Summary of Contents for Tvone 1T-MX-3344
-
Page 1: Instruction Manual
Instruction Manual 1T-MX-3344 4x4 Matrix Switcher Component Video with Stereo Audio... -
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
CORIO are the registered Trademarks of TV One. All other trademarks are the property of their respective holders. Features The 1T-MX-3344 has many features that enable it to perform in a superior manner. Among those features you will find: •... -
Page 5: Specifications
SPECIFICATIONS Video Inputs YPbPr or YUV Component 4x via 3x RCA Video Outputs YPbPr or YUV Component 4x via 3x RCA Audio Inputs Analog Stereo (R/L) 4x via 2x RCA Audio Outputs Analog Stereo (R/L) 4x via 2x RCA Performance Television Standards NTSC, PAL Video Level... -
Page 6: Checking Package Contents
Please study the panel drawings below and become familiar with the signal input, outputs, power requirements/inputs plus any controls present. The 1T-MX-3344 is a 4x4 Matrix Switcher capable of switching Component Video Signals, YPbPr or YUV (Y,R-Y,B-Y), plus line level Stereo (L&R) Audio Signals input via connectors on the rear of the unit. -
Page 7: Operating The Unit
The 1T-MX-3344 can be controlled via any of three (3) methods: From the front panel, by use of the included Infrared Remote Controller, or via the RS-232 functionality. - Page 8 The included RC-44 Infrared Remote Controller has a Power Switch at the top right that can be used to turn the 1T-MX-3344 on and off. Beneath that switch you’ll find four rows of selector buttons. The top row controls selections for output number one, the second row controls input selections for output two and the third and fourth rows control input selections for outputs number three and four respectively.
-
Page 9: Troubleshooting
Output 4, Select Input 4 TROUBLESHOOTING Aside from faulty AC or DC power, most problems with the 1T-MX-3344 relate to damaged/poor quality cables or incorrect signal levels. If some inputs function correctly and others do not, interchange cables between sources and see if the problem moves with the cables. -
Page 10: Limited Warranty
REGULATORY COMPLIANCE The 1T-MX-3344 has been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supply has been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines. This Product... -
Page 11: Contact Information
San-Min Rd, Panchiao City No.518 Shangcheng Road Taipei Hsien 220 Pudong, Shanghai Taiwan R.O.C. China 200120 Tel +886 2 8951-0674 Tel +86 21 5830-2960 Fax +886 2 8951-0675 Fax +86 21 5878-0161 sales.asia@tvone.com Email: sales.china@tvone.com www.tvoneasia.com Website: www.tvonechina.com End of Manual...
