  • Page 1 GRYPHON™ Reference Manual...
  • Page 3 GRYPHON™ REFERENCE MANUAL...
  • Page 4 ALL RIGHTS RESERVED Datalogic reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    2.8.1 Battery Type....................7 2.8.2 Battery Charging ................... 7 2.8.3 Replacing GRYPHON™ M Batteries ............7 GRYPHON™ M SYSTEM AND NETWORK LAYOUTS ........ 9 Stand Alone Layouts ..................9 3.1.1 Single Reader Layout..................9 3.1.2 Multiple Reader Layout ................. 9 3.1.3...
  • Page 6 RS232 PARAMETERS ................29 Baud Rate ....................30 Parity......................31 Data Bits ..................... 31 Stop Bits...................... 32 Handshaking ....................32 Ack/Nack Protocol..................33 FIFO......................33 Inter-character Delay................... 34 Rx Timeout....................34 Serial Trigger Lock..................35 USB PARAMETERS .................. 36 Handshaking ....................37 Ack/Nack Protocol..................
  • Page 7 DATA FORMAT ..................58 Code Identifier..................... 61 Custom Code Identifier ................62 Header ......................63 Terminator....................64 Field Adjustment ..................65 Field Adjustment Character................. 66 Code Length Tx ..................66 Character Replacement ................67 Address Stamping (M Series Only) ............. 69 Address Delimiter (M Series Only) ..............
  • Page 8 Code 93 ...................... 94 Codabar Family................... 95 MSI ......................97 Plessey ....................... 98 Telepen ....................... 99 Delta IBM ....................100 Code 11 ....................101 Code 16K ....................102 Code 49 ....................102 PDF417..................... 103 RSS Codes ....................104 ADVANCED FORMATTING ..............105 Concatenation...................
  • Page 9 Single Store ....................143 Configuration Editing Commands.............. 144 5.10 Configuration Copying Commands ............145 5.10.1 Copy GRYPHON™ D-Series..............145 5.10.2 Copy GRYPHON™ M-Series ..............146 5.10.3 Copy OM-GRYPHON™ ................147 5.11 C-GRYPHON™ Configuration ..............148 5.12 Default Parameters for POS Terminals............. 149 TECHNICAL FEATURES .................

  • Page 10: General View

    GENERAL VIEW GRYPHON™ D/M READERS Gryphon™ D Cable Connector Gryphon™ M Battery Cover Trigger Reading Window Figure A – Gryphon™ D and M Series Readers Battery Reconditioning Button LEDs Figure B – OM-GRYPHON™ and C-GRYPHON™ viii...

  • Page 11: Introduction

    30 cm. High resolution codes, which can reach 3 mils are also easily read. Two specific models of the Gryphon™ series (D200 and M200) have also been designed to provide decoding of the PDF417, as well as traditional barcodes.

  • Page 12: Installation

    To disconnect the cable, insert a paper clip or other similar object into the slot on the reader battery cover while unplugging the cable from the Gryphon™ D body. Connections should always be made with power OFF! CAUTION...

  • Page 13: Om-Gryphon™ Interface Cable Connections

    Cable OM-GRYPHON™ Connectors The OM-GRYPHON™ incorporates a multi-standard interface which can be connected to a Host by simply plugging the correct interface cable into the connector, placed on the base of the cradle. In addition the cradle must be connected to an external power supply.

  • Page 14: Rs232 Connection

    GRYPHON™ RS232 CONNECTION (if required)

  • Page 15: Ibm Usb Pos

    INSTALLATION IBM USB POS WEDGE CONNECTION...

  • Page 16: Pen Emulation Connection

    GRYPHON™ PEN EMULATION CONNECTION...

  • Page 17: Gryphon™ M Battery Maintenance

    2.8.2 Battery Charging Once the system is connected and powered, you can place the Gryphon™ M into the cradle to charge the battery. When the scanner is correctly inserted in the cradle, the red LED on the cradle goes on to indicate that the battery is charging.
  • Page 18 GRYPHON™ Open the battery cover. Battery Cover Replace the old batteries with new ones, then screw the battery cover back into place. NiMh, NiCd, or Alkaline AA Batteries Do not incinerate, disassemble, short terminals or expose to high temperature. Risk of fire, explosion. Use specified charger only.

  • Page 19: Gryphon™ M System And Network Layouts

    GRYPHON™ M SYSTEM AND NETWORK LAYOUTS GRYPHON™ M SYSTEM AND NETWORK LAYOUTS There are two basic system layouts that can be employed: Stand Alone systems and Multidrop STAR-System™ Networks. STAND ALONE LAYOUTS 3.1.1 Single Reader Layout 3.1.2 Multiple Reader Layout...

  • Page 20: Multiple Stand Alone Layouts

    Multiple Stand Alone Systems in the Same Area Since the cradles can communicate to multiple Gryphon™ M scanners, you might nd it useful to employ one or more C-Gryphon™ battery chargers in addition to the OM- ryphon™ cradle, so that the ba ttery re-charging operation can be performed for several scanners at the same time.

  • Page 21: Multidrop Star-System™ Network Layouts

    Host. Gryphon™ M readers are compatible with TAR-System™ networks. These networks provide seamless active roaming for any RF reading device in the system.

  • Page 22: Configuration

    GRYPHON™ CONFIGURATION CONFIGURATION METHODS 4.1.1 Reading Configuration Barcodes This manual can be used for complete setup and configuration of your reader by llowing the setup procedures in this chapter (see par. 4.2 for an overview If you wish to change the default settings, this manual provides complete configuration of your reader in an easy way.

  • Page 23: Sending Configuration Strings From Host

    SETUP PROCEDURES or Gryphon™ D-Series readers, follow the setup procedures in pars. 4.3 and 4.6. For Gryphon™ D USB readers, follow the setup procedures in par. 4.7. or Gryphon™ M-Series readers, the setup procedures depend on two ba a pl ations, Stand Alone or STAR-System™.

  • Page 24: Gryphon™ D Setup

    Gryphon™ M reader. Enter configuration Ì$+;Î Set R adio Address ÌRA0RFHÎ four digits for the Gryphon™ M Address (from 0000 to 1999). All readers used in the same area must have different addresses. Exit and Save configuration Ì$-?Î...
  • Page 25 CONFIGURATION Read the Bind code to pair the Gryphon™ M to the OM-Gryphon™ cradle he reader is dedicated to t he cradle. Any previously bound reader w ill be excluded. To connect several readers to the same cradle see the following paragraph 4.4.1, ‘Using Multiple M Readers with Same Cradle'.

  • Page 26: Using Multiple M-Series Readers With Same Cradle

    Bind command w ith Join (step 5). Join Ì$+RN1$-NÎ he green LED on the Gryphon™ M will blink: the reader is ready to be positioned onto the cradle. Complete step 6. END of procedure. If the cradle is not Bound to a reader, its address assumes a random value which can cause conflicts and malfunctions to other cradles within its range.

