Hi Sharp HS-CC756W User Manual

Thank you for purchasing our product.
Please read this User's Manual before
using the product. Change without Notice
1/3" Wide Dynamic Range Color

CCD Camera

FCC STATEMENT

WARNING
This device complies with Part 15 FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including
interference that may cause undesired operation."
* Federal Communications Commission (FCC) Statement
WARNING
This Equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the ser is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
* You are cautioned that changes or modifications not expressly approved
by the party responsible for compliance could void your authority to operate
the equipment.
3

Table of Content

FCC Statement............................................................................3

Safety Precautions....................................................................... 4

Features.................................................................................... 5
Parts & Functions........................................................................ 6
IRDA Remote Controller................................................................7
Connection Interface.................................................................... 8
Operations................................................................................. 9
Main menu............................................................................... 10
General menu......................................................................... 10
Ae menu................................................................................ 11
Wdr menu.............................................................................. 12
Day / Night menu.................................................................... 13
Awb menu..............................................................................14
Privacy menu......................................................................... 15
Special menu......................................................................... 16
Message menu....................................................................... 17
Initial.................................................................................... 17
Exit.......................................................................................17
Specification............................................................................... 18
Dimension................................................................................. 19
Safety Precautions
Please read before using
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of insulated dangerous Voltage within the
product's enclosure that may be sufficient magnitude to
constitute risk of electrical shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operation and maintenance (servicing) instructions in the
literature accompanying the appliance.
1. Don't try to disassemble the chassis or the part easily, in case
that touch the power by mistake, is shocked by electricity the
danger or caused inside parts to be damaged.
2. Do not attempt to service this unit yourself unless you are
authorized to do so. Opening cover may exposure you to
dangerous voltage or other hazards. When the problem
cannot solve, please contact the professional. Refer all
servicing to qualified personnel only.
When being regular, please lock the parts firmly first to prevent
3.
the machine damage.
Please connect power source correctly in accordance with
4.
the regulation, prevent the machine from using, or striking
improperly.
5. Power source of camera is AC100-240V or DC12V/AC24V.
Please don't use any organic solution or the corrosively
sanitizer to insert and wipe away the chassis outside. While
inserting and wiping away. Please turn off the power, and use
the clean cloth is stained with letting a small amount of branch
water, insert and wipe away appearance.
7. Please don't use the camera under the following abominable
environments: The humidity is higher than 90%. Temperature
is lower than- 10 degrees Centigrade, or is higher than +50
degrees Centigrade.
