  • Page 1 PUSH OPERATING MANUAL 56-VOLT LITHIUM-ION CORDLESS LINE TRIMMER MODEL NUMBER ST1200E WARNING: To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Read All Instructions ........3 Safety Symbols .

  • Page 3: Read All Instructions

    READ ALL INSTRUCTIONS! This line trimmer has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate. DANGER! People with electronic devices, such as pacemakers, should consult their physician(s) before using this product.

  • Page 4: Safety Symbols

    SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate it. Safety Alert Precautions that involve your safety. To reduce the risk of injury, user must read WARNING: Read and understand operator’s manual before operator’s manual...
  • Page 6 Volt Voltage Amperes Current Hertz Frequency (cycles per second) Watt Power Minutes Time Alternating Current Type of current Direct Current Type or a characteristic of current No-Load Speed Rotational speed, at no load ... /min Per Minute Revolutions per minute 56V LITHIUM-ION CORDLESS LINE TRIMMER...

  • Page 7: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING! When using electric trimmers, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the following: READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE DANGER! Do not rely on the tool’s insulation against electric shock. To reduce the risk of electrocution, never operate the tool in the vicinity of any wires or cables (power, etc.) which may carry electric current.
  • Page 8 ◾ ◾ Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of rubber gloves and substantial footwear is recommended when working outdoors. Wear protective hair covering to contain long hair. ◾ ◾ Use Safety Glasses –...
  • Page 9 Never hold the cutting attachment above waist height. ◾ ◾ If situations occur that are not covered in this manual, use care and good judgment. Contact the EGO Service Center for assistance. 56V LITHIUM-ION CORDLESS LINE TRIMMER...

  • Page 10: Save These Instructions

    The battery or conductor may overheat and cause burns. ◾ ◾ Replacement Parts – When servicing, use only identical EGO replacement parts. Use of any other accessory or attachment may increase the risk of injury ◾ ◾...

  • Page 11: Introduction

    Should you experience any problem you cannot easily remedy, please contact EGO customer service center 1300 000 EGO (1300 000 346). This manual contains important information on to the safe assembly, operation and maintenance of your line trimmer. Read it carefully before using the line trimmer. Keep this manual handy so you can refer to it at any time.

  • Page 12: Assembly

    ASSEMBLY WARNING: If any parts are damaged or missing, do not operate this product until the parts are replaced. Use of this product with damaged or missing parts could result in serious personal injury. WARNING: Do not attempt to modify this product or create accessories not recommended for use with this line trimmer.
  • Page 13 MOUNTING THE GUARD WARNING: Always wear gloves when mounting or replacing the guard. Take care of the blade on the guard and protect your hand from cutting. 1. Remove the battery pack from the trimmer. 2. Position your trimmer so that the trimmer head faces up.

  • Page 14: Packing List

    MOUNTING AND ADJUSTING THE FRONT-ASSIST HANDLE 1. Remove the battery pack from the trimmer. Front-Assist Handle 2. Loosen the four screws in the handle with a Phillips screwdriver (available separately) and remove the screws, spring washers, flat washers and lower clamp from the handle (Fig.

  • Page 15: Description

    DESCRIPTION KNOW YOUR LINE TRIMMER (Fig. 6a & 6b) Rear Handle Lock-Off Lever Battery-Release Button Trigger Adjustable Front-Assist Handle Soft Sleeve Shaft Bump Protector Latch Guard PUSH Electric Contacts Line-Cutting Blade Bump Head (Cutting Head) Bump Knob Ejection Mechanism WARNING: Never operate the tool without the guard firmly in place.
  • Page 16 ADJUSTABLE FRONT-ASSIST HANDLE For easy control of the trimmer during cutting. REAR HANDLE Ergonomic handle with overmold improves comfort and grip. TRIGGER To turn the line trimmer On and Off. LOCK-OFF LEVER Helps prevent accidental or unauthorized activation of the trigger. It must be depressed before the trigger can be activated.

