- Page 1 1080p Scaler GTV-HDMI-1080PS User Manual www.gefentv.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Gefen TV 1080p HDMI Scaler is a trademark of Gefen Inc. © 2008 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
CONTENTS Introduction Operation Notes Panel Descriptions Features Connecting And Operating The 1080p HDMI Scaler / Operating The 1080p HDMI Scaler 1080p HDMI Scaler Confi guration Specifi cations Warranty... -
Page 4: Introduction
HDMI output. Conversely, you can use an HDMI source with a DVI display and the Gefen TV 1080p HDMI Scaler will extract the audio for the digital audio out to be used on an external sound system and/or amplifi er... -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE 1080P HDMI SCALER • The 1080p HDMI Scaler will cross convert between digital and analog audio formats (please see note 1 on page 5 for additional information). • Compatible with all HDMI and DVI* displays. •... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS Front Panel 5V DC Power HDMI Mono-Lok Analog Stereo Input Input Audio Input Power Status IR Sensor S/PDIF (Optical) Audio Input Back Panel S/PDIF (Optical) OSD Menu Menu UP Audio Output Button Button Analog Stereo HDMI Mono-Lok Menu DOWN Audio Output Output Button... -
Page 7: Features
FEATURES Features • Digital Input is format-converted and pixel re-scaled on the outputs • Dual high-quality scaling engines • Dual 3D motion video adaptive deinterlacers • DVI/HDMI/HDCP compliant input; Operates up to 165 MHz (UXGA @ 60Hz) • Automatic 3:2 pull-down & 2:2 pull-down detection and recovery •... -
Page 8: Connecting And Operating The 1080P Hdmi Scaler / Operating The 1080P Hdmi Scaler
CONNECTING AND OPERATING THE 1080P HDMI SCALER How to Connect the 1080p HDMI Scaler Connect the HDMI source to the 1080p HDMI Scaler using the supplied HDMI cable. Connect an optional external audio source to either the TOSLINK digital audio input or the stereo mini-jack input using user supplied cables. -
Page 9: 1080P Hdmi Scaler Confi Guration
EDID. If an image is still not being displayed, it is possible that either the display’s EDID is corrupt or the 1080p HDMI Scaler cannot output the display’s native resolution. Please call Gefen’s technical support line. Navigation Navigation of the GUI is accomplished using the front panel buttons. Please see the chart below for the functions of each panel button. - Page 10 1080P HDMI SCALER CONFIGURATION VIDEO Picture Mode Preset and user confi gurable settings for different viewing scenarios. Preset settings will not allow user adjustment. Only the USER option will allow customized video settings. The USER settings are saved. Options: • Standard - useful for general content •...
- Page 11 1080P HDMI SCALER CONFIGURATION NR (Noise Reduction) NR is not used for digital HDMI video. COLOR Color Tone Sets the color for the appearance of white. Only the USER option will allow customized settings. The USER settings are saved. Options: •...
- Page 12 1080P HDMI SCALER CONFIGURATION OSD (ON SCREEN DISPLAY) H-Pos (Horizontal Position) Adjusts the OSD’s horizontal position on the screen. Options: • Adjusts in increments of 1 on a scale of 1 to 100 (default is 50) V-Pos (Vertical Position) Adjusts the OSD’s vertical position on the screen. Options: •...
- Page 13 1080P HDMI SCALER CONFIGURATION Sound Select general audio output function Options: • On - Use selected audio source (default) • Mute - No sound output INFORMATION This menu will allow the user to view general information. There are no confi gurable options in this menu.
-
Page 14: Specifi Cations
SPECIFICATIONS Digital Video Amplifi er Bandwidth ............165 MHz Input DDC Signal ................. 5 Volts p-p (TTL) Input Video Signal ................1.2 Volts p-p Single Link Range ..............1080p/1920x1200 Input/Output HDMI Connectors .......... Type A, 19-pin Female Digital Audio Connector ........Optical TOSLink + Coaxial S/PDIF Power Supply ....................