  • Page 27: Gryphon™ M/Star-Modem™ In Stand Alone Mode

    CONFIGURATION 4.4.2 GRYPHON™ M/STAR-Modem™ in Stand Alone Mode To configure a Gryphon™ M reader to communicate with STAR-Modem™ in Stand Alone Mode, follow the procedure in par. 4.4 substituting steps 4 and 5 with t hose elow: AR-Modem™ Address ÌRSRÎ...

  • Page 28: Gryphon™ M/Star-System™ Setup

    GRYPHON™ GRYPHON™ M/STAR-SYSTEM™ SETUP The following procedure allows config uring a Gryphon™ M reader to communicate with va rious STAR-System™ devices such as STARGATE™ RF base stations. Restore Gry phon™ M Default Ì$+$*oÎ Enter configuration Ì$+;Î Set t he co...
  • Page 29 CONFIGURATION First STAR-System™ Address ÌRSRÎ Read the code above and the four-digit address of the First STAR-System™ device in the system. Set Last STAR-System™ Address ÌRTTÎ Read the code above and the four-digit address of the Last STAR-System™ device in the system. Whenever the system is composed of a single base station, the first and last base station addresses (steps 5 and 6) must have the same value.

  • Page 30: Interface Selection

    GRYPHON™ INTERFACE SELECTION Read the interface selection code for your application RS232 Standard Ì$+CP0$-$Î POS Terminals Nixdorf Mode A Ì$+CM2EC0$->Î Fujitsu Ì$+CM1$-ÈÎ ICL Mode Ì$+CM0$-ÃÎ For POS termina l default settings refer to par. 5.12. Ì$+CP6$-BÎ...
  • Page 31 CONFIGURATION WEDGE IBM AT or PS/2 PCs Ì$+CP500$-aÎ IBM XT Ì$+CP503$-vÎ PC Notebook Ì$+CP505$-ÈÎ IBM SURE1 Ì$+CP506$-$Î IBM Terminal 3153 Ì$+CP504$-}Î...
  • Page 32 GRYPHON™ WEDGE (CONTINUED) IBM Termina ls 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct KEY TRANSMISSION code. Select KEYBOARD TYPE necessary (default = advanced keyboard). KEY TRANSMISSION MODE make-only keyboard Ì$+CP502$-oÎ make-break keyboard Ì$+CP501$-hÎ...
  • Page 33 CONFIGURATION WEDGE (CONTINUED) ALT MODE he ALT-mode selection allows barcodes sent to the PC to be interpreted correctly independently from the Keyboar d Nationality used. You do not need to make a Keyboard Nationality sele ction. efault = Num Lock Unchanged). Make sure the Num Lock key on your eyboard is ON.
  • Page 34 GRYPHON™ WEDGE (CONTINUED) DIGITAL TERMINALS VT2xx/VT3xx/VT4xx Ì$+CP512$- uÎ APPLE ADB Bus Ì$+CP513$-|Î IBM 46XX (IBM 46xx models only) PORT 9B 4501 Protocol Ì$+CP800$-pÎ (typical) 1520 Protocol Ì$+CP801$-wÎ PORT 5B 1520 Protocol Ì$+CP801$-wÎ (typical)

  • Page 35: Usb Reader Configuration

    Load drivers from the O.S. (if requested). When configuring the USB-COM interface, the relevant files and drivers must be installed from the USB Device Installation software which can be downloaded from the web page http://www.datalogic.com. The reader is ready.
  • Page 36 GRYPHON™ First Start- onnect device to LED blinks st with USB cable Load drivers (if requested) Does a dialog box Discon nect reader appear asking LED off Host whether Bus power is sufficient? Connect external power supply to cable and power up...
  • Page 37 USB-KBD Ì$+UA03$-:Î USB-KBD-ALT-MODE Ì$+UA04$-@Î USB-KBD-APPLE Ì$+UA05$-FÎ USB-COM* Ì$+UA02$-4Î USB-IBM-Table Top Ì$+UA00$-(Î USB-IBM-Hand Held Ì$+UA01$-.Î When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software which can be downloaded from the web site http://www.datalogic.com.

  • Page 38: Changing Default Settings

    Gryphon™ series readers Gryphon™ M/OM-Gryphon™ Stand Alone configurations only: The USB group is for Gryphon™ D USB only. The IBM 46xx group is for IBM 46xx models only. The following par ter grou ps are common to all interfa...

  • Page 39: Rs232 Parameters

    RS232 PARAMETERS Gryphon™ D Series Readers Gryphon™ M/OM-Gry phon™ configurat ns only ARITY ANDSHAKING ROTOCOL NTER CHARACTER ELAY IMEOUT ERIAL RIGGER Read the Ent er Configuration code ONCE , available at the top of each page. Read configuratio n codes from the desired groups.

  • Page 40: Baud Rate

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 150 baud ÌCDOKÎ 300 baud ÌCD1XÎ 600 baud ÌCD2[Î 1200 baud ÌCD3^Î 2400 baud ÌCD4aÎ 4800 baud ÌCD5dÎ 9600 baud ÌCD6gÎ 19200 baud ÌCD7jÎ 38400 baud ÌCD8mÎ...

  • Page 41: Parity

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 ARITY none ÌCC0SÎ even parity ÌCC1VÎ odd parity ÌCC2YÎ 7 bits ÌCA0OÎ 8 bits ÌCA1RÎ 9 bits ÌCA2UÎ...

  • Page 42: Stop Bits

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 1 stop bit ÌCB0QÎ 2 stop bits ÌCB1TÎ ANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details.

  • Page 43: Ack/Nack Protocol

    ÌCF0YÎ enable (sw 3.1.0) ÌCF3bÎ disable (sw 4.0 and later ÌER0sÎ enable (sw 4.0 and later) ÌER1vÎ See par. 5.1.2 for details, particularly on implementing this parameter with Gryphon™ M. FIFO disable ÌEC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details.

  • Page 44: Inter-Character Delay

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 N TER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled timeout control in reception from Host ÌCL5Î...

  • Page 45: Serial Trigger Lock

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 ERIAL RIGGER disabled ÌCR0qÎ enable and select characters ÌCR1tÎ Read 2 characters from the Hex/Numeric table in the range 00-FE where: − First Character enables device trigger − Second Character inhibits device trigger until the first character is received again.

  • Page 46: Usb Parameters

    USB PARAMETERS USB-COM Handshaking, Ack/Nack protocol, FIFO, Inter-character delay, Rx timeout, Serial trigger lock USB-KBD Keyboard na tionality, FIFO, Inte r-character ay, Inter-code delay USB-IBM No parameter selection required. Read the Enter Configuration code ONCE , available at the top of each page. Read configuration codes from the desired groups.

  • Page 47: Handshaking

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM ANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details. ROTOCOL disable ÌER0 sÎ enable ÌER1vÎ See par. 5.1.2 for details.

  • Page 48: Fifo

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM FIFO disable Ì EC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details. CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 m illiseconds...

