Auto Setup

Auto Setup
Before carrying out this
section, it is very
important that The Setup
Diskette for Windows 95 or
Windows 98/Windows 2000/
Windows NT has been run.
(see page 6)
The Setup Utility
included on the setup
diskette is for displaying do
patterns. They do not replace
or modify the display dirver.
The Auto Setup instructions
require the monitor to be
warmed up for 15 minutes.
This is not required for normal
operation.
Å Æ
By pressing the
and keys
simultaneously allows direct
access to the auto set-up
controls.
If your PC does not run
with the setup diskettes
shipped with the monitor, refer
to Manual Setup on page 12
A
The process
UTO SETUP
only applies to the current
screen mode. When a new
mode is selected, repeat this
section to reset the monitor
When you first use your monitor you must perform Auto Setup. This
procedure sets up your monitor to process the video signals from your
computer without image discoloration or smearing. After you perform Auto
Setup, the settings are stored and used each time you turn on the monitor.
In order to optimise the displayed image a set-up utility is provided on the IBM
Monitor Installation Diskette. Operation of the utility is dependent on the
operating system on your PC. For correct operation locate the operating
system on your PC from the table below and follow the appropriate
instructions. You may choose to run
that you use. This means that if you sometimes use your monitor while
running any version of Windows and sometimes also use it from within DOS
(not a DOS window), you must run
You may run versions of
Operating System
DOS
Windows 3.1
Windows 95
Windows 98
Window 2000
Window NT
Before you begin
A S
UTO
1. Make a backup copy of the setup diskettes supplied with the monitor.
2. Make sure the PC's video mode is set in the range of the supported
screen resolution shown in the table on page 18.
You should perform
A
UTO
for each operating system
A S
UTO ETUP
for both Windows and DOS.
A S
UTO ETUP
in any order.
A S
UTO ETUP
Corresponding Auto Setup procedure
Auto Setup for DOS
Auto Setup for Windows 3.1, Windows 95,
Windows 98, Windows 2000 or Windows
NT
for your PC:
ETUP
for each screen mode you use.
S
ETUP
on page 9
on page 11
