, pressures, temperatures), contact Pentair Equipment Protection at 800-896-2665. © 2014 Pentair Equipment Protection 89104461 - 19 -... - Page 20 NOTES © 2014 Pentair Equipment Protection 89104461 - 20 -...
- Page 21 NOTES © 2014 Pentair Equipment Protection 89104461 - 21 -...
-
Page 22: Warranty
Pentair Equipment Protection approval. Pentair Equipment Protection must be notified of a claim in writing not later than fourteen (14) days from the date when Buyer has become aware of such occurrence, or where the defect is such that it may cause damage, immediately, such notice containing a description of how the defect manifests itself. -
Page 23: Limitation Of Liability
B. All returns to Pentair Equipment Protection must be securely packed, using original cartons if possible. All returns must have the RMA number visible on the outside of the carton. Pentair Equipment Protection is not responsible for material damaged in transit. Any refrigerant-bearing Goods must be shipped upright for return. -
Page 24: Pentair Equipment Protection
Pentair Equipment Protection 2100 Ho man Way Minneapolis, MN 55303 USA +1.763.422.2211 +1.763.576.3200 PentairProtect.com © 2014 Pentair Equipment Protection 89104461 Rev. C P/N 89104461...