  • Page 49: Rx Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM IMEOUT timeout control in reception from Host ÌCL5Î Read 2 numbers from the table where: 00 = TIMEOUT disabled 01-99 = TIMEOUT from .1 to 9.9 seconds rx timeout 5 seconds See par.

  • Page 50: Keyboard Nationality

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD EYBOAR ONALITY Not Available for USB-KBD-ALT-MODE Interface his parameter default value is restored through the Interface Selection code and not Restore Default. Belgian ÌFJ7yÎ English ÌFJ4pÎ French ÌFJ2jÎ German ÌFJ3mÎ Italian ÌFJ1gÎ...

  • Page 51: Fifo

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD FIFO disable Ì EC0UÎ enable ÌEC1 XÎ See par. 5.1.3 for details. NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled...

  • Page 52: Inter-Code Delay

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD NTER CODE ELAY lay between code transmitted to Ho ÌFG.Î ead 2 numbers from the table wh ere: 00 = D ELAY disabled 01-99 = DELAY from 1 to 99 seconds elay disabled...

  • Page 53: Wedge Parameters

    WEDGE PARAMETERS ryphon™ D Series Readers Grypho n™ M/OM-Gryphon™ configurat ns only EYBOARD ATIONALITY RECOGNITION NTER CHARACTER ELAY NTER CODE ELAY EYBOARD ETTING ead the E nter Configuration code ONCE , available at the top of each page. Read configuration codes from the desired groups.

  • Page 54: Keyboard Nationality

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE EYBO ATION ALITY Belgian ÌFJ7yÎ English ÌFJ4pÎ French ÌFJ2jÎ Germa ÌFJ3mÎ Italian Ì FJ1gÎ Spanish ÌFJ6vÎ Swedish ÌFJ5sÎ ÌFJ0dÎ The Japanese Key board Nationality sele ction is valid only for IB M AT compatible PCs.

  • Page 55: Caps Lock

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE caps lock OFF ÌFE0ZÎ caps lock ON ÌFE1]Î Select the appropriate code to match your keyboard caps lock status. ote: Caps lock manual configuration is ignored when Caps Lock Auto-Recognition is enabled.

  • Page 56: Num Lock

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE toggle num lock Ì FL1kÎ num lock unchanged ÌFL0hÎ his selection is used together with the Alt Mode interface selection for AT or Notebook PCs. It changes the way the Alt Mode procedure is executed, therefore it should be set as follows: •...

  • Page 57: Inter-Code Delay

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE NTER CODE ELAY delay between codes transmitted to Host ÌFG.Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 seconds delay disabled...

  • Page 58: Keyboard Setting

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE EYBOARD ETTING LPHANUMERIC K EYBOARD SETTING he reader can be used with terminals or PCs with various k eyboard types and nationalities through a simple keyboard setting procedure. he type of computer or termin al mu st be selected before activatin...
  • Page 59 74 : DEL GRYPHON™ M-Series Readers Only When working with Gryphon™ M-Series readers, the keyboard setup functioning is signaled by the LEDs on the OM-Gryphon™ cradle. Each key stroke corresponds to a double blinking of the green LED. y pressing the Backspace key the red LED on the OM-Gryphon™...

  • Page 60: Pen Emulation

    PEN EMULATION Gryphon™ D Series Readers Gryphon™ M/ OM-Gryphon™ config urations only PERATING INIMU UTPUT ONVERSION TO VERFLOW UTPUT EVEL EVEL NTER LOCK ELAY Read the Enter Configuration code ONCE , available at the top of each page. Read configuration codes from the desired groups.

  • Page 61: Operating Mode

    PEN EMULATION The operating mode paramet ers are complete commands and do not require reading the Enter and E it configuration codes. PERATING interpret mode Ì$]8Î Interprets commands without sending them to the deco der. transparent mode Ì$[4Î Sends commands to the decoder without interpreting them.

  • Page 62: Minimum Output Pulse

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION INIMUM UTPUT ULSE high resolution code emulation 200 µs ÌDG0\Î 400 µs ÌDG1_Î 600 µs ÌDG2bÎ 800 µs ÌDG3eÎ 1 ms ÌDG4hÎ 1.2 ms ÌDG5kÎ low resolution code emulation See par. 5.2.1 for details.

  • Page 63: Conversion To Code 39 And Code 128

    Converts codes read into Code 39 format. enable conversion to Code 128 ÌDA2VÎ Converts codes read into Code 128 format. ► = default value for Gryphon™ D Series Readers = default value for Gryphon™ M Series Readers See par. 5.2.2 for details.

  • Page 64: Overflow

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION VERFLOW narrow ÌDH0^Î medium ÌDH1aÎ wide ÌDH2dÎ See par. 5.2.3 for details. UTPUT EVEL normal (white = logic level 0) ÌDD0VÎ inverted (white = logic level 1) ÌDD1YÎ See par. 5.2.4 for details.

  • Page 65: Idle Level

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION EVEL normal (black level) ÌDE0XÎ inverted (white level) ÌDE1[Î See par. 5.2.4 for details. NTER LOCK ELAY delay between character blocks transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from .1 to 9.9 seconds delay disabled...

  • Page 66: Ibm 46Xx

    IBM 46XX IBM 46xx Models On IBM D ORMATTING Read the Enter Configuration code ONCE , available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 67: Ibm Data Formatting

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î IBM 46xx IBM D ORMATTING conversion to Code 39 ÌGD0YÎ IBM Standard ÌGD1\Î mixed IBM Standard + Code 39 ÌGD2_Î See par. 5.3.1 for details.

  • Page 68: Data Format

    DATA FORMAT NOT FOR PEN INTERFACES NTIFIER USTOM DENTIFIER ERMINATOR IELD STMENT IELD HARACTER HARACT EPLACEMENT DDRE TAMPING DDRE ELIMITER Read th Enter Configuration code ONCE , available a he top of each page. d configuration codes from the desired groups. = Read the code and follow the procedure given = Default value...
  • Page 69 DATA FORMAT CODE IDENTIFIER TABLE CODE AIM STANDARD DATALOGIC STANDARD Custom 2/5 interleaved ] I y 2/5 industrial ] X y 2/5 normal 5 bars ] S y matrix 3 bars ] X y EAN 8 ] E 4 EAN 13...
  • Page 70 The y value depends on the selected options (check digit tested or not, check digit tx or not, etc.). • When customizing the Datalogic Standard code identifiers, 1 or 2 identifier characters can be defined for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).

  • Page 71: Code Identifier

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT DENTIFIER disable Ì EB0SÎ Datalogic standard ÌEB1VÎ AIM standard ÌEB2YÎ custom ÌEB3\Î...

  • Page 72: Custom Code Identifier

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT USTOM NTIFIER define custom code identifier( ) ÌEH/Î the above code. (Cod Identifiers default to Da al ogic standard, see table on previous page). Select the code type from the code table in Appendix for th e identifier you want to change.

  • Page 73: Header

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT EADER no header ÌEA00*Î one character header ÌEA01.Î two character header ÌEA022Î three character header ÌEA036Î four character header ÌEA04:Î five character header ÌEA05>Î six character header ÌEA06BÎ seven character header ÌEA07FÎ...

