Digital copier

Advertisement

Quick Links

AR-SP3
AR-FX3
AR-DE9
AR-PG1
[ 1 ] GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
[ 2 ] UNPACKING AND INSTALLATION . . . . . . . . . . . . . 2 - 1
[ 3 ] AR-SP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
[ 4 ] AR-DE9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
[ 5 ] AR-PG1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
G PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
DIGITAL COPIER OPTIONS
AR-SP3
AR-FX3
AR-DE9
AR-PG1
MODEL
CONTENTS
SHARP CORPORATION
CODE: 00ZAR15OPTA1E
(SPF)
(FAX)
(1 TRAY UNIT)
(GDI + USB Kit)
∗ For
the
specifications,
operational
diagrams, and Parts Guide of the AR-FX3, refer to the AR-F151
Service Manual and Parts Guide.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
AR-SP3
descriptions,
circuit

Advertisement

Table of Contents
loading