  • Page 17: Operation

    OPERATION WARNING: Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. WARNING: Always wear eye protection with side shields marked to comply with AS1337.1 2010. along with hearing protection. Failure to do so could result in objects being thrown into your eyes and other possible serious injuries.
  • Page 18 To remove (Fig. 8) WARNING: Always take care of your feet and children or pets around you when pressing the battery release button. Serious injury could result if the battery Press to Release pack falls. NEVER remove the battery pack at a high location. ◾...
  • Page 19 STARTING/STOPPING THE LINE TRIMMER Before starting the line trimmer ◾ ◾ Make sure you have a secure and balanced footing. ◾ ◾ Stand upright and hold the line trimmer in a relaxed position. ◾ ◾ Make sure that the cutting line is not touching the ground or any other objects. ◾...
  • Page 20 WARNING: To prevent serious personal injury, remove the battery pack from the tool before servicing, cleaning, changing attachments or removing material from the unit. Before each use check for damage/worn parts Check the bump head, guard and front-assist handle and replace the parts that are cracked, warped, bent, or damaged in any away.
  • Page 21 Tips for best trimming results (Fig. 12) ◾ ◾ The correct angle for the cutting attachment is parallel to the ground. Direction of rotation ◾ ◾ This line trimmer allows you to rest the bump knob on the ground for operating more comfortably.
  • Page 22 ADJUSTING CUTTING LINE LENGTH The bump head allows the operator to release more cutting line without stopping the motor. As line becomes frayed or worn, additional line can be released by lightly tapping the bump knob on the ground while operating the trimmer (Fig. 13). Bump Knob NOTICE: Always keep the cutting line fully extended.
  • Page 23 LINE REPLACEMENT WARNING: Always use only EGO authorized replacement nylon cutting line. Using line other than that specified may cause the line trimmer to overheat or become damaged. WARNING: Never use metal-reinforced line, wire, or rope, etc. These can break off and become dangerous projectiles.
  • Page 24 5. Hook the folded end of the cutting line onto either of the slots in the Wind Direction spool (Fig. 18). 6. Wind the line, in two even and tight layers, onto the spool. Wind the line in the direction indicated on the spool (Fig.
  • Page 25 9. Hold the spool and spool retainer; grasp the line and pull it to release the line from the notch in the eyelet (Fig. 21). 21 21 10. Check to see if the spring is Spring Spring properly located in the spool base. If it comes loose or drops out, position the spring in the mounting hole of the spool base and press it...
  • Page 26 WARNING: Always use only EGO authorized replacement nylon cutting line. Using line other than specified may cause the line trimmer to overheat or be damaged. 1. Press the release tabs on the spool retainer and remove the retainer by pulling it straight out (Fig.

  • Page 27: Maintenance

    MAINTENANCE WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. Inspect and maintain the machine regularly. To ensure safety and reliability, all repairs should be performed by a qualified service technician.
  • Page 28 Protecting the environment Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.

  • Page 29: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION Line trimmer 1. The battery pack is not 1. Attach the battery pack to the doesn’t work. attached to the trimmer. trimmer. 2. No electrical contact between 2. Remove battery, check contacts the trimmer and battery. and reinstall the battery pack.

  • Page 30: Warranty

    5 year limited warranty on EGO outdoor power equipment and 3 year limited warranty on EGO Power+ System battery packs and chargers. Please contact EGO customer service on 1300 000 EGO (1300 000 346) any time you have questions or warranty claims.
  • Page 31 Chervon Australia Pty Ltd, Unit 13, 1488 Ferntree Gully Rd, Knoxfield, VIC. 3180. Phone Number: 1300 000 EGO (1300 000 346). Email address: support@egopowerplus.com.au...

  • Page 32: Parts List

    PARTS LIST 56V LITHIUM-ION CORDLESS LINE TRIMMER MODEL NUMBER ST1200E The Model Number will be found on the Nameplate attached to the housing of the line trimmer. Always mention the Model Number when ordering parts for this tool. EXPLODED VIEW 56V LITHIUM-ION CORDLESS LINE TRIMMER...

  • Page 33: Parts List

    PARTS LIST INDEX PART NO. DESCRIPTION NUMBER 2823713000 Line cutting blade set 2823710000 Guard assembly 2823712000 Spool retainer assembly 3800097000 Cutting line 2823045000 Spool assembly 2823709000 Bump head assembly 2823711000 Front-assist handle assembly. 3660269000 Spring (in the bump head) 2822959000 Hexagon nut set (for bump head) 3650148000 Bump protector...