  • Page 74: Terminator

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT ERMINATOR no terminator ÌEA10-Î one character terminator ÌEA111Î two character terminator ÌEA125 Î ee character terminator ÌEA139Î four character terminator ÌEA14 =Î five character terminator ÌEA15AÎ six character terminator ÌEA16EÎ seven character terminator ÌEA17IÎ...

  • Page 75: Field Adjustment

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT IELD DJUSTMENT disable field adjustment ÌEF 0[Î Field adjustment allow s a numbe r of characters n, to be added to or subtracted from the barcode read. The adjustment can be di fferent for each en abled code type.

  • Page 76: Field Adjustment Character

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT I ELD DJUSTMENT HARACTER Read the field adjustment c haracter code: field adjustment character ÌEG-Î Read the hexadecimal value corresponding to the character you w ant to use for field adjustment.

  • Page 77: Character Replacement

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT HARACTER EPLACEMENT disable character replacement ÌEO0mÎ his parameter allows up to three characters to be replaced from the barcode read. These ubstitutions are stored in memory. To define each character replacement: Read one of the follow ng cha racter replacement codes:...
  • Page 78 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT Example: The following strings define: First Character Replacement: su bstitution in Code 39 ba rcodes of all occurrences of the 0 character with the 1 character. Second Character Replacement: substitution in Code 39 barcodes of all occurrences of the A character with the B character.

  • Page 79: Address Stamping (M Series Only)

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT (M S DDRESS TAMPING ERIES disable reader address stamping ÌRU0ÊÎ enable reader address tamping ÌRU1"Î See par. 5.4.3 for details. (M S DDRESS ELIMITER ERIES disable reader address delimiter ÌRV0!Î enable reader address delimiter and select characters ÌRV1$Î...

  • Page 80: Power Save

    POWER SAVE /USB S LEEP TATE USPEND NTER LEEP IMEOUT TANDBY Read the Enter Configuration code ONCE , available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow t he procedure given = Default value Read the Exit and Save Configuration code ONCE...

  • Page 81: Scan Rate

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î POWER SAVE 67 scans per sec. Ì BT0tÎ 135 scans per sec. ÌBT1wÎ 270 scans per sec. ÌBT2zÎ A lower scan rate reduces power con sumption but c an lengthen reading response time. /USB S LEEP TATE...

  • Page 82: Enter Sleep Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î POWER SAVE NTER LEEP IMEOUT enter sleep timeout ÌBR@Î Read 2 numbers in the range 00-99: 00 = Enter Sleep state immediately 01-99 = corresponds a max. 9.9 sec. delay before entering the Sleep state.

  • Page 83: Reading Parameters

    READING PARAMETERS PERATING PERATION TAND ERATION ARDWARE RIGGER RIGGER IMEOUT LASH EADS PER YCLE AFETY EEPER NTENSITY EEPER EEPER EEPER ENGTH PDF D ECODING ECOGNITION NTENSITY URATION Read the Enter C onfiguration code ONCE , available at the top of each page. Read configuration codes from the desired groups.

  • Page 84: Operating Mode

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS PERATING You can pre-configure both Hand-Held and Stand operating modes, and with the codes below, you c an switch between t hem. See par. 5.6.1 f or details. Stand operation is not advised for M- Series readers since it constantly consumes battery power.

  • Page 85: Stand Operation

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS PERATIO hardware trigger ÌBU3ÃÎ software trigger ÌBU1yÎ * always on ÌBU2|Î * not available for M-Series readers automatic ÌBU0vÎ ARDWARE RIGGER trigger active level ÌBA0NÎ trigger active pulse ÌBA1QÎ See par. 5.6.2 for details RIGGER IMEOUT trigger-off timeout...

  • Page 86: Flash Mode

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS LASH "FLASH" ON duration Ì BB0PÎ "FLASH" OFF duration ÌBB1SÎ Read 2 numbers in the range 01-99: 01 to 99 = from .1 to 9.9 seconds. Flash-ON = 1 sec. Flash-OFF = 0.6 sec EADS PER YCLE one read per cycle...

  • Page 87: Safety Time

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS AFETY safety time ÌBE&Î Limits same code consecutive reading. Read 2 numbers in the range 00-99: 00 = no same code consecutive reading until reader is removed (no decoding) for at least 400 ms. 01-99 = timeout from .1 to 9.9 seconds before a consecutive read on same code.

  • Page 88: Beeper Tone

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS EEPER tone 1 ÌBH0\Î tone ÌBH1_Î tone 3 ÌBH2bÎ tone 4 ÌBH3eÎ EEPER monotone ÌBJ0`Î bitonal ÌBJ1cÎ EEPER ENGTH long ÌBI0^Î short ÌBI1aÎ...

  • Page 89: Pdf Decoding Recognition Intensity

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS PDF D ECODING ECOGNITION NTENSITY ÌBW0zÎ high ÌBW1}Î URATION disable ÌBV0xÎ short ÌBV1{Î medium ÌBV2~Î long ÌBV3ÅÎ...

  • Page 90: Decoding Parameters

    DECODING PARAMETERS PREAD VERFLOW ONTROL NTERDIGIT ONTROL ECODING AFETY ™ Before changing these parameter value s read the descriptions in par. 5.7. CAUTION Read the Enter Configura tion code ONCE, available at the top of each page. Read configuration codes from the desired groups.

  • Page 91: Ink Spread

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS PREAD disable ÌAX0{Î enable ÌAX1~Î See par. 5.7.1 for details. VERFLOW ONTROL disable ÌAW1|Î enable ÌAW0yÎ See par. 5.7.2 for details.

  • Page 92: Interdigit Control

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS NTERDIGIT ONTROL disable ÌAV0wÎ enable ÌAV1zÎ See par. 5.7.3 for details. ECODING AFETY one read ÌED0WÎ (decoding safety disabled) two reads ÌED1ZÎ three reads ÌED2]Î four reads ÌED3`Î Required number of good reads before accepting code.

  • Page 93: Puzzle Solver

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS ™ UZZLE OLVER disable ÌAU0uÎ enable ÌAU1xÎ In the case of damaged or poorly printed codes, this pa rameter allows reading multiple parts of the single code to reconstruct it. To read codes using this technology, si mply move the illuminated bar o...

  • Page 94: Code Selection

    CODE SELECTION N/UPC F AMILY 2/5 F AMILY 39 F AMILY 128 F AMILY ODABAR AMILY LESSEY ELEPEN ELTA PDF417 PDF R EADERS RSS C ODES Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE , available at the top of...
  • Page 95 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION DISABLE ALL CODE FAMILIES ÌAZ0ÃÎ The reader allow s up to 5 code selections. This does not limit the number of CODES enabled to 5, as it depends on the code family. NOTE SINGLE SELECTIONS...

