Town & Country Fireplaces TC36.NGST04C Instructions Manual

Tc36 see-thru series c
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
101812-16
PART#
FOR TC36 SEE-THRU
SERIES C
TC36.NGST04C
TC36 See-Thru
TRANQUILITY
BURNER KIT
INSTRUCTIONS
TC36.NGST04C
5056.42801C4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36.NGST04C and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC36.NGST04C

Summary of Contents for Town & Country Fireplaces TC36.NGST04C

  • Page 1 Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC36 See-Thru TRANQUILITY BURNER KIT INSTRUCTIONS TC36.NGST04C PART# FOR TC36 SEE-THRU SERIES C 101812-16 TC36.NGST04C 5056.42801C4...

  • Page 2: Package Contents

    2) Attach a line cover to the left side of firebox using screw from top center of air channel. (Fig #1) 3) Remove panel retainer clips from the top heat shield. Install left porcelain panel. (Fig #2) Fig #2 TC36.NGST04C 101812-16...
  • Page 3 4) Place burner assembly into center of porcelain base panels. (Fig #3) 5) Attach fuel flex lines to bulkhead fittings. (Fig #4) CAUTION: Ensure that all connections are gas tight. Fig #4 TC36.NGST04C 101812-16...
  • Page 4 Red end to the connector marked by the red dot, white end to the connector marked by the white dot(Fig. #5 & 6) BULKHEAD PLATE Fig #6 MODULE WHITE END TO RED END TO WHITE DOT RED DOT TC36.NGST04C 101812-16...
  • Page 5 7) Place second line cover over lines and Fig #7 attach to right side of firebox using top bulkhead screw. (Fig #7) 8) Install right porcelain panel and re-install panel retainer clips. (Fig #8) Fig #8 TC36.NGST04C 101812-16...
  • Page 6 (Fig #9) Fig #10 10) Place sand in tray. Brush sand smooth and level to just below top of raised burner ports. Gently remove excess sand from around ports. (Fig #10 & 11) Fig #11 TC36.NGST04C 101812-16...
  • Page 7 11) Remove tapered plugs from ports. (Fig #12) Fig #12 Fig #13 12) Gently place pebble assembly onto sand base using pins to locate position. (Fig #13) NOTE: Do not lift pebble assembly by the top rocks. TC36.NGST04C 101812-16...
  • Page 8 13) The three loose rocks may be placed anywhere in the sand around the pebble assembly (Fig #14) NOTE: Do not place on top of the main pebble assembly as sooting and poor performance could occur. 14) Install the door. Unit is ready for lighting. TC36.NGST04C 101812-16...

  • Page 9: Propane Conversion

    Loosen the primary air shutter screw, Fig #18 open shutter fully and re-tighten. (Fig. #17) 4. Remove the 2 screws holding the pilot assembly in place with a stubby screwdriver. (Fig #18) TC36.NGST04C 101812-16...
  • Page 10 Fig #22 Replace the minimum rate screw with the one provided in the propane con- version kit supplied with this fireplace. Ensure that the screw is fully seated. (Fig. #22) TC36.NGST04C 101812-16...
  • Page 11 3/32” (2.38 mm) lation en bon état. Fig #25 Max.: 61,000 (17.9) 13. Re-attach the access panel to the side Min.: 46,200 (13.5) of the firebox with the screws previously 260911 6-TC42C 5052.5206C removed. (Fig. #25) TC36.NGST04C 101812-16...

  • Page 12: Gas Pressure Check

    (Fig. #27) 3) Attach a pressure gauge onto the fitting. 4) When testing is complete shut off the gas, remove the fit- ting and replace the plug. Thread sealant will be required to ensure a gas tight connection. TC36.NGST04C 101812-16...

  • Page 13: Burner Flame Adjustment

    The shutter should be set to fully closed for natural gas or fully open for propane. The flame should be just orange and “lazy” . It should NEVER be set to create sooting on internal parts and window glass. Fig #28 TC36.NGST04C 101812-16...

  • Page 14: Replacement Parts

    11 ..1/2” FLEX FLARE CONNECTION ..5019.223 6..PILOT ASSEMBLY ......... 5005.025 12 ..19 PORT CAST BURNER......5011.8399 7..BURNER INLET TUBE ........5011 13 ..TAPERED PLUGS ......TC36.503152 ..PEBBLE ASSEMBLY (not shown) ..TC42.9499 NOT SOLD SEPARATELY TC36.NGST04C 101812-16...
  • Page 15 TC36.NGST04C 101812-16...
  • Page 16 TECHNICAL SUPPORT: 1-250-748-1184 www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada TC36.NGST04C 101812-16...
