AR-150P
DEFINITION
The definition of each Rank is as follows and also noted in the list
A : Parts necessary to be stocked as High usage parts.
B : Parts necessary to be stocked as Standard usage parts.
C : Low usage parts.
D : Parts necessary for refurbish.
E : Unit parts recommended to be stocked for efficient after sales service.
Please note that the lead time for the said parts may be longer than normal parts.
S : Consumable parts.
Please note that the following parts used in Copier under the same description are classified into A or B Rank depending
upon the place used.
Example : Gear made of Metal, Sprocket, Bearing, Belt made of Rubber, Spring clutch mechanism.
A Rank : The parts which may be with the revolution or loading.
B Rank : Parts similar to A Rank parts, but are not included in Rank A.
Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with
the parts specific to the product specification.
F
Other than this Parts Guide, please refer to documents Service Manual (including Circuit Diagram) of this model.
F
Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature.
Do not order from parts department.

1 AR-SP3-1(Exterors)

NO. PARTS CODE
1 L S O U - 0 0 0 4 Q S Z Z
2 L P L T P 0 0 1 1 Q S Z Z
3 L P L T P 0 0 1 2 Q S Z Z
4 N G E R R 0 3 7 7 F C Z Z
5 X E P S D 3 0 P 0 8 X 0 0
6 N G E R H 0 1 9 3 F C Z Z
7 M S P R P 0 0 5 9 Q S Z Z
8 P C O V P 0 0 3 6 Q S Z Z
11 C F R M - 0 0 1 1 Q S 5 1
13 X E B S D 4 0 P 1 0 0 0 0
14 C F R M - 0 0 1 3 Q S 5 1
15 L B N D J 0 0 1 3 F C Z 1
16 P S H E P 0 0 3 8 Q S Z Z
17 P S H E P 0 0 6 3 Q S Z Z
18 M S P R P 0 1 1 3 Q S Z 1
19 P S H E P 0 0 3 7 Q S Z 1
20 X E B S D 3 0 P 0 8 0 0 0
21 M H N G - 0 0 0 3 Q S Z Z
22 X E B S E 4 0 P 1 4 0 0 0
23 N R O L P 0 0 1 1 Q S Z Z
24 P S P O - 0 0 0 1 Q S Z Z
25 N S F T Z 0 0 1 0 Q S Z Z
26 M S P R T 0 0 6 1 Q S Z Z
27 M S P R P 0 0 6 0 Q S Z Z
28 N R O L P 0 0 1 0 Q S Z Z
29 N S F T Z 0 0 0 9 Q S Z Z
30 L P L T M 0 0 9 6 Q S Z Z
31 L X - B Z 0 0 1 6 Q S Z Z
32 M H N G - 0 0 0 4 Q S Z Z
33 L S O U - 0 0 0 5 Q S Z 3
34 P C U S S 0 0 1 0 Q S Z 1
35 P S H E Z 0 1 0 2 Q S Z Z
36 P S H E Z 0 1 1 2 Q S Z Z
37 M S P R C 0 1 4 9 Q S Z Z
501 C S O U - 0 0 0 4 Q S 5 1
PRICE NEW PART
RANK MARK RANK
AX D Original tray
AH
C Control plate F
AH
C Control plate R
AD C Manual feeding rack gear
AA
C Screw (3 8X)
AB
C Manual feeding gear
AD C Control plate spring
AK
D Rack cover
BE
E SPF pick up unit
AA C Screw (4 10)
BS
E SPF transport unit
AA
C Wire band
AE C Base tray sheet
AC
C Transport sheet
AD
C Earth spring
AE C OC mat sheet
AA
C Screw (3 8)
AX
C SPF hinge L
AA C Screw (4 14)
AD
C Delivery roller
AB
C Sponge
AE C Delivery shaft
AC
C Delivery spring
AD
C Transport spring
AD C Transport roller
AE
C Transport shaft
AF
C Base tray reinforce plate
AC C Screw (3 8)
AX
C SPF hinge R
BB
D Base tray
AV
C OC sheet
AD
C Motor pressure sheet
AE
C Delivery earth sheet SPF
AC C PS earth spring SPF
BC
E SPF original tray unit
