Summary of Contents for Erbauer ERI068TOR
- Page 1 WARRANTY YEARS ERI068TOR 18V LI-ION TORCH...
- Page 3 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carries a 24-month guarantee, the terms of which are detailed below.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 6: Additional Safety Instructions
may cause irritation or burns. Service a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. ADDITIONAL SAFETY INSTRUCTIONS Note: This product is supplied without batteries or a charger . The charger and battery information is supplied for reference purposes. - Page 7 15. If you intend to store a battery for a period without use then store battery at room temperature (19°C to 25°C), charged to about 30 – 50% of capacity. When storing for very long periods boost-charge the battery once per year to prevent over discharge. 16.
- Page 8 ON/OFF SWITCH LIGHT HEAD COVER LIGHT BODY PART BATTERY PACK BATTERY PACK RELEASE LATCH CHARGER (SEE FIG 1-1) CHARGED INDICATOR LIGHT (GREEN) (SEE FIG 2) CHARGING INDICATOR LIGHT (RED) (SEE FIG 2) SPRING (SEE FIG 4) 10. RESERVE SLOT (SEE FIG 4) Note: This product is supplied without batteries or a charger .
-
Page 9: Technical Data
TECHNICAL DATA Power: Charger volts: 230V~50Hz Working time: 180min Battery capacity: 2.6Ah Lithium-Ion Charging time: 1 hour Machine weight: 0.3kg ACCESSORIES Extra bulb 18V LI-ION TORCH... -
Page 10: Operation Instructions
OPERATION INSTRUCTIONS Note: Before using the tool, read the instruction book carefully. 1. Before using your cordless lamp Your battery pack is UNCHARGED and you must charge once before use. Warning: The charger and battery pack are specifically designed to work together so do not attempt to use any other devices. - Page 11 Defective battery, after pre-charge 30 minutes with Red Flashing trickle current, the total Green Off battery voltage is still less than 15.0v. Red ON Charging Green Off Green ON Power On and Fully Red Off Charged Fig 3-1 The temperature of battery Green Flashing pack is less than 0 Red Off...
- Page 12 8. Disposal of an exhausted battery pack To preserve natural resources, please recycle or dispose of the battery pack properly. This battery pack contains Lithium batteries. Consult your local waste authority for information regarding available recycling and/or disposal options. Discharge your battery pack by operating your lamp, then remove the battery pack from the lamp housing and cover the battery pack connections with heavy duty adhesive tape to prevent short...
-
Page 13: Maintain Tools With Care
3. Reasons for different battery pack working times. Charging time problems, as above, and having not used a battery pack for a prolonged storage will reduce the battery pack working time.This can be corrected after several charge and discharge operations by charging & working with your lamp. Do not re-charge your battery pack below 0 C and above 40... -
Page 14: Plug Replacement
PLUG REPLACEMENT If you need to replace the fitted plug then follow the instructions below. IMPORTANT The wires in the mains lead are coloured in accordance with the following code: Blue – Neutral Brown – Live As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows. -
Page 15: Declaration Of Conformity
Declaration of Conformity We, Importer Erbauer (UK) LTD BA22 8RT Declare that the product 18V LI-ION TORCH ERI068TOR Complies with the essential health and safety requirements of the following directive: 98/37/EC EC Machinery Directive 2006/95/EC EC Low Voltage Directive 2004/108/EC EC Electromagnetic Compatibility Directive 2002/95/EC Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Standards and technical specifications referred to:...
