  • Page 1 ® LEGACY LR121SX OWNER’S MANUAL INDASH AM/FM MPX CAR RADIO WITH CASSETTE PLAYER...

  • Page 2: Control Operation

    CONTENTS Control Operation...2 Wire Connection ...4 Installation ...4 Specification...4 CONTROL OPERATION POWER ON/VOLUME Rotate the knob to right for turning on the unit and increasing the degree of sound. FREQUENCY DISPLAY The dial pointer indicates the frequency of current reception. RADIO INDICATOR A glow of this indicator represents good reception of broadcasting.
  • Page 3 BAND SELECTOR Push this button to select AM band. Push and release the button to UP position to select FM band. EJECT BUTTON Push down halfway to run the cassette tape fast forward and fully down to eject the cassette tape.

  • Page 4: Wire Connection

    WIRE CONNECTION ANTENNA CONNECTOR POWER ANTENNA IGNITION B(+) LEFT SPEAKER INSTALLATION FIG. 1 SPECIFICATIONS AUDIO & GENERAL Supply Voltage Frequency Response Dimensions Weight CASSETTE SECTION Tape Speed Wow and Flutter RADIO SECTION Stereo Separation Stereo Sensitivity Tuning Range Sensitivity Tuning Range Sensitivity MAIN UNIT BLUE...
