  • Page 1 ATTACHMENT K – USERS MANUAL © 2001 PCTEST Lab...
  • Page 3 • To isolate the monitor from the electrical supply, you must remove the plug from the power outlet. The power outlet should be easily accessible. Handling: • Your color monitor is heavy, so handle it with care. IBM recommends that this monitor is moved or lifted by two people. DANGER Pour éviter les risques d’électrocution :...
  • Page 4 3These user’s setup instructions cover typical user environments. The on-screen messages may differ depending on the level of your hardware and software. In some cases you may need to vary the setup procedures. For more information, refer to your computer or operating system manuals or consult your system administrator or dealer.
  • Page 5 References in this publication to IBM products, programs, or services do not imply that IBM intends to make these available in all countries in which IBM operates. Any reference to an IBM product, program or service is not intended to state or imply that only IBM’s product, program, or service may be used.

  • Page 6: Table Of Contents

    Contents Setup..........................2 Hardware Requirements ..................2 Handling Instructions ...................2 Workplace preparation ..................2 Working Practices ....................3 Connecting your Monitor..................4 Switching on your Monitor..................4 Adjusting the Monitor Position ................5 Caring for your Monitor ..................5 Configuring your Monitor ..................6 Setup Diskette for Microsoft Windows95 or Microsoft Windows98......6 Setup Diskette for Microsoft Windows 2000 ............7 Auto Setup ........................8 Auto Setup ......................8...

  • Page 7: Setup

    Setup Hardware Requirements This monitor requires a computer with a suitable on-board sub-system or Video Adapter card that can support XGA 1024 x 768, SVGA 800 x 600, or VGA 640 x 480 at 60Hz. Handling Instructions Handling Instructions Do not support the monitor 1.

  • Page 8: Workplace Preparation

    Workplace Preparation Height This section gives advice on what you should The monitor should be positioned so that the top of the screen is slightly consider before you set up below your eye level when you sit at your workstation. your monitor.

  • Page 9: Connecting Your Monitor

    Connecting your Monitor 1. Turn off your computer and all attached devices. Connect the monitor signal cable to the Video output of your computer Be sure to read the ‘Safety Information’ at the front of this and tighten the thumscrews. Ensure that the connectors align. Do not User Guide before carrying out force the connectors as this may bend the pins.

  • Page 10: Adjusting The Monitor Position

    • Gently wipe the covers and the screen with a soft cloth. • Remove finger marks and grease with a damp cloth and mild detergent. • Never use flammable cleaning materials to clean your IBM monitor or any other electrical apparatus.

  • Page 11: Configuring Your Monitor

    7. Insert the Setup diskette into drive A: and select the H button. 8. Select OK. 9. Choose IBM T545H monitor and select OK. The files will be copied from the diskette to your hard drive. 10.Close all open windows and remove the diskette.

  • Page 12: Setup Diskette For Microsoft Windows 2000

    12.Insert the Setup diskette into drive A: and select the H button. 13.Select OK. 14.Choose IBM T545H monitor and select OK. The files will be copied from the diskette to your hard drive. 15.Close all open windows and remove the diskette.

  • Page 13: Auto Setup

    In order to optimise the displayed image a set-up utility is provided on the The Setup Utility included IBM Monitor Installation Diskette. Operation of this utility is dependent on the on the setup diskette is for operating system on your computer. For correct operation locate the operating displaying dot patterns.

  • Page 14: Auto Setup For Dos

    2. Wait approximately 15 minutes, until the monitor warms up. If you are using PC-DOS/V, change to U.S. mode by 3. Insert the diskette labelled ‘IBM Monitor Installation Disk’ into the typing ‘CHEV US’ and pressing diskette drive. ENTER at the command prompt.

  • Page 15: Auto Setup For Microsoft Windows3.1, Microsoft Windows95, Microsoft Windows98, Microsoft Windows Nt Or Microsoft Windows2000

    2. Wait approximately 15 minutes, until the monitor warms up. 3. Drag the icon bar and tool bar, if they are displayed, to the bottom of the screen. 4. Insert the diskette labelled ‘IBM Monitor Installation Disk’ into the diskette drive. The size and diversity of the 5.
  • Page 16 10. Press the ESC key to return to Windows. You have completed the monitor setup for Windows. If you use other operat- ing systems, perform the appropriate AUTO SETUP for those systems, also: see Auto Setup for DOS on page 9.

  • Page 17: Manual Setup

    Manual Setup Normally, you can complete the setup procedure using A , however, ETUP if your screen image is still distorted after you perform A or the ETUP setup diskette does not run on your system, perform M ANUAL ETUP If the monitor is in standby 1.

