Summary of Contents for Tvone 1T-EDID-11

  • Page 1: Instruction Manual

    Instruction Manual 1T-EDID-11 EDID/CEC Selector...
  • Page 3: Table Of Contents

    Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information...
  • Page 4: Introduction

    Thanks for purchasing the 1T-EDID-11 EDID/CEC Selector product from TV One. The 1T-EDID-11 allows easy set up of the EDID and CEC parameters between a source and display monitor. Instead of waiting for the source and display to synchronize, this HDMI switcher saves time by using preset EDID and CEC settings to speed up the process.
  • Page 5: Specifications

    3 Years Parts and Labor Regulatory Approvals 3G Extender Unit FCC, CE, RoHS Power Supply UL, CUL, CE, PSE, GS, RoHS Mechanical (H-W-D) 1T-EDID-11 (HWD) 30x125x90mm (1.2x4.9x3.54”) Weight 1T-EDID-11 250g (0.55 lbs) Power Requirement External Power Supply 5 VDC@2A, Locking DC...
  • Page 6: Checking Package Contents

    1T-EDID-11 EDID/CEC Selector Connect the source device’s output to the HDMI IN connector of the 1T-EDID-11 using a high quality cable. Connect an HDMI cable to the HDMI OUTPUT connector and then to the display...
  • Page 7: Operating The Unit

    HDMI compatible display devices will eventually sort out the incoming resolution and signal type. If capable of displaying the incoming signal, they will do so after several seconds. The purpose of the 1T-EDID-11 is to allow you to speed up the process by pre-selecting the appropriate signal.
  • Page 8: Troubleshooting

    Other than faulty cables or attempting to use the product over too great a distance, there are seldom problems with the 1T-EDID-11 EDID/CEC Selector product. If there is no image present at the remote location, connect the display device directly to the source to make certain that the problem is not in the display.
  • Page 9: Regulatory Compliance

    REGULATORY COMPLIANCE The 1T-EDID-11 EDID/CEC Selector has been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supply has been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines.
  • Page 10 Erlanger, KY 41018 Westwood Industrial Estate Margate, Kent CT9 4JG, UK Tel 859-282-7303 Tel +44 (0)1843 873311 Fax 859-282-8225 Fax +44 (0)1843 873312 sales@tvone.com sales.europe@tvone.com www.tvone.com www.tvone.eu TV One Latin America TV One Mercosur 6991 NW 82 Avenue #8 AV Diaz Velez 3965 PB...
