5. Installing your child seat (forward facing) with harness

9-18kgs Group 1 (approximate age 9 months - 4 years)
5a
5b
5c
2d
5d
3
1
IMPORTANT
seat belt (approved to UN/ECE regulation no. 16 or equivalent standards).
IMPORTANT
described in the instructions and marked in the child restraint.
70-80cm
Stow the footprop in the footprop storage area.
Place the child seat forward facing in your car. For ease of access, turn the
front of the child seat towards you. Pull out the seat belt as shown, holding the
lap and diagonal sections together
IMPORTANT
Feed the seat belt around the front of the child seat, through the first routing
slot, directly in to the back of the seat at the point shown
IMPORTANT
Take the seat belt and pass it through the second routing slot
Handy hint -
section behind the headrest before starting the installation.
Pull all the slack from the seat belt to the front of the child seat and fasten the
seat belt in the buckle
Make sure the seat belt is not twisted and the lap section passes across both
red lap belt guides. Ensure the diagonal belt is positioned in the back corner of
the child seat shell behind the headrest.
Push the child seat in to your vehicle seat using your full body weight and
tighten using the following sequence.
2
Pull and hold the diagonal belt
and pull to tighten
Check the seat by pulling firmly on the harness. There should be little or no
movement. If the child seat is still loose, carefully repeat the above tightening
sequence.
- The child seat MUST only be used with a lap and diagonal
- Do not use any load bearing contact points other than those
(dia 5a inset).
- Do not allow the belt to twist at any time.
- Do not use the red diagonal guide on the headrest.
If your seat belt is too short you may need to direct the diagonal
(dia 5c).
, pull at position
3 (dia 5d).
(dia 5a).
(dia 5b).
2 to remove all the slack