  • Page 96: Ean/Upc Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UPC F AMILY disable the family ÌAA0MÎ Read the desired family code Note: Since the EA N/UPC without ADD ON code sele ion is enabled by default, to correctly enable another selection, first disable the family.
  • Page 97 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION WITH ADD ON 2 AND 5 N 8/EAN 13/UPC A/UPC E ÌAA5\Î EAN 8/EAN 13 ÌAA6_Î UP C A/UPC E ÌAA7bÎ WITH ADD ON 2 ONLY EAN 8/EAN 13 ÌAAK7Î UPC A/UPC E ÌAAM=Î...
  • Page 98 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UP C CHECK DIGIT TX SELEC TIONS For each code type in this family you can choose to transmit the check digit or not CHECK DIGIT TRANSMISSION NO CHECK DIGIT TRANSMISSION EAN 8 ÌAAG1oÎ...
  • Page 99 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION CONVERSION OPTIONS UPC E to UPC A conversion ÌAAAÄÎ UPC E to EAN 13 conversion ÌAABÇÎ UPC A to EAN 13 conversion ÌAACÊÎ EAN 8 to EAN 13 conversion ÌAAD"Î Enable only ISBN con version ÌAP1nÎ...

  • Page 100: 2/5 Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 2/5 F AMILY disable the family ÌAC0QÎ Read the desired family code Read a check digit selection Interleaved 2/5 ÌAC1TÎ CHECK DIGIT TABLE o check digit control Ì12Î ormal 2/5 (5 Bars) ÌAC2WÎ...

  • Page 101: Code 39 Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 39 F AMILY disables the family ÌAB0OÎ Read the desired family code Read a check digit selection HECK DIGIT TABLE Standard Code 39 no check digit control ÌAB1RÎ Ì12Î check digit control Full ASCII Code 39 and transmission ÌAB2UÎ...
  • Page 102 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION The pharmaceutical codes below are part of the Code 39 family but have no check digit selections. Code CIP39 ÌAB3XÎ French pharmaceutical co Code 32 ÌAB4[Î Italian pharmaceutical code DE LENGTH (optional) The code length selection is valid for the entire Code 39 family set code length Read the code +...

  • Page 103: Code 128 Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 128 F MILY disables the family ÌAI0]Î Read the desired family code Code 128 ÌAI11=Î control wi thout transmission check digit EAN 128 ÌAI21@Î control without transmission of check digit Transmit GS Before Code Code EAN 128 uses the ASCII <GS>...
  • Page 104 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION ISBT 128 ÌAI31CÎ Enabling ISBT 128 automatically disables Puzzle Solver™. CODE LENGTH (optional) T e code length selection is valid for the entire C e 128 fami set code length ead the code + 4 numbers for the code length where: ÌAILJÎ...

  • Page 105: Codabar Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION ODABAR AMILY disable the family ÌAD0SÎ Read the desired equality co ntrol code Read a start/stop transmission ection START/STOP CHA RACTER TRANS ISSION Standard Codabar ÌAD113Î no start/stop character equality contro no transmiss Ì12Î...
  • Page 106 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION Codabar ABC Forced Concatenation enable Codabar ABC with forced concatenation ÌAD2321Î non start/stop char acter equality control b ut transmission CODE LENGTH (optional) The code length selection is valid for the entire Codabar family set code length Read the code + 4 numbers for the code length where:...

  • Page 107: Msi

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the family ÌAE0UÎ Enable the code by selecting one of the check digit selections. no check digit control ÌAE1XÎ MOD10 check digit control no check digit transmission Ì AE2[Î MOD10 check digit control check digit transmission ÌAE3^Î...

  • Page 108: Plessey

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION LESSEY disable the family ÌAF0WÎ Enable the code by selecting one of the check digit selections. Standard Plessey no check digit control ÌAF117Î check digit control check digit transmitted ÌAF12;Î check digit control check digit not transmitted ÌAF13?Î...

  • Page 109: Telepen

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION ELEPEN disable the family ÌAL0cÎ Enable the code by selecting one of the check digit selections. Numeric Telepen no check digit control ÌAL11CÎ check digit control check digit transmitted ÌAL12GÎ check digit control check digit not transmitted ÌAL13KÎ...

  • Page 110: Delta Ibm

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION ELTA disable the family ÌAH0[Î Enable the code by selecting one of the check digit selections. no check digit control ÌAH1^Î pe 1 check digit control ÌAH2aÎ Type 2 check digit control ÌAH3dÎ...

  • Page 111: Code 11

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the family ÌAG0YÎ nable the code by selecting one of the check digit selections. no check digit control ÌAG1\Î Type C check digit control check digit transmitted ÌAG21<Î Type C check digit control check digit not transmitted ÌAG22@Î...

  • Page 112: Code 16K

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the code ÌAJ0_Î Code 16K ÌAJ1bÎ To read stacked codes, simply move the reader over the cod e so that each line of the code is anned. During this process a series of brief “ticks” indicates that reading is proceeding rrectly.

  • Page 113: Pdf417

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION PDF417 Only PDF417 readers disable the code ÌAR0oÎ PDF417 ÌAR1 rÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned.

  • Page 114: Rss Codes

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION RSS C ODES disable the family ÌAQ0mÎ DISABLE CODE ENABLE CODE disable RSS Exp ande d Linear and Stacked ÌA Î enable RSS Expanded Linear and Stacked ÌAQ11MÎ disable RSS Limited ÌAQ20LÎ...

  • Page 115: Advanced Formatting

    ADVANCED FORMATTING NOT FOR PEN INTERFACES ONCATENATION NCED ORMATTI Please follow the setup procedure carefully for these parameters. NOTE The Advanced Forma tting parameters may not be compatible w th IBM USB POS/IBM 46xx interface selection. NOTE Read the Enter Configurat ion code ONCE, available at the top of page .

  • Page 116: Concatenation

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING ONCATENATION disable ÌEI0aÎ enable ÌEI1dÎ Permits concatenation of two codes defined by code type and length. It is possible to set a eout r the second code reading and to define code transmission if the timeout expires. e order of transmission is CODE 1-CODE 2.
  • Page 117 Since you can concatenate codes from different families, you must select the Code ID character of the resulting code. The Code ID character will be sent in the output message only if it is enabled according to the Code Identifier selection (Datalogic, AIM, or Custom). Concatenation Timeout timeout ÌEJ3Î...
  • Page 118 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Transmission after Timeout no code transmitted after timeout ÌEM0iÎ only code 1 transmitted (if read) after timeout ÌEM1lÎ only code 2 transmitted (if read) after timeout ÌEM2oÎ either code 1 or code 2 transmitted after timeout ÌEM3rÎ...

