ProForm Performance 1450 User Manual

Proform performance 1450 (petl12714.0) treadmill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. PETL12714.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
CASTLEFORD
WF10 5QJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for ProForm Performance 1450

Summary of Contents for ProForm Performance 1450

  • Page 1 Model No. PETL12714.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. c/o HI Group PLC Express Way CASTLEFORD...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 DANGER: 21. Do not attempt to move the treadmill until it Always unplug the power is properly assembled. (See ASSEMBLY on cord immediately after use, before clean- page 7, and HOW TO FOLD AND MOVE THE ing the treadmill, and before performing the TREADMILL on page 26.) You must be able maintenance and adjustment procedures to safely lift 45 lbs.

  • Page 5: Before You Begin

    PERFORMANCE 1450 treadmill. The manual. To help us assist you, please note the product ® PERFORMANCE 1450 treadmill offers an impres- model number and serial number before contacting us. sive selection of features designed to make your The model number and the location of the serial num- workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex key materials until you finish all assembly steps.
  • Page 8 2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (94). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94). See the inset drawing. Tie the wire tie in the Right Upright (90) securely around the end of the Upright Wire (81).
  • Page 9 4. Insert a Wheel Spacer (63) into a Front Wheel (62). Hold the Front Wheel inside the bottom of the Right Upright (90), and insert a 3/8" x 4" Screw (7) with a 3/8" Star Washer (13) into the Right Upright and the Front Wheel. Repeat this step with the Left Upright (not shown).

  • Page 10: Slide The Left Base Cover Onto The Left Upright

    6. Identify the Left and Right Base Covers (82, 83). Slide the Left Base Cover onto the Left Upright (89), and slide the Right Base Cover onto the Right Upright (90). Do not press the Base Covers into place yet. Identify the Right and Left Bottom Handrail Covers (84, 85).
  • Page 11 8. If there are four screws (B) in the locations shown, remove and discard them. 9. Note: If assembled on a smooth surface, the treadmill may roll forward during this step. Raise the Frame (56) to the upright position. IMPORTANT: Do not raise the Frame past the Brackets vertical position.
  • Page 12 10. Orient the Storage Latch (53) so that the decals are facing away from the treadmill as shown. Attach the lower end of the Storage Latch (53) to the bracket on the Base (94) with a 5/16" x 1 3/4" Bolt (6) and a 5/16"...
  • Page 13 12. Set the console assembly on the Left Handrail Console (86) and the Right Handrail (87). Make sure not Assembly to pinch any wires (D, 81). Attach the console assembly with four 5/16" x 1/2" Screws (4) and four 5/16" Star Washers (11).
  • Page 14 14. See the inset drawing. Connect the Upright Wire (81) to the console wire (D). The connec- tors should slide together easily and snap into place. If they do not, turn one connector and try again. IF YOU DO NOT CONNECT THE CONNECTORS PROPERLY, THE CONSOLE MAY BECOME DAMAGED WHEN YOU TURN ON THE POWER.
  • Page 15 16. Slide the Left Bottom Handrail Cover (85) up against the Left Handrail Cover (79), and attach the Left Bottom Handrail Cover with two #8 x 1/2" Screws (1). Do not overtighten the Screws. Attach the Right Bottom Handrail Cover (84) as described above.

  • Page 16: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...

  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you The treadmill console offers an impressive array of exercise. features designed to make your workouts more effec- To turn on the power, see page 19.
  • Page 19 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 20 4. Change the incline of the treadmill as desired. The My Trail tab will show a track that represents 400 m (1/4 mile). As you exercise, the flashing To change the incline of the treadmill, press the rectangle will show your progress. The My Trail tab Incline increase or decrease button or one of the will also show the number of laps you complete.
  • Page 21 6. Measure your heart rate if desired. 7. Turn on the fan if desired. Note: If you use the handgrip heart rate moni- The fan features multiple tor and the chest heart rate monitor at the same speed settings. Press time, the console will not display your heart the fan increase or de- rate accurately.
  • Page 22 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 23 HOW TO USE A SET-A-GOAL WORKOUT 7. When you are finished exercising, remove the key from the console. 1. Insert the key into the console. See step 8 on page 21. See HOW TO TURN ON THE POWER on page 19. 2.
  • Page 24 To re-run a recent iFit workout from your schedule, your top four competitors. The end of the matrix first press the Track button. Next, press the in- represents the end of the race. crease and decrease buttons to select the desired 7.
  • Page 25 THE INFORMATION MODE into the reset position, and insert the key into the console. However, when you remove the key, the The console features an information mode that keeps displays will remain lit, although the buttons will not track of treadmill information and allows you to person- function.

  • Page 26: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regularly clean the treadmill and keep the walking a. Check the power switch (see drawing c at the left). belt clean and dry. First, press the power switch into If the switch has tripped, wait for five minutes and the off position and unplug the power cord.
  • Page 28 Locate the Reed Switch (52) and the Magnet (50) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (49). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
  • Page 29 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails a. First, remove the key and UNPLUG THE POWER IMPORTANT: If the walking belt rubs against the CORD. Using the hex key, turn both idler roller foot rails, the walking belt may become damaged.

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 31 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 32 NOTES...
  • Page 33 NOTES...

  • Page 34: Part List

    PART LIST Model No. PETL12714.0 R0114A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Drive Roller/Pulley #8 x 3/4" Screw Magnet 5/16" x 2" Bolt Reed Switch Clip 5/16" x 1/2" Screw Reed Switch #10 Star Washer Storage Latch 5/16"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Wheel Filter Key/Clip Motor Isolator Cable Tie Receptacle 1/4" x 1 1/2" Screw Strap Pulse Sensor Motor Bushing – User’s Manual Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL12714.0 R0114A...
  • Page 37 EXPLODED DRAWING B Model No. PETL12714.0 R0114A...
  • Page 38 EXPLODED DRAWING C Model No. PETL12714.0 R0114A...
  • Page 39 EXPLODED DRAWING D Model No. PETL12714.0 R0114A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
