Page 1: Instruction Manual
Instruction Manual MX-3141HDA HDTV Video and Audio Routing Switcher... -
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance RS-232 Protocols 10.0 Contact Information... -
Page 4: Introduction
INTRODUCTION Thanks for purchasing this MX-3141HDA HDTV 4x1 Video and Audio Switcher from TV One. The MX-3141HDA is designed to switch four different Video inputs and their associated stereo audio inputs. The Video I/O is YPbPr and the Audio I/O are Right and Left channel Analog Audio or S/PDIF Digital Audio. -
Page 5: Specifications
SPECIFICATIONS Video Inputs MX-3141HDA 4x YPbPr via RCA Audio Inputs MX-3141HDA 4x via RCA + 4x Coaxial via RCA Video Outputs MX-3141HDA 1x YPbPr via RCA Audio Outputs MX-3141HDA 1x via RCA + 1x Coaxial via RCA Performance Video Bandwidth... -
Page 6: Checking Package Contents
CHECKING PACKAGE CONTENTS Before attempting to use this unit, please check the packaging and make certain the following items are contained in the shipping carton: 1x MX-3141HDA Video Routing Switcher 1x AC Power Adapter 1x IR Remote Control ... -
Page 7: Operating The Unit
In order for the remote to function properly, the small square window on the front of the MX-3141HDA must be unobstructed and not in sunlight or extremely bright artificial light and the distance from the IR remote and the switcher should not be more than found in a standard residential room. -
Page 8: Limited Warranty
LIMITED WARRANTY TV One warrants the original purchaser that the equipment it manufactures or sells will be free from defects in materials and workmanship for a fixed term from the date of purchase. The warranty term for specific product lines is defined below. 1. -
Page 9: Regulatory Compliance
REGULATORY COMPLIANCE The MX-3141HDA has been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supply has been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines. This Product and Power Adapter is RoHS Compliant. -
Page 10: Contact Information
Hsin Tai Wu Road, Hsichih No. 1900 Shangcheng Road Taipei Hsien 22101 Pudong, Shanghai Taiwan R.O.C. China 200120 Tel +886 2 2698-2296 Tel +86 21 5830-2960 Fax +886 2 2698-2297 Fax +86 21 5851-7949 sales.asia@tvone.com Email: sales.china@tvone.com www.tvoneasia.com www.tvonechina.com End of Manual...
