2.10 GV-I/O Box (8 Ports)

The GV-I/O Box 8 provides 8 inputs and 8 relay outputs, and supports both DC and AC
output voltages.
Key Features
•
8 inputs and 8 outputs are provided.
•
Up to 9 pieces of GV-I/O Box 8 can be chained together.
•
A USB port is provided for PC connection, and it is only used for 30 DC output voltage.
•
Ethernet module is optional.
System Requirements
•
GV-System version 8.2 or above
Packing List
1. GV-I/O Box 8 x 1
2. USB Cable (Type A to B) x 1
Note: The GV-I/O box (8 Ports) comes with the option of an Ethernet module. See
2.12 Accessing GV-I/O Box over Networks.
Hardware Accessories
2
3. Power Adapter DC 12V x 1
4. Installation Guide x 1
