This section explains how to set up a connection for packet communication without using "DOCOMO
Connection Manager".
The packet communication uses AT commands to carry out the settings from a personal computer. To
specify settings, communication software to enter AT command is required. "Hyper Terminal", which is
attached to Windows as the standard software, is used here for explanation.
When using DOCOMO Internet access service "mopera U" or "mopera", you do not need to set an access
point name (APN) (see page 17).
You can set "caller ID notified/not notified" (see page 20) as required. (You need to set "caller ID notified"
when using "mopera U" or "mopera".)
<Packet communication setting flow using AT commands>
Start the communication software that enables the entry of AT commands (See step 3 on page 17)
AT commands
≥The AT commands are used to control a modem. The FOMA terminal, which conforms to the AT commands, supports some extended
commands and unique AT commands.
≥By entering AT commands, you can carry out detailed setting for packet communication and FOMA terminal, and confirm (display) the
setting contents.
≥If the entered AT command is not displayed, enter "ATE1
To manually carry out the communication setting, you need to specify a COM port number, which is assigned to "FOMA
P06A" (modem) embedded after you install the "FOMA communication configuration file" (driver).
The confirmation method varies depending on the operating system of your personal computer.
≥When using DOCOMO Internet access service "mopera U" or "mopera", you do not need to set an access point name (APN);
therefore, you do not need to confirm the modem.
For Windows Vista
1
" [
2
From "
(Control panel)", open "
modem options)".
3
If the "
"

Setting Dial-up Network

Set Packet Communication
Confirm the COM port number (See page 15)
Set an access point name (APN) (See step 7 on page 19)
Set "caller ID notified/not notified"(See step 2 on page 20)
Set others (See page 33)
Exit the communication software (See step 9 on page 19)
Confirm COM Port Number
(Start)]"1Open "
(Address information)" display appears, enter
(City code/Area code)", then click "OK".
".
(Hardware and sound)" in "
15
(Control panel)".
(Phone and