  • Page 18: Adjusting Your Lcd Monitor

    Adjusting Your LCD Monitor User controls User control features Icon Direct Access Function Function Using Menu Controls 1.None 1. Exits from menus, sub menus 2.DPM : Convertible Digital 2. Exits from OSD or Analog 1. Brings up Brightness control Moves the cursor to highlight icons or make adjustments.
  • Page 19 CONTROLS LOCK / UNLOCK This feature allows you to secure the current control settings, while allowing the user to adjust Brightness, Contrast and initiate Auto Setup, so that they cannot be inadvertently changed. Push and hold the enter button[ ] for 10 seconds;...

  • Page 20: On-Screen Display (Osd) Controls

    On-screen display (OSD) controls The settings adjustable with the user controls are viewed through the On - The LCD monitor needs Screen Display (OSD). Press the enter button [ ] to display the main OSD time to become thermally menu. stable the first time you turn it on each day.
  • Page 21 Controls and OSD Icon Description Sub-menu(s) Adjustments If manual is selected, the user will go To adjust the focus of the Manual SET- to the manual adjustment screen. display. This item allows you to remove any • Fine horizontal noise and clear •...
  • Page 22 Controls and Description Sub-menu(S) OSD Icon Adjustments Reset should return all available functions • YES (apart from language which should not change unless adjusted via the • NO LANGUAGE menu) fo their factory RESET presets. Moves the screen left and right . It is not availible when the digital input H-POSITION Moves the screen up and down.

  • Page 23: Further Information

    Further Information Display modes The display mode the monitor uses is controlled by the computer. Therefore, you should refer to your computer documentation for details on how to change display modes. The image size, position and shape may change when the display mode changes.

  • Page 24: Power Management

    768 at 60Hz. NERGY STAR 2000 guidelines for energy efficiency. ® IBM recommends that you switch off your monitor at the end of each working day, or whenever you expect to leave it unused for long periods during the day.

  • Page 25: Troubleshooting

    Troubleshooting If you have a problem setting up or using your monitor, you may be able to solve it yourself. Before calling your retailer or IBM, try the suggested actions that are appropriate to your problem. Possible Problem Suggested Action...
  • Page 26 Possible Suggested Action Reference Problem Cause • • Check that the signal cabel Sreen is blank The monitor is Connecting not receving a and power your monitor is firmly connected to the video signal indicator is computer. section on • • Check that no pins are bent flashing green page 4 every 0.5...

  • Page 27: Further Help

    With the original purchase of an IBM machine, you have access to extensive support coverage. During the IBM machine warranty period, you may call IBM or your reseller for problem determination assistance under the terms of the IBM Statement of Limited Warranty.
  • Page 28 10. Slide the cable cover on the base assembly(B). To obtain the correct cables and/or to get further instructions on installing them, call the IBM HELPCENTER at the above numbers or contact your dealer, retailer, or other IBM authorized Servicer.

  • Page 29: Specifications

    Specifications DVI-I Connector (Digital/Analog) Signal(DVI-I) Signal(DVI-I) T. M. D. S. Data2- Hot Plug Detect T. M. D. S. Data2+ T. M. D. S. Data0- T. M. D. S. Data2/4 Shield T. M. D. S. Data0+ T. M. D. S. Data4- T.
  • Page 30 Separate (TTL) Sync Input Type Composite (TTL) Communications VESA DDC: Supported Display Standard modes : IBM, VESA, MAC Modes Horiz / Vert Freq: See Factory Set Display Modes on page 18. See Display Mode Ranges on page 25. Temperature: Environment 10 to 35°...
  • Page 31 Display Mode Ranges Horizontal Frequency / Refresh Rate / Addressabillty Range ( + / - 3%) Range ( + / - 3%) 640 x 350 67.9 ~ 72.1 Hz 30.56 ~ 31.45 kHz 720 x 400 67.9 ~ 72.1 Hz 30.56 ~ 31.45 kHz 640 x 480 58.2 ~ 61.8 Hz...