  • Page 119: Advanced Formatting

    ADVANCED FORMATTING DVANCED ORMATTING Advanced formatting has been designed to offer you complete flexibility in changing the format of barcode data before transmitting it to the host system. This formatting will be performed when the barcode data meets certain criteria which you will define in the following procedure. Up to 4 advanced code management formats can be defined and saved in memory.
  • Page 120 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING Begin Format Definition begin Format 1 definition ÌHA0TÎ begin Format 2 definition ÌHA1WÎ begin Format 3 definition ÌHA2ZÎ begin Format 4 definition ÌHA3]Î Match Code Type match code type ÌHB&Î Read the above code + the code type to match from the Code Identifier Table in Appendix B.
  • Page 121 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Match with Predefined Characters no match ÌHD0HE00ÄÎ match with 1 character ÌHD1]Î match with a 2-character string ÌHD2`Î match with a 3-character string ÌHD3cÎ match with a 4-character string ÌHD4fÎ After selecting the predefined match code, read the character(s) from the HEX table. Range of characters = 01-FE.
  • Page 122 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Divide Code into Fields divide code into fields ÌHF.Î Read one number in the range 1 to 5 to divide the code into fields. Define Code Fields define code fields Each code field length can be set by either: a) defining a field separator character to be found in the code itself.
  • Page 123 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 1 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î field length ÌHG1cÎ Read two numbers in the range 01 to 99 to define the field length. this is the last field (variable length) ÌHG2fÎ...
  • Page 124 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 2 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î field length ÌHG1cÎ Read two numbers in the range 01 to 99 to define the field length. this is the last field (variable length) ÌHG2fÎ...
  • Page 125 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 3 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î field length ÌHG1cÎ Read two numbers in the range 01 to 99 to define the field length. this is the last field (variable length) ÌHG2fÎ...
  • Page 126 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 4 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î field length ÌHG1cÎ Read two numbers in the range 01 to 99 to define the field length. this is the last field (variable length) ÌHG2fÎ...
  • Page 127 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 5 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î field length ÌHG1cÎ Read two numbers in the range 01 to 99 to define the field length. this is the last field (variable length) ÌHG2fÎ...
  • Page 128 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING First Additional Fixed Field no fixed field ÌHI0dÎ 1 character fixed field ÌHI1gÎ 2 character fixed field ÌHI2jÎ 3 character fixed field ÌHI3mÎ 4 character fixed field ÌHI4pÎ 5 character fixed field ÌHI5sÎ 6 character fixed field ÌHI6vÎ...
  • Page 129 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Second Additional Fixed Field no fixed field ÌHJ0fÎ 1 character fixed field ÌHJ1iÎ 2 character fixed field ÌHJ2lÎ 3 character fixed field ÌHJ3oÎ 4 character fixed field ÌHJ4rÎ 5 character fixed field ÌHJ5uÎ 6 character fixed field ÌHJ6xÎ...
  • Page 130 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Field Transmission number of fields to transmit ÌHK8Î Read one number in the range 1 to 7 for the number of fields to transmit. Include only fields to be transmitted. Field Order Transmission Read the codes corresponding to the fields to transmit in the order in which they are to be transmitted.
  • Page 131 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Standard Formatting do not apply standard formatting ÌHL0jÎ apply standard formatting ÌHL1mÎ After performing Advanced Formatting on the barcode read, Standard Formatting (Headers, Code Length, Code ID, Terminators) can be applied to the message to be transmitted. End Format Definition end Format 1 definition ÌHM0lÎ...
  • Page 132 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING ble Advanced Form no Advanced Formats enabled ÌHN0nÎ Advanced Format 1 enable ÌHN11NÎ disable ÌHN10JÎ Advanced Format 2 enable ÌHN21QÎ disable ÌHN20MÎ Advanced Format 3 enable ÌHN31TÎ disable ÌHN30PÎ Advanced Format 4 enable ÌHN41WÎ...
  • Page 133 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING No Match Result clear data - no transmission ÌHO0pÎ transmit data using standard format ÌHO1sÎ This selection determines the action to be taken when codes read do not conform to the advanced format requisites (no match).

  • Page 134: Radio Parameters

    RADIO PARAMETERS Gryphon™ M Series Readers only ADIO ROTOCOL IMEOUT OWER IMEOUT EEPER ONTROL FOR ADIO ESPONSE ATTERY INGLE TORE Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups.

  • Page 135: Radio Protocol Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS ADIO ROTOCOL IMEOUT radio protocol timeout ÌRH<Î Read a number from the table where: 02-19 = timeout from 2 to 19 seconds 2 seconds See par. 5.8.1 for details. OWER IMEOUT power-off timeout ÌRPLÎ...

  • Page 136: Beeper Control For Radio Response

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS EEPER ONTROL FOR ADIO ESPONSE normal ÌBF0XÎ only good decode ÌBF1[Î only good reception ÌBF2^Î ÌBF3aÎ See par. 5.8.3 for details. ATTERY OM-GRYPHON™ CRADLE ONLY NiMh/NiCD ÌRB1cÎ alkaline ÌRB0`Î...

  • Page 137: Single Store

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS INGLE TORE disable ÌRO0zÎ one attempt ÌRO1}Î two attempts ÌRO2ÄÎ three attempts ÌRO3ÇÎ four attempts ÌRO4ÊÎ five attempts ÌRO5"Î six attempts ÌRO6%Î seven attempts ÌRO7(Î eight attempts ÌRO8+Î nine attempts ÌRO9.Î...

  • Page 138: References

    GRYPHON™ REFERENCES RS232 PARAMETERS 5.1.1 Handshaking Hardware handshaking: (RTS/CTS) The RTS line is activated by the decoder before transmitting a character. Transmission is possible only if the CTS line (controlled by the Host) is active. Signals at EIA levels Transmitted data...

  • Page 139: Ack/Nack Protocol

    REFERENCES 5.1.2 ACK/NACK Protocol GRYPHON™ D Series Readers This parameter sets a transmission protocol in which the Host responds to the reader after every code transmitted. The Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception.

  • Page 140: Fifo

    If the FIFO buffering is disabled, each code must be transmitted before another one can be read. GRYPHON™ M Series Readers If enabled, the OM-Gryphon™ collects all messages sent by Gryphon™ M and sends them in order of acquisition to the connected Host. disabled, Gryphon™...

  • Page 141: Rx Timeout

    5.2.2 Conversion to Code 39 and Code 128 GRYPHON™ D Series Readers When using these readers it is possible to convert all codes to Code 39. By disabling this option the decoded codes will be transmitted in their original format; except for the following codes which are ALWAYS converted into Code 39 format: MSI, Plessey, Telepen, Delta IBM, Code 11, Code 16K, Code 49, PDF417, RSS.

  • Page 142: Overflow

    GRYPHON™ 5.2.3 Overflow This parameter generates a white space before the first bar and after the last bar of the code. The selections are as follows: narrow = space 10 times the minimum output pulse. medium = space 20 times the minimum output pulse.

  • Page 143: Inter-Block Delay

    The transmission format of codes belonging to this set is specified by the protocol. As the reader allows a wider set of codes to be selected, the following formats are defined to offer the user all the reading possibilities of the Datalogic products. Conversion to Code 39 Format Data from any code selected may be transmitted.

