HOW TO USE WITH A CHILD HARNESS

USING THE BOOSTER SEAT WITH A CHILD HARNESS
A child harness MUST be used with this Booster seat if the seating position chosen
has a Lap only seat belt. A child harness can also be used in a position with a
lap-sash seatbelt and is useful if the occupant does not always wear the seat belt
correctly.
When using this Booster Seat with a child harness the Sash guide is not needed
and can be left in the slot in the cover or hanging at the back of the seat.
Before using the Child Harness with a Lap-Sash Seat Belt, you need to convert
the seat belt to a Lap Seat Belt by using a Gated Slide.
The Booster Seat can be used with a child harness in a seating position where a
upper anchorage fitting is fitted in the vehicle. Refer to the car owners manual for
the location of the child restraint upper anchorage fitting and for any precaution
related to airbags in selected seating position. If there is no anchor fitting you
will need to refer to the instruction book for the child harness which will provide
information about fitting an anchor fitting into the car.
This booster seat is suitable for use with either of the following child harnesses:
Safe-n-Sound Protecta PLUS™ harness Series 220/2010 and 220/2013 or
Babylove EzyGo Harness™ Series BL220/2010 and BL220/2013.
CAUTION:
ALWAYS FOLLOW THE CHILD HARNESS INSTRUCTIONS.
Curved
If the seating position has a lap only seat belt then no other
Gated 3-bar Slide
preparation is required.
If the seating position has a lap-sash seatbelt then it MUST be
converted into a lap belt by fitting a Gated 3 bar slide.
Only use Gated Slides recommended for this Harness.
When using a curved Gated Slide, the belt route through this
can only go one way as shown.
24
Instructions for Installation & Use - Series No. 4000/A/2013