  • Page 32: Warranty

    Date of Installation unless IBM or your reseller informs you otherwise. If a Machine does not function as warranted during the warranty period, and IBM or your reseller are unable to either 1) make it do so or 2) replace it with one that is at least functionally equivalent, you may return it to your place of purchase and your money will be refunded.
  • Page 33 IBM or your reseller of changes in a Machine’s location. IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM’s possession or 2) in transit in those cases where IBM is responsible for the transportation charges.
  • Page 34 2. as to any other actual damage arising in any situation involving nonperformance by IBM pursuant to, or in any way related to the subject of this Statement of Limited Warranty, IBM’s liability will be limited to the charge paid by you for the individual Machine that is the subject of the claim.
  • Page 35 Limitation of Liability: The following replaces item 2 in this Section: as to any other actual direct damages, IBM’s liability will be limited to the total amount you paid for the Machine that is the subject of the claim. For purposes of this item, the term “Machine”...
  • Page 36 1. (unchanged) 2. as to any other actual damage arising in all situations involving non-performance by IBM pursuant to, or in any way related to the subject matter of this Statement of Warranty, IBM’s liability, will be limited to the total amount you paid for the Machine that is the subject of the claim.
  • Page 37 Environmental Labelling of Personal Computers Congratulations! You have just purchased a TCO’95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and to the further development of environmentally-adapted electronic products.
  • Page 38 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level, in one or more stages. The length of time to reactivate the computer shall be reasonable for the user. Labelled products must meet strict environmental demands, for example, in respect of the reduction of electric and magnetic fields, along with physical and visual ergonomics and good usability.
  • Page 39 Cadmium is present in rechargeable batteries and in the color-generating layers of certain computer displays. Cadmium damages the nervous system and is toxic in high doses. The relevant bio-accumulative TCO’95 requirement states that batteries may not contain more than 25 ppm (parts per million) of cadmium. The color-generating layers of display screens must not contain any cadmium.
  • Page 40 Environmental Labelling of Personal Computers Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 41 Approval requirements cover a wide range of issues: environment, ergonomics, usability, emission of electric and magnetic fields, energy consumption and electrical and fire safety. The environmental demands impose restrictions on the presence and use of heavy metals, brominated and chlorinated flame retardants, CFCs (freons) and chlorinated solvents, among other things.
  • Page 42 Environmental Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and requirements housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.

  • Page 43: Service Information

    Service Information The following parts are for use by IBM service, or IBM authorised dealers, to support the customer warranty. Parts are for service use only. P/NO Description Video Color 22P7473 FRU Monitor Hybrid Stealth Black 6653-HG2 22P7474 FRU Monitor...
  • Page 44 Power Cords For your safety, IBM provides a power cord with a grounded attachment plug to use with this IBM product. To avoid electrical shock, always use the power cord and plug with a properly grounded power outlet.
  • Page 45 The cord set should have the appropriate safety approvals for the country in which the equipment will be installed. IBM power cords for a specific country or region are usually available only in that country or region. IBM Fig. #...
  • Page 46 Avis de conformité à la réglementation d'Industrie Canada Cet appareil numérique de classe B est conforme à la norme NMB-003 du Canada. As an ENERGY STAR Partner, IBM Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency.
  • Page 47 Congratulations! You have just purchased a TCO99 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labeled computers? In many countries, environmental labeling has become an established method for encouraging the adaptation of goods and services to the environment.
  • Page 48 products with regards to their eventual recycling and disposal. By proper selection of these materials and substances, the impact on the environment can be minimized. There are also other characteristics of a computer, such as energy consumption levels, that are important from the viewpoints of both the work (internal) and natural (external) environments.
  • Page 49 Member States relating to electromagnetic compatibility. IBM can not accept responsibility for any failure to satisfy the protection requirements resulting from a non- recommended modification of the product, including the fitting of non-IBM option cards.
  • Page 50 In solch einem FAll ist der Abstand bzw. die Abschirmungzu der industriellen Storquelle zu vergroern. Anmerkung: Um die Einhaltung des EMVG sicherzustellen sind die Gerate, wie in den IBM Handbuchern angegeben, zu installieren und zubetreiben. Declaración de la Unión Europea (UE) Este producto satisface los requisitos de protección del Consejo de la UE, Directiva 89/ 336/ CEE en lo que a...
  • Page 51 IBM non accetta responsabilità alcuna per la mancata conformità alle normative di protezione dovuta a modifiche non consi gliate al prodotto, compresa l’installazione di schede e componenti di marca diversa da IBM. Le prove effettuate sul presente prodotto hanno accertato che esso rientra nei limiti stabiliti per le le apparecchiature di informatica Classe B ai sensi del CISPR 22 / Norma Europea EN 55022.
  • Page 52 VCCI Class B Notice (Japan Only) This equipment complies with the limits for a Class B digital device (devices used in or adjacent to a residential environment) and conforms to the standards for information technology equipment that are set by the Voluntary Control Council for Interference for preventing radio frequency interference in residential areas.
