Thank you for purchasing our product.
Please read this User's Manual before
using the
product.
Change without Notice
COLOR IR CCD IP CAMERA
Product Feature
■
1/3" CCD Camera
■
530 TV Lines of High Horizontal Resolution
■
Built-in Vari-Focal Lens
■
Lightness, Compact, Solid-Stage Body Design
■
Vandal Proof Design for Long Durability
■
3 – Axis design
■
Class IP65 Weatherproof
■
IR LED : 30PCS
■
IR Cutter
■
Auto IRIS
■
H.264 dual streams
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-CI532H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hi Sharp HS-CI532H

Summary of Contents for Hi Sharp HS-CI532H

  • Page 1 Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without Notice COLOR IR CCD IP CAMERA User’s Manual Product Feature ■ 1/3" CCD Camera ■ 530 TV Lines of High Horizontal Resolution ■ Built-in Vari-Focal Lens ■...
