Summary of Contents for Datalogic DIAMOND D531

  • Page 1 DIAMOND™ D531 Scanners Quick Reference...
  • Page 3 Diamond™ D531 Scanners QUICK REFERENCE...
  • Page 4 Datalogic reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material. Product names mentioned herein are for identification purposes only and may be trademarks and or registered trademarks of their respective companies.

  • Page 5: Table Of Contents

    CONTENTS Updates and Language Availability..............v Using Diamond™ ....................1 Sleep State......................1 Single Line Mode ....................2 Connections ......................3 Connecting / Disconnecting the Cable ..............5 Interface Selection ....................5 USB Interface Configuration ................6 USB Interface Selection ..................9 USB Keyboard Nationality.................
  • Page 6 Patents ......................22 Services and Support..................22 Compliance ....................... 23...

  • Page 7: Updates And Language Availability

    The latest drivers and documentation updates for this product are available on Internet. Log on to : www.datalogic.com Su Internet sono disponibili le versioni aggiornate di driver e documentazione di questo prodotto. Questo manuale è disponibile anche nella versione italiana.

  • Page 9: Using Diamond

    DIAMOND™ D531 USING DIAMOND™ The Datalogic Diamond™ D531 is an omni-directional scanner, which generates a scan pattern of 16 lines, thus ensuring high performance scanning. Barcodes are read simply on presentation to the scanner window. The Diamond™ scanner can be used handsfree as well as hand-held, e.g.: Handsfree scanning by presenting the item to the scanner using a sweeping curved motion towards the scanner window.

  • Page 10: Single Line Mode

    DATALOGIC SINGLE LINE MODE When many barcodes are present in the same reading area, like in barcode price lists or in the case of configuration barcodes in this manual, selecting a specific barcode to read is not practical with the large raster pattern emitted by the Diamond™, so a special single line scanning mode can be easily entered to...

  • Page 11: Connections

    DIAMOND™ D531 CONNECTIONS The scanner and the host system must be switched off before starting the installation of the scanner. By following this precaution you prevent any electrical damage. You are advised to install the scanner in a place with good air circulation out of direct sunlight.
  • Page 12 DATALOGIC (if required) KEYBOARD WEDGE...

  • Page 13: Connecting / Disconnecting The Cable

    DIAMOND™ D531 CONNECTING / DISCONNECTING THE CABLE Interface Cable Connector INTERFACE SELECTION Follow the procedure to configure the interface required by your application. • USB Interface • RS232 Interface • Wedge Interface...

  • Page 14: Usb Interface Configuration

    DATALOGIC USB INTERFACE CONFIGURATION The USB interface is compatible with: Windows 98 (and later) Mac OS 8.0 (and later) IBM POS for Windows 4690 Operating System Start-Up As with all USB devices, upon connection, the Host performs several checks by communicating with the Diamond™.
  • Page 15 DIAMOND™ D531 First Start-Up Connect Diamond™ to Green LED blinks Host Load drivers (if required) Does a dialog box appear Disconnect scanner Green LED off warning that Bus at Host power is not sufficient? Connect external power supply to cable and power up Green LED off - BEEP OK Select desired USB Reconnect reader...
  • Page 16 DATALOGIC Successive Start-Ups Connect Diamond™ to Green LED blinks Host Does a dialog box Disconnect scanner appear warning Green LED off at Host that Bus power is not sufficient? Connect external power supply to cable and power up Green LED off - BEEP OK Reconnect reader Read test codes.

  • Page 17: Usb Interface Selection

    USB-KBD Ì$+UA03$-:Î USB-KBD-ALT-MODE Ì$+UA04$-@Î USB-KBD-APPLE Ì$+UA05$-FÎ USB-COM* Ì$+UA02$-4Î USB-IBM-Table Top Ì$+UA00$-(Î USB-IBM-Hand Held Ì$+UA01$-.Î When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software, which can be downloaded from the web site http://www.datalogic.com.

  • Page 18: Usb Keyboard Nationality

    DATALOGIC USB KEYBOARD NATIONALITY USB-KBD users should select one of the following keyboard nationality codes. Belge Ì$+FJ7$-8Î Deutsch Ì$+FJ3$-$Î English Ì$+FJ4$-)Î Español Ì$+FJ6$-3Î Français Ì$+FJ2$-ÊÎ Italiano Ì$+FJ1$-ÅÎ Svenskt Ì$+FJ5$-.Î Ì$+FJ0$-|Î Japanese Ì$+FJ8$-=Î...

  • Page 19: Rs232 Reader Configuration

    DIAMOND™ D531 RS232 READER CONFIGURATION Read the restore default code, then read the interface selection code for your application: RESTORE DEFAULT Ì$+$*oÎ RS232 INTERFACE Standard Ì$+CP0$-$Î POS TERMINALS Nixdorf Mode A Ì$+CM2EC0$->Î Fujitsu Ì$+CM1$-ÈÎ ICL Mode Ì$+CM0$-ÃÎ...

