Page 1: Instruction Manual
Instruction Manual 1T-DVI-721 and 1T-DVI-741 DVI Switchers... -
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
INTRODUCTION Thanks for purchasing this 1T-DVI-721 2x1 or 1T-DVI-741 DVI Switcher from TV One. The DVI Switcher is designed to allow the switching of multiple DVI (HDCP or non- HDCP compliant) DVI signals to one display device. Our professional video conversion products have been serving the industry for over twenty years. -
Page 5: Specifications
1x DVI-I 29 pin female Display device selection Push Button or Remote Mechanical Dimension (H-W-D) 44x160x70mm (1.7”x6.3”x2.8” ) 1T-DVI-721 Weight (Net) 400 g (0.86 lbs) 1T-DVI-741 Weight (Net) 450 g (0.86 lbs) Warranty Limited Warranty 2 Years Parts and Labor... -
Page 6: Connecting The Hardware
CONNECTING THE HARDWARE Please study the panel drawings below and become familiar with the signal inputs, output, power requirements/inputs plus any controls present. This will facilitate in better understanding the operating instructions that follow. After familiarizing yourself with the unit’s controls and connectors, connect appropriate input and output cables plus the AC adapter as explained below. -
Page 7: Operating The Unit
OPERATING THE UNIT Before installation, please make sure all of devices have been turned off. • Connect your DVI display to the switcher’s DVI output with high quality cable • Connect two or four DVI-I sources to the switcher’s inputs (total depends on switcher model) with high quality cable •... -
Page 8: Limited Warranty
TV One. Should the dealer’s technical personnel be unable to assist you, contact TV One via our support website: http://tvone.crmdesk.com. Create a technical support request on the site and our support team will respond within a short period of time.
