C. Paper feed solenoid
1) Remove the screw.
2) Remove the connector.
3) Remove the paper feed solenoid.
3
D. Transport roller
1) Remove two E-rings.
2) Remove the transport roller.
1
A
B
*
Install so that the earth spring A is brought into contact over bearing
B.
2
1
4
3
2
E. Paper feed clutch
1) Remove the E-ring.
2) Remove the paper feed clutch.
3) Remove the parts.
3
*
When installing, fit the cut surface A.
F. 2nd paper feed roller
1) Remove the E-ring and the parts.
2) Remove the 2nd paper feed roller.
1
2
C
D
*
When installing, hang the 2nd connection arm on the 2nd connection
arm SP B. Be sure to install so that the earth spring C is in contact
under the bearing D.
4 – 2
AR-SP3
A
2
A
B
1
1
