Summary of Contents for GefenTV HDMI-2-COMPSVIDS
- Page 1 HDMI To Composite/S-Video Scaler GTV-HDMI-2-COMPSVIDS User Manual www.gefentv.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. HDMI To Composite/S-Video Scaler is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
Introduction Operation Notes Features Panel Layout Panel Descriptions Connecting And Operating The Hdmi To Composite/S-Video Scaler Specifi cations Warranty CONTENTS... -
Page 4: Introduction
Your complete satisfaction is very important to us. Gefen TV Gefen TV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to ensure you get the most from your hardware. -
Page 5: Operation Notes
READ THESE NOTES BEFORE INSTALLING OR OPERATING THE HDMI TO COMPOSITE/S-VIDEO SCALER • HDMI To Composite/S-Video Scaler converts 480i/p, 576i/p, 720p, 1080i/p to either NTSC 480i or PAL 576i. • The HDMI To Composite/S-Video Scaler will cross convert between some digital audio formats. -
Page 6: Features
Features • HDMI to Composite / S-Video conversion plus scaling • HDMI pass-through • Supports 480i to 1080p HDMI input resolutions • Outputs 480i / 576i signal for Composite/S-Video • Supports both NTSC and PAL formats Package Includes (1) HDMI To Composite/S-Video Scaler (1) 6 Foot HDMI Cable (M-M) (1) 5V DC Power Supply (1) User’s Manual... -
Page 7: Panel Layout
PANEL LAYOUT Front Panel Back Panel... -
Page 8: Panel Descriptions
Stereo Analog Audio Output 2 RCA stereo analog audio outputs. Connects to the display or a audio receiver. Only 2 channel LPCM from the HDMI input can be passed to these outputs. Multi-channel bit-stream such as Dolby Digital will not be passed to this output. Composite Analog Video Output RCA composite video output. -
Page 9: Connecting And Operating The
CONNECTING AND OPERATING THE HDMI TO COMPOSITE/S-VIDEO SCALER How to Connect the HDMI To Composite/S-Video Scaler Connect the HDMI source to the HDMI To Composite/S-Video Scaler’s HDMI input using the supplied HDMI cable. Connect the display to the HDMI To Composite/S-Video Scaler’s composite or s-video outputs using user supplied cables. -
Page 10: Specifi Cations
SPECIFICATIONS Input Video Signal ... 1.2V p-p Input Sync Signal ... 5V p-p (TTL) Horizontal Frequency Range ... 15-70 KHz Vertical Frequency Range ... 30-170 KHz Video In/Out ... 1 L/R Composite RCA / 1 S-Video Audio In/Out ... 2 L/R RCA audio, 2 S/PDIF digital audio Power Consumption ...