  • Page 20: Wedge Interface Selection

    DATALOGIC WEDGE INTERFACE SELECTION Read the restore default code, then read the interface selection code for your application: RESTORE DEFAULT Ì$+$*oÎ WEDGE INTERFACE IBM AT or PS/2 PCs Ì$+CP500$-aÎ IBM XT Ì$+CP503$-vÎ PC Notebook Ì$+CP505$-ÈÎ IBM SURE1 Ì$+CP506$-$Î IBM Terminal 3153...
  • Page 21 DIAMOND™ D531 WEDGE INTERFACE (CONTINUED) IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct key transmission code. Select the keyboard type if necessary (default = advanced keyboard). KEY TRANSMISSION MODE make-only keyboard Ì$+CP502$-oÎ...
  • Page 22 DATALOGIC WEDGE INTERFACE (CONTINUED) WYSE TERMINALS ANSI Keyboard Ì$+CP509$-9Î PC Keyboard Ì$+CP510$-gÎ ASCII Keyboard Ì$+CP511$-nÎ VT220 style Keyboard Ì$+CP514$-ÇÎ DIGITAL TERMINALS VT2xx/VT3xx/VT4xx Ì$+CP512$-uÎ...

  • Page 23: Wedge Keyboard Nationality

    DIAMOND™ D531 WEDGE KEYBOARD NATIONALITY If you selected the Wedge interface, you should also read among the following codes the one that matches your Keyboard Nationality: Belge Ì$+FJ7$-8Î Deutsch Ì$+FJ3$-$Î English Ì$+FJ4$-)Î Español Ì$+FJ6$-3Î Français Ì$+FJ2$-ÊÎ Italiano Ì$+FJ1$-ÅÎ Svenskt Ì$+FJ5$-.Î Ì$+FJ0$-|Î...

  • Page 24: Default Values

    DATALOGIC DEFAULT VALUES USB DEFAULT SETTINGS : code identifier disabled, no field adjustment, code length not DATA FORMAT transmitted, character replacement disabled. : USA keyboard, inter-character and inter-code delays disabled, USB KEYBOARD control character emulation = ctrl+shift+key. : no handshaking, delay disabled, rx timeout 5 sec., ack/nack disabled, USB COM serial decode control = disabled, serial sleep control = disabled.
  • Page 25 DIAMOND™ D531 : code identifier enabled, no field adjustment, code length not DATA FORMAT transmitted, no header, terminator = CR, character replacement disabled. WEDGE DEFAULT SETTINGS USA keyboard, caps lock off, caps lock auto-recognition enabled, num lock unchanged, inter-character and inter-code delays disabled, control character emulation = ctrl+shift+key.

  • Page 26: Operating Test

    DATALOGIC OPERATING TEST Read the TEST codes below. EAN-8 1 2 3 4 5 6 7 0 EAN-13 1 2 3 4 5 6 7 0 0 0 9 9 2 Code 39 (Normal) Code 128 Interleaved 2 of 5 0 1 2 3 4 5 6 7 8 4 YOUR SCANNER IS NOW READY TO READ CODES.

  • Page 27: Technical Features

    Light Source Visible laser diode (in the range 630 ~ 680 nm) Reading Field See reading diagram Max Resolution 0.10 mm (4 mils) Min. 20% (Datalogic Test Chart) Scan Pattern 4 directions, 16 lines Scan Rate 1200 scans/seconds Environmental Features Operating Temperature 0°...

  • Page 28: Reading Diagram

    DATALOGIC READING DIAGRAM Reading Zones (15° skew angle) CODE 39 CODE 39 EAN13 = M 1 0.10 mm 0.21 mm 0.33 mm (4 mils) (8 mils) (13 mils) (cm)

  • Page 29: Scanner Data Entry

    24 months from the date of shipment, provided that the product is operated under normal and proper conditions. Datalogic has the faculty to repair or replace the product, these provisions do not prolong the original warranty term.

  • Page 30: Services And Support

    1,012,189 Additional patents pending. SERVICES AND SUPPORT Datalogic provides several services as well as technical support through its website. Log on to www.datalogic.com and click on the links indicated for further information including: • PRODUCTS Search through the links to arrive at your product page where you can download specific Manuals and Software &...

  • Page 31: Fcc Compliance

    FCC COMPLIANCE Modifications or changes to this equipment without the expressed written approval of Datalogic could void the authority to use the equipment. This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation.
  • Page 32 DATALOGIC S.p.A., Via Candini, 2 40012 - Lippo di Calderara Bologna - Italy dichiara che declares that the déclare que le bescheinigt, daß das Gerät declare que el DIAMOND Dxxx e tutti i suoi modelli and all its models et tous ses modèles...
