- Page 1 HDMI to HDMI Plus Audio Converter GTV-HDMI-2-HDMIAUD User Manual www.gefentv.com...
- Page 2 ASKING FOR ASSISTANCE Technical Support: Telephone (818) 772-9100 (800) 545-6900 (818) 772-9120 Technical Support Hours: 8:00 AM to 5:00 PM Monday thru Friday PST. Write To: Gefen LLC c/o Customer Service 20600 Nordhoff St Chatsworth, CA 91311 www.gefentv.com support@gefentv.com Notice Gefen LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice.
-
Page 3: Table Of Contents
CONTENTS Introduction Features Connecting The HDMI To HDMI Plus Audio Converter Supported Audio Formats Audio Processing Panel Layout Panel Descriptions Specifi cations Warranty... -
Page 4: Introduction
INTRODUCTION Congratulations on your purchase of the GefenTV HDMI to HDMI Plus Audio Converter. Your complete satisfaction is very important to us. GefenTV GefenTV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to ensure you get the most from your hardware. -
Page 5: Features
Bitstream Audio via Optical Toslink and LPCM 7.1 via 8 RCA connectors • Locking power supply • CEC pass-through Package Includes (1) HDMI to HDMI Audio (GTV-HDMI-2-HDMIAUD) (1) 6 ft HDMI cable (M-M) (1) 5V DC Power Supply (1) User Manual... -
Page 6: Connecting The Hdmi To Hdmi Plus Audio Converter
Wiring Diagram for the GefenTV HDMI to HDMI Plus Audio Converter DIGITAL AUDIO (TOSLINK) CABLE ® MULTI-CHANNEL RCA CABLE HDMI CABLE Hi Def Source HDMI to HDMI Plus Audio Converter Audio Receiver HDTV Display GTV-HDMI-2-HDMIAUD... -
Page 7: Supported Audio Formats
SUPPORTED AUDIO FORMATS The Audio Selector Switches The audio output supports uncompressed LPCM 7.1 and lossless compressed digital Bitstream (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio). There are two switches on the front of the unit to the right of the power LED. (See Panel Layout and Description on pages 6 and 7.) The switch at the left makes changes to the input audio and the right switch changes from “Auto”... -
Page 8: Audio Processing
AUDIO PROCESSING Mode Selection: AUTO MODE: To use this mode, set the EDID Mode Switch on the front panel to the AUTO position. In Auto mode, the Converter directly retrieves EDID data from each connected A/V display device and builds a new EDID created from the highest common video resolution that all display devices can use together and the highest audio capability. -
Page 9: Panel Layout
PANEL LAYOUT Front Panel Back Panel... -
Page 10: Panel Descriptions
PANEL DESCRIPTIONS Power LED When the LED is lit it shows that the unit is powered. 2.1 / 5.1 -7.1 / Bit Stream Switch This enables the 3-way choice between 2.1, 5.1 and 7.1, and bit stream audio (when in manual mode only) . Mode Switch This switch will toggle between MANUAL and AUTO modes. -
Page 11: Specifi Cations
SPECIFICATIONS Digital Video Amplifi er Bandwidth..............225 MHz Maximum Resolutions..............1080p, 1920 x 1200 HDMI Input..................1 x HDMI 19-pin HDMI Output..................1 x HDMI 19-pin Digital Audio output................1 x TOSLINK Analog Audio Outputs.................8 x RCA Power Supply..................5V I 2.6A DC Power Consumption.................13 Watts (max) Operating Temperature................0 - 40 °C Dimensions................10.25”W x1”H x 4.25”D Shipping Weight....................4 lbs... -
Page 12: Warranty
WARRANTY Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi... - Page 13 Rev A1 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentv.com support@gefentv.com...