  • Page 144: Data Format

    GRYPHON™ DATA FORMAT The system always provides gun to host data communication using the following message formatting: Output Message from Gryphon™ D or Gryphon™ M Stand Alone Towards Host CODE [Header] [Gun_Addr] [Gun_Addr_delimiter] ] [Code ID] [Code Length] [Terminator] [Items in square brackets are optional.] Output Message from Gryphon™...
  • Page 145 REFERENCES For the WEDGE interface, the following extended keyboard values can also be configured: EXTENDED KEYBOARD TO HEX CONVERSION TABLE IBM AT IBM XT IBM 31xx, 32xx, Wyse IBM 3153 34xx, 37xx Digital APPLE ADB ENTER ENTER FIELD EXIT RETURN BACKSPACE HOME HOME...

  • Page 146: Set Custom Extended Header/Terminator Keys

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î 5.4.2 Set Custom Extended Header/Terminator Keys The extended Header/Terminator keys for Wedge Interface users can be customized by defining them through a simple keyboard setting procedure. For example, the Numeric Keypad keys can be set for use as Headers or Terminators by substituting the default extended keys using this procedure.
  • Page 147 Readers Only When working with Gryphon™ M-Series readers, the keyboard setup functioning is signaled by the LEDs on the OM-Gryphon™ cradle. Each key stroke corresponds to a double blinking of the green LED. By pressing the Backspace key the red LED on the OM-GRYPHON™ cradle blinks, while the green LED stays on.

  • Page 148: Address Stamping

    GRYPHON™ 5.4.3 Address Stamping It is possible to include the reader address in the message sent to the host. The reader Address Stamping parameter consists of a 4-digit number in the range 0000-1999. For message output format, refer to par. 5.4.

  • Page 149: Enter Sleep Timeout

    REFERENCES 5.5.2 Enter Sleep Timeout For readers that have the Sleep state enabled, this timeout determines when the reader will enter this state. 5.5.3 Standby If this command is enabled, part of the CCD circuitry shuts down (Standby), in order to optimize low power consumption when not reading.

  • Page 150: Hardware Trigger Mode

    GRYPHON™ 5.6.2 Hardware Trigger Mode This mode determines how the reading phase is controlled when the hardware trigger operating mode is selected: • trigger active level: the reader goes ON when the trigger is pressed and goes OFF when it is released;...

  • Page 151: Safety Time

    REFERENCES 5.6.5 Safety Time Safety time prevents the device from immediately decoding the same code more than nce. Same code consecutive reading can be disabled requiring the reader to be removed from the code (no decoding) for at least 400 ms, or a timeout can be set up to 9.9 seconds before the decoder will accept the same code.

  • Page 152: Radio Parameters (M Series Only)

    5.8.2 Power-Off Timeout If this command is enabled, after the desired timeout in hours, the Gryphon™ batteries are disconnected and all power consumption ceases. To restore power, press the trigger once. The reader will now be ready to read codes.

  • Page 153: Single Store

    REFERENCES 5.8.4 Single Store When single store mode is enabled, if the Gryphon™ M fails to transmit a code to the cradle, it enters a special operating mode that prevents the user from reading arcodes. When such operating mode is entered, the trigger no longer enables barcode reading but is used to retry transmission itself for the number of attempts selected in configuration.

  • Page 154: Configuration Editing Commands

    GRYPHON™ CONFIGURATION EDITING COMMANDS The following commands carry out their specific function and then exit the configuration environment. Command Description Restore Gryphon™ reader default configuration Ì$+$*oÎ (see the relative Quick Reference Manual for default settings) Transmit Gryphon™ Ì$+$!KÎ Gryphon™ M Software release Transmit Gryphon™...

  • Page 155: 5.10 Configuration Copying Commands

    Connect the master (correctly configured reader) and the slave (reader to be configured) together through two RS232 serial interface cables and external power supply. Accessory cables and power supply are available from your Datalogic distributor to provide this connection. RS232 Cables: CAB363 & CAB364 or CAB320 & CAB328 Power Supply: PG5...

  • Page 156: Copy Gryphon™ M-Series

    The configuration will be copied from the master to the slave Gryphon™ M. The slave Gryphon™ M signals the end of the procedure with a series of beeps. It is now ready to be used with its own OM-Gryphon™ cradle.

  • Page 157: Copy Om-Gryphon

    Ì$+ZZ3$-9Î The configuration will be copied from the master OM-Gryphon™ to the slave OM-Gryphon™. The reader signals the end of the procedure with a series of beeps. Repeat the procedure above to configure other slave cradles. Note: The master OM-Gryphon™ can be configured for any interface.

  • Page 158: 5.11 C-Gryphon™ Configuration

    C-Gryphon™ either for serial configuration, software upgrades or to hold Gryphon™ M. Since this type of battery must not be charged it is necessary to disable the C-Gryphon™ charge function by following the procedure: With the Gryphon™...

  • Page 159: 5.12 Default Parameters For Pos Terminals

    REFERENCES 5.12 DEFAULT PARAMETERS FOR POS TERMINALS The default values of the RS232 and Data Format parameters for POS terminals are listed in the following table: NIXDORF Mode A FUJITSU ICL Mode RS232 Group Baud Rate 9600 9600 9600 Parity None Even Data Bits...

  • Page 160: Technical Features

    GRYPHON™ TECHNICAL FEATURES GRYPHON™ D Electrical Features Supply Voltage 5 Vdc ± 5% Consumption Maximum 330 mA 250 mA Operating <500 µA Sleep Mode/USB Suspend Optical Features Sensor CCD solid state (3648 pixels) Scan Rate (max) 270 scans/sec Reading field see reading diagram (par.

  • Page 161: Gryphon™ M

    TECHNICAL FEATURES GRYPHON™ M Electrical Features Battery Type 2 AA NiMh* batteries 1.2 V – 1400 mAh Time of recharge NiMh From 3 to 5 hours Operating autonomy 25,000 reads - NiMh (typ. continuous reading) Indicators LED, Good Read Spot, Beeper...

  • Page 162: Om-Gryphon™ / C-Gryphon

    208 x 107 x 55.5 mm / 8.1 x 4.2 x 2.18 in Material * Having a switching regulator inside, the OM-Gryphon™ and C-Gryphon™ draw the same power, regardless of the supply voltage. i.e. as the input voltage increases the current drawn decreases.

  • Page 163: System And Radio Features

    STATUS INDICATORS The reader has three indicators, LED, Beeper and Good Read Spot. The OM-Gryphon™ and C-Gryphon™ cradles have three indicator LEDs. They signal several operating conditions which are described in the tables below. H = high tone L = low tone GRYPHON™...
  • Page 164 ² The data entry good read tone is user-configurable with all the Beeper commands in the Reading Parameters section. For M-Series readers, normally this results in two beeps; the first indicates that the reader has decoded the code, the second indicates whether OM-Gryphon™ has received the data. See also par. 5.8.3.

