- Page 1 Composite to HDMI Scaler GTV-COMPSVID-2-HDMIS User Manual Version A2 gefen.com...
- Page 2 ASKING FOR ASSISTANCE Technical Support: 1-707-283-5900 Telephone 1-800-472-5555 Email support@gefen.com Technical Support Hours: 8:00 AM to 5:00 PM Monday thru Friday PST. Write To: Gefen Nortek Security & Control, LLC c/o Customer Service 1800 S McDowell Blvd Petaluma, CA 94954 USA ©...
-
Page 3: Table Of Contents
CONTENTS Introduction Operation Notes Features Panel Layout Panel Description Connecting And Operating The Composite to HDMI Scaler Confi guring The Composite to HDMI Scaler 12 Specifi cations 13 Warranty... -
Page 4: Introduction
Please call us so we can better assist you with your particular needs. The Gefen TV Composite to HDMI Scaler The new GefenTV Composite to HDMI Scaler takes either Composite Video or S-Video as input and converts it to digital HDMI video, then scales it up to a maximum output of 1080p resolution (or 1920x1200 when used with a computer monitor). -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE COMPOSITE TO HDMI SCALER • The Composite to HDMI Scaler will cross convert between some digital and audio formats. All audio outputs (HDMI, digital TOSLINK®, and analog stereo mini-jack) will be active. The Composite & S-video to HDMI Scaler will not, however, down-mix multi-channel audio formats to 2 channel analog stereo. -
Page 6: Features
FEATURES Features • Inputs S-Video or Composite Video at 480i or 576i resolutions • Outputs HDMI video at resolutions of up to 1080p • Input resolution is automatically detected while the output resolution and refresh rate can be selected via the on-screen display (OSD) menu system and front panel push-buttons •... -
Page 7: Panel Layout
PANEL LAYOUT Front Panel Back Panel... -
Page 8: Panel Description
This LED indicator will become active once the power supply is properly connected. If the light is not active, the power supply may not be the correct one, or the unit may have a fault. Please contact GefenTV technical support. -
Page 9: Connecting And Operating The Composite To Hdmi Scaler
CONNECTING AND OPERATING THE COMPOSITE TO HDMI SCALER How to Connect the Composite to HDMI Scaler Connect the composite or s-video source to the scaler using user supplied cables. Connect the audio source (digital or analog) to the scaler using user supplied cables. -
Page 10: Configuring The Composite To Hdmi Scaler
CONFIGURING THE COMPOSITE TO HDMI SCALER Entering the Menu System Pressing the Menu button on the front panel will display the GUI (graphical user interface) for adjustment options. The GUI is overlaid onto the outgoing video to the display. Therefore, the source must be outputting a compatible resolution for viewing on the display. - Page 11 CONFIGURING THE COMPOSITE TO HDMI SCALER MAIN MENU The following are the main menu options. Use the - and + buttons to choose your desired subcategory and press Menu to enter it. CONTRAST BRIGHTNESS FINE TUNE COLOR OUTPUT AUDIO INFORMATION CONTRAST Press the - and + buttons to select the CONTRAST option and press the MENU button to select it.
- Page 12 CONFIGURING THE COMPOSITE TO HDMI SCALER COLOR Press the MENU button to select the COLOR option. There are several sub- categories that are available for adjustment. Select the desired option using the - and + buttons and press the MENU button to begin adjustment. Use the - and + buttons to adjust the selected option and press the MENU button when you are fi...
- Page 13 CONFIGURING THE COMPOSITE TO HDMI SCALER OUTPUT Press the - and + buttons to select the OUTPUT option and press the MENU button to select it.. There are several sub-options that are available for selection. Select the desired option using the - and + buttons and press the MENU button to select it and exit.
- Page 14 CONFIGURING THE COMPOSITE TO HDMI SCALER FACTORY RESET This option will reset the entire unit to factory settings. Press the MENU button to select the FACTORY RESET option. Press the MENU button once and a confi rmation will appear with the word YES. Press the MENU button once more to confi...
-
Page 15: Specifications
SPECIFICATIONS* Digital Video Amplifi er Bandwidth ............165 MHz VGA Amplifi er Bandwidth ................10 MHz Input DDC Signal ................. 5 Volts p-p (TTL) S-Video Connector ................... Mini-DIN Composite Connector ................RCA Jack Power Consumption ............... 10 Watts (max) Power Supply ....5V 2.6A DC, non-locking plug (2.1mm pin, 5.5mm barrel) Dimensions (W X H X D) ....4.1"... -
Page 16: Warranty
WARRANTY For the latest warranty coverage information, refer to the Warranty and Return Policy under the Connect section of the Gefen website at http://www.gefen.com/connect/warranty-and-return-policy... - Page 17 Rev A2 Gefen • Nortek Security & Control, LLC 1950 Camino Vida Roble, Suite 150 • Carlsbad, CA 92008, USA 1-800-472-5555 1-707-283-5900 www.gefen.com support@gefen.com © 2018 Nortek Security & Control, LLC. All Rights Reserved. All trademarks are the property of their respective owners. Gefen and Nortek Security &...
