- Page 1 Auto Volume Stabilizer w/Digital Audio Decoder GTV-VOLCONT-D User Manual...
- Page 2 Gefen LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. GefenTV Auto Volume Stabilizer w/Digital Audio Decoder is a trademark of Gefen LLC Manufactured under license from Dolby Laboratories.
-
Page 3: Table Of Contents
CONTENTS Introduction ............................... 1 Operation Notes ............................2 Features..............................3 Panel Layout ............................. 4 Panel Descriptions ........................... 5 Connecting And Operating The Auto Volume Stabilizer ............... 6 Bypass And Standby Modes ........................7 Auto Volume Stabilizer Remote Description ..................8 Specifi... -
Page 4: Introduction
GefenTV GefenTV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to ensure you get the most from your hardware. We invite you to explore our distinct product line and hope you fi nd your solutions. -
Page 5: Operation Notes
The device can be bypassed in situations where a wide dynamic range is appropriate (such as movies and classical symphony concerts). • The remote can be used to control the GefenTV Auto Volume Stabilizer from a comfortable distance. • This unit supports the following conversions: Analog to Analog (two-channel stereo to two-channel stereo). -
Page 6: Features
FEATURES Features • Prevent fl uctuations in audio volume using Dolby Volume™ processing technology. • Automatic down-mixing from Dolby Digital 5.1 (AC-3) to two-channel L/R on all outputs ensures compatibility with broadcast formats. • Boosts low and high-frequency content dynamically (20 bands / channel) using an advanced psycho-acoustic modeling engine. -
Page 7: Panel Layout
PANEL LAYOUT Back Panel Front Panel *LED Mode Table Mode LED Color Standby Dolby Digital + Dolby Volume On Blue Dolby Digital + Dolby Volume Off Purple LPCM + Dolby Volume On Blank LPCM + Dolby Volume Off... -
Page 8: Panel Descriptions
PANEL DESCRIPTIONS Bypass Button Input Select Button Used to place the unit in Bypass Mode, Used to select between L/R audio, Coax, and allowing the signal to pass through Optical inputs unmodifi ed. Optical (TOSLINK) Input Connect an Optical cable from this port to the Bypass LED Indicated the current state of the unit. -
Page 9: Connecting And Operating The Auto Volume Stabilizer
GefenTV Auto Volume Stabilizer to the input(s) of the A/V equipment. Connect the included 5 V DC power adapter to the power receptacle on the rear of GefenTV Auto Volume Stabilizer. The LED next to the BYPASS button will turn red, indicating that the unit is powered and in Standby Mode. -
Page 10: Bypass And Standby Modes
Placing the GefenTV Audio Volume Stabilizer in Standby Mode allows the to minimize power (less than 1 W) when not in use. To place the GefenTV Auto Volume Stabilizer in Standby Mode, press and hold the BYPASS button on the front panel. After a few seconds, the Bypass LED will turn red indicating that the unit is in Standby Mode. -
Page 11: Auto Volume Stabilizer Remote Description
AUTO VOLUME STABILIZER REMOTE DESCRIPTION Power On/Off Bypass Select Input NOTE: A battery tab inserted to protect the battery during shipping will need to be Insert Battery (included) underneath removed to allow the unit to work. -
Page 12: Specifi Cations
SPECIFICATIONS Input (analog) ......................1x RCA-type connector Input (digital) ....................1x SPDIF RCA-type connector Input (digital) ....................1x TOSLINK optical connector Output ........................1x RCA-type connector Output ..........................1x S/PDIF connector Output ......................1x TOSLINK optical connector Power supply .............................5 V DC Power Consumption (max) ........................5 W Audio Formats ......
