Clearances - J. A. Roby MYSTERE Owner's Manual

Due to its reduced clearances, this appliance occupies a minimum of space in the room
where it is installed. No matter where you install it, this appliance will perfectly complete
your decoration by its originality and its heat. This appliance only needs 8 inches
clearance at its back and 12 inches from the lateral walls when installed with a single wall
pipe and a certified CAN/ULC S641 heat shield.
A
B
D
E

CLEARANCES

C
LEARANCES FROM COMBUSTIBLE MATERIALS
(Measured from the top of the appliance)
Single wall pipe
Inches Centimeters
18
12
20.5
22
Single wall pipe with certified
Can/ULC S 641 heat shield at the
Inches
45.7 8
30.5 12
52.0 10.5
55.9 22
A D
E
B
back
Centimeters
20.3
30.5
26.7
55.9
12