  • Page 165: Reading Diagrams

    TECHNICAL FEATURES OM-GRYPHON™/C-GRYPHON™ CHARGE STATUS Red LED Green LED Meaning Charging End of charge No battery inserted Flashing Discharging (see par. 2.8.2) Flashing Flashing Shorted or open battery OM-GRYPHON™/C-GRYPHON™ POWER/COMMUNICATION Yellow LED Meaning Power applied Error in reading EEPROM parameters...
  • Page 166 GRYPHON™ GRYPHON™ D/M200 Reading Zones (10° skew angle) 0.13 mm (5 mils) CODE39 CODE39 EAN13 M=1 CODE39 0.076 mm 0.13 mm 0.33 mm 0.50 mm (3 mils) (5 mils) (13 mils) (20 mils) Reading Zones (10° skew angle) PDF417 Aspect Ratio 3:1 0.17 mm...

  • Page 167: Ahost Configuration Strings

    HOST CONFIGURATION STRINGS A HOST CONFIGURATION STRINGS In this section we provide a description of how to modify the device configuration using serial strings sent from the Host. This method requires the RS232 interface. The device configuration can be changed by receiving commands from the Host through the serial interface.
  • Page 168 GRYPHON™ SERIAL CONFIGURATION STRINGS ENTER/EXIT CONFIGURATION COMMANDS DESCRIPTION STRING Enter Configuration Exit and Save Configuration Restore Default Transmit Software Release (not for PEN emulation) Transmit Device Configuration in ASCII (not for PEN emulation) $& These commands do not require $-.
  • Page 169 HOST CONFIGURATION STRINGS RS232 DESCRIPTION STRING Baud rate 1200 2400 4800 9600 19200 38400 Parity none even Data bits Stop bits Handshaking disable RTS/CTS XON/XOFF RTS always On ACK/NACK Protocol disable (sw 3.1.0) enable (sw 3.1.0) disable (sw 4.0 and later) enable (sw 4.0 and later) FIFO disable...
  • Page 170 GRYPHON™ DESCRIPTION STRING USB-COM Handshaking disable RTS/CTS XON/XOFF RTS always ON ACK/NACK Protocol disable enable FIFO disable enable Inter-character delay (ms) CK00 - CK99 RX Timeout (100 ms) CL00 - CL99 Serial Trigger Lock disable enable CR1 ab USB-KBD Keyboard nationality...
  • Page 171 HOST CONFIGURATION STRINGS WEDGE (continued) DESCRIPTION STRING Caps Lock caps Lock ON caps Lock OFF Caps Lock Auto-Recognition disable (IBM AT compatible only) enable Num Lock Toggle Num Lock Num Lock Unchanged Delays Inter-Character (ms) CK00 - CK99 Inter-Code (s) FG00 - FG99 DESCRIPTION STRING...
  • Page 172 , c , x = HEX values representing an ASCII character. a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 59. b = Hex value of the first Custom Code Identifier character from 00 to FD;...
  • Page 173 = a number from the Hex/Numeric Table e, f, g, h = HEX values representing an ASCII character a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 59. d = a number in the range 01-32 from the Hex/Numeric Table...
  • Page 174 GRYPHON™ READING PARAMETERS DESCRIPTION STRING Operating Mode hand-held operation stand operation automatic Hand-Held Operation software trigger hardware trigger automatic always on hardware trigger ready Stand Operation software trigger hardware trigger automatic always on Hardware Trigger Mode trigger active level trigger active pulse...
  • Page 175 HOST CONFIGURATION STRINGS DECODING PARAMETERS DESCRIPTION STRING Ink-spread disable enable Overflow control disable enable Interdigit control disable enable Puzzle Solver disable enable Decoding Safety one read two reads three reads four reads CODE SELECTION DESCRIPTION STRING DISABLE ALL FAMILY CODES EAN/UPC disable EAN/UPC family EAN 8/EAN 13/UPC A/UPC E without ADD ON...
  • Page 176 GRYPHON™ CODE SELECTION (continued) DESCRIPTION STRING ISBN Conversion codes enable ISBN enable ISSN enable ISBN and ISSN disable ISBN and ISSN Code 39 disable Code 39 family Standard no check digit control AB11 check digit control and transmission AB12 check...
  • Page 177 HOST CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION STRING Codabar disable Codabar family Standard no start/stop character equality control AD111 nor transmission no start/stop character equality control AD112 but transmission start/stop character equality control AD121 but no transmission start/stop character equality control AD122 and transmission ABC Codabar...
  • Page 178 GRYPHON™ CODE SELECTION (continued) DESCRIPTION STRING Plessey disable the family Standard no chec Standard check - with tx Standard check - no tx Anker no check AF21 Anker check - with Anker check - no Telepen disable the family Numeric no check...
  • Page 179 HOST CONFIGURATION STRINGS RADIO PARAMETERS DE CRIPTION STRING Radio Protocol Timeout enable (seconds) RH02-RH19 Power-Off Tim eout RP00-RP99 Beeper Control For Radio Response normal only good decode only good reception Battery Type alkaline NiMh Single Store disable one attempt two attempts three attempts four attempts five attempts...

  • Page 180: Bcode Identifier Table

    GRYPHON™ B CODE IDENTIFIER TABLE 2/5 Interleaved ÌNOÎ 2/5 Industrial ÌPQÎ 2/5 normal 5 bars ÌOPÎ 2/5 matrix 3 bars ÌQRÎ EAN 8 ÌABÎ EAN 13 ÌBCÎ UPC A ÌCDÎ UPC E ÌDEÎ EAN 8 with 2 ADD ON ÌJKÎ...
  • Page 181 CODE IDENTIFIER TABLE UPC A with 5 ADD ON ÌGHÎ UPC E with 2 ADD ON ÌHIÎ UPC E with 5 ADD ON ÌIJÎ Code 39 ÌVWÎ Code 39 Full ASCII ÌWXÎ CODABAR ÌRSÎ ABC CODABAR ÌSTÎ Code 128 ÌTUÎ EAN 128 ÌklÎ...
  • Page 182 GRYPHON™ ÌZ[Î Plessey Anker ÌopÎ Plessey Standard ÌabÎ Delta IBM ÌcdÎ Telepen ÌdeÎ Code 16K ÌpqÎ Code 11 ÌbcÎ Code 49 ÌqrÎ RSS Expanded Linear and Stacked ÌtuÎ RSS Limited ÌvwÎ RSS 14 Linear and Stacked ÌuvÎ PDF417 ÌrsÎ...

  • Page 183: Chex And Numeric Table

    HEX AND NUMERIC TABLE C HEX AND NUMERIC TABLE OPEN THIS PAGE TO READ THE DESIRED HEX AND NUMERIC SELECTIONS...
  • Page 184 HEX AND NUMERIC TABLE HEX / NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE Ì01Î char char char Ì12Î Ì23Î Ì34Î Ì45Î Ì56Î Ì67Î Ì78Î < Ì89Î > Ì9:Î ÌABÎ ÌBCÎ ÌCDÎ SPACE ÌDEÎ " ÌEFÎ & ÌFGÎ Backspace Ì$%/Î Cancels an incomplete configuration sequence...
  • Page 185 90ACC1780...

This manual is also suitable for:

Gryphon d100Gryphon d200Gryphon m100Gryphon m200

Table of Contents
