- Page 1 SBS63XE SBS63XED SBS63NED SBS63XEDH Instruction Manual Manuale di istruzioni Notice d'Utilisation Bruksanvisning Manual de instrucciones Bedienungsanleitung Brugsvejledning fin Käyttöohje Bruksanvisning...
- Page 2 Dear Customer, We'd like you to achieve the optimal efficiency from our product, which has been manufactured in modern facilities with meticulous quality controls. For this purpose, please fully read the user guide before using the product and keep the guide as a reference source.
-
Page 3: Table Of Contents
Table of Contents 1 Safety and environment instructions 3 5 Using the product 1.1. General safety..... . . 3 5.1. Indicator panel ..... 14 1.1.1 HC warning . -
Page 4: Safety And Environment Instructions
Safety and environment instructions • Do not place liquids in bottles and cans into the This section provides the safety instructions freezer compartment. They may burst out! necessary to prevent the risk of injury and material • Place liquids in upright position after tightly damage. -
Page 5: Hc Warning
Safety and environment instructions 1.1.1 HC warning • The product’s bench life is 10 years. The spare If the product comprises a cooling system using parts necessary for the product to function will R600a gas, take care to avoid damaging the be available for this period. -
Page 6: Refrigerator
Refrigerator 1- Freezer compartment 10- Zero degree compartment 2- Cooler compartment 11- Vegetable bins 3- Fan 12- Adjustable stands 4- Butter-cheese compartment 13- Frozen food storing compartments 5- Glass shelves 14- Freezer compartment door shelves 6- Cooler compartment door shelves 15- Icematics 7- Minibar accessory 16- Ice storage box... -
Page 7: Installation
Installation 3.1. Right place for installation 3.2. Attaching the plastic wedges Use the plastic wedges in the provided with Contact the Authorized Service for the product's the product to provide sufficient space for air installation. To ready the product for installation, circulation between the product and the wall. -
Page 8: Adjusting The Stands
Installation 3.3. Adjusting the stands 3.5. Water connection If the product is not in balanced position, adjust the (Optional) front adjustable stands by rotating right or left. WARNING: Unplug the product and the water pump (if available) during connection. The product’s water mains, filter and carboy connections must be rendered by authorizer service. -
Page 9: Connecting Water Hose To The Product
Installation 3.6. Connecting water 3.7. Connecting to water mains hose to the product (Optional) To connect the water hose to the product, To use the product by connecting to the cold water follow the instructions below. mains, a standard 1/2” valve connector must be 1. -
Page 10: For Products Using Water Carboy
Installation 4. Attach the connector into the faucet adaptor 2. Connect the other end of the water hose to and tighten by hand / tool. the water pump by pushing the hose into the pump’s hose inlet. 5. To avoid damaging, shifting or accidentally 3. -
Page 11: Fixing External Filter On The Wall (Optional)
Installation 3.9.1.Fixing external filter on the wall (Optional) WARNING: Do not fix the filter on the product. Check to see the following parts are supplied with your product’s model: 4. Attach the water hose extending from the top of the filter to the product’s water connection adaptor, (see 3.6.) 1. -
Page 12: Internal Filter
Installation 3.9.2.Internal filter 1. “Ice Off” indicator must be active while installing the filter. Switch the ON-OFF The internal filter provided with the product is not indicator using the “Ice” button on the screen. installed upon delivery; please follow the instructions below to install the filter. - Page 13 Installation 3. Remove the water filter by-pass cover by pulling. A few drops of water may flow out after removing the cover; this is normal. 4. Place the water filter cover into the mechanism and push to lock in place. 5.
-
Page 14: Preparation
Preparation 4.1. What to do for energy saving 4.2. First Use mehmet Before using your refrigerator, make sure the Connecting the product to electronic necessary preparations are made in line with energy-saving systems is harmful, as it the instructions in “Safety and environment may damage the product. -
Page 15: Using The Product
Using the product 5.1. Indicator panel Indicator panels may vary depending on the model of your product. Audial and visual functions of the indicator panel will assist in using the refrigerator. 1. Cooler compartment indicator 2. Error status indicator 3. Temperature indicator 4. - Page 16 Using the product 1. Cooler compartment indicator Push the Vacation button ( ) again to cancel The cooler compartment light will turn on when this function. adjusting the cooler compartment temperature. 5. Temperature adjustment button 2. Error status indicator Respective compartment's temperature varies in This sensor will activate if the refrigerator is not -24°C..
- Page 17 Using the product 1- Economic use 2- High temperature / fault alert 3- Rapid cooling 4- Vacation function 5- Cooler compartment temperature setting 6- Energy saving (display off) 7- Keypad lock 8- Eco-fuzzy 9- Cooler compartment temperature setting 10- Rapid freezing *Optional: The figures in this user guide are intended as drafts and may not perfectly match your product.
