B. USB INTERFACE
Connector
4-pin DDK DUSB-BRA42-T11
Type-B connector
Cable
Shielded twisted pair cable
(2 m (6 feet) Max.: high-speed transmission equivalent)
Pin configuration
The pin numbers and signal names are listed in the following table.
Pin No. Signal name
1 +5V
2 – DATA
3 +DATA
4 GND

3. Print Area

The print area of this printer is shown below.
A. 600 dpi
Paper
size
A B C
Letter 5100 4900 6600
Legal 5100 4900 8400
Invoice 3300 3100 5100
A4 4960 4760 7014
A5 3508 3308 4960
B5 4298 4098 6070
Folio 5100 4900 7800
Foolscap 5100 4900 7440
E
Dots
D E F G
6400 100 100 100
8200 100 100 100
4900 100 100 100
6814 100 100 100
4760 100 100 100
5870 100 100 100
7600 100 100 100
7240 100 100 100
Portrait
E
D C
F
G
B
A
1
2
3 4
B. 300 dpi
Paper
size
A B
Letter 2550 2450
Legal 2550 2450
Invoice 1650 1550
A4 2480 2380
A5 1754 1654
B5 2149 2049
Folio 2550 2450
Foolscap 2550 2450
Landscape
E
E
F
D
C
Paper size
Print area
5 – 2
AR-SP3
Dots
C D E F
3300 3200 50 50
4200 4100 50 50
2550 2450 50 50
3507 3407 50 50
2480 2380 50 50
3035 2935 50 50
3900 3800 50 50
3720 3620 50 50
B A
G
G
50
50
50
50
50
50
50
50