- Page 18 Using the product 1. Economic use 6. Energy saving (display off) This sign will light up when the freezer Pressing this button ( ) will light up the energy- compartment is set to -18°C', the most saving sign ( ) and the Energy-saving function economical setting.
- Page 19 Using the product 10. Rapid freezing For rapid freezing, press the button number (10); this will activate the rapid freezing indicator ( When the rapid freezing function is turned on, the rapid freeze indicator will light up and the freezer compartment temperature indicator will display the value -27.
- Page 20 Using the product 1. Freezer compartment temperature setting 2. Economy mode 3. Error status 4. Cooler compartment temperature setting 5. Rapid cooling 6. Vacation function 7. Keypad lock / filter replacing alert cancellation 8. Water, fragmented ice, ice cubes selection 9.
- Page 21 Using the product 6. Vacation function 1. Freezer compartment temperature setting Pressing the button ( ) number (1) will enable When the Vacation function ( ) is active, the cooler compartment temperature indicator displays the freezer compartment temperature to be set at -18,-19,-20,-21 ,-22,-23,-24,-18...
-
Page 22: Activating The Water Filter Replacing Alert
Using the product 5.2. Activating the water 11. Autoeco filter replacing alert Press the auto eco button ( ), number (11), for 3 seconds to activate this function. If the (For products connected to water mains and door remains closed for a long time when this comprising filter) function is activated, the cooler section will switch The water filter replacing alert is adjusted as... -
Page 23: Using The Water Fountain
Using the product 5.4. Filling the fountain water tank 5.3. Using the water fountain Open the water tank’s lid, as shown in the figure. (for certain models) Fill in pure and clean drinking water. Close the lid. The first few glasses of water taken from the fountain will normally be warm. -
Page 24: Cleaning The Water Tank
Using the product 5.5. Cleaning the water tank Remove the water filling reservoir inside the door shelf. Detach by holding both sides of the door shelf. Hold both sides of the water tank and remove at 45° angle. Remove and clean the water tank lid. Do not fill the water tank with fruit juice, fizzy beverages, alcoholic beverages or any other liquids incompatible for use in... -
Page 25: Taking Ice / Water
Using the product 5.6. Taking ice / water • The water may be cloudy during first use of the filter; do not consume the first 10 glasses (Optional) of water. To take water ( ) / ice cube ( ) / fragmented • You must wait approximately 12 hours to get ice ( ), use the display to select the respective... -
Page 26: Zero Degree Compartment
Using the product 5.8. Zero degree compartment 5.11. Ionizer (Optional) (Optional) Use this compartment to keep delicatessen The ionizer system in the cooler compartment's at lower temperatures or meat products for air duct serves to ionize the air. The negative immediate consumption. -
Page 27: Icematic And Ice Storage Box
Using the product 5.15. Ice-maker 5.14. Icematic and ice storage box (Optional) (Optional) Ice maker is located on the upper section of the Fill the icematic with water and put in place. freezer cover. The ice will be ready after approximately two hours. -
Page 28: Freezing Fresh Food
Using the product 5.16. Freezing fresh food 5.17. Recommendations for storing frozen foods • To preserve food quality, the food items placed in the freezer compartment must be frozen as The compartment must be set to at least -18°C. quickly as possible, use the rapid freezing for 1. -
Page 29: Placing The Food
Using the product 5.19. Placing the food Freezer Various frozen goods including compartment meat, fish, ice cream, shelves vegetables etc. Cooler Food items inside pots, capped compartment plate and capped cases, eggs shelves (in capped case) Cooler Small and packed food or compartment beverages door shelves... -
Page 30: Maintenance And Cleaning
Maintenance and cleaning 6.2. Protecting plastic surfaces Cleaning the product regularly will prolong its service life. Oil spilled on plastic surfaces may damage the surface and must be cleaned immediately with WARNING: Disconnect the power before warm water. cleaning the refrigerator. • Do not use sharp and abrasive tools, soap, house cleaning materials, detergents, gas, gasoline, varnish and similar substances for... -
Page 31: Troubleshooting
Troubleshooting Check this list before contacting the service. Doing so will save you time and money. This list includes frequent complaints that are not related to faulty workmanship or materials. Certain features mentioned herein may not apply to your product. The refrigerator is not working. - Page 32 Troubleshooting The freezer temperature is very low, but the cooler temperature is adequate. • The freezer compartment temperature is set to a very low degree. >>> Set the freezer compartment temperature to a higher degree and check again. The cooler temperature is very low, but the freezer temperature is adequate. • The cooler compartment temperature is set to a very low degree.
- Page 33 Troubleshooting The interior smells bad. • The product is not cleaned regularly. >>> Clean the interior regularly using sponge, warm water and carbonated water. • Certain holders and packaging materials may cause odour. >>> Use holders and packaging materials without free of odour. • The foods were placed in unsealed holders.
