BASIC OPERATION 1. REL BUTTON Press it to detach the front panel when you want to take the unit away. 2. CLOCK ADJUSTMENT BUTTON Press it to change the display to clock display. In clock display, press CLK button for more than 2 seconds until time flashes on LCD, then press hour.
Page 3
BASIC OPERATION 7. MON/INT BUTTON MON MODE: Press it to select mono or stereo mode. INT MODE: During CD mode, press INT (intro) button to hear the first 10 seconds of each track on the disc. Press this button again to restore the player to its normal play mode.
ELECTRIC CONNECTION ANTENNA CONNECTOR IGNITION SWITCH (B+) YELLOW MEMORY (B+) BLACK GROUND (B–) BLUE AUTO ANTENNA FRONT – Lch SPK. REAR – Lch SPK. MAIN UNIT 0.5A FUSE BOX WHITE WHITE/BLACK GREEN GREEN /BLACK FRONT RCA OUTPUT CABLE (optional) Rch RED Lch WHITE GREY FRONT...
Page 6
DISC NOTICE Cleaning discs Before playing, clean the disc with a clean, lint-free. Flip the disc in the direction of the arrow. NOTE: Do not use so solvents such as benzine, thinners. Commercially available cleaners or anti static spray damage the unit. Insert a disc with the label surface down.
SPECIFICATIONS Supply voltage Current consumption Audio signal output characteristics Frequency Coverage Sensitivity(S/N=30dB) Stereo Separation Frequency Coverage Sensitivity(S/N=30dB) Frequency Coverage Sensitivity(S/N=30dB) Note: Specifications and design are subject to modification, without notice, due to improvements in technology. : 12V DC (11V-15V), test voltage 14.4V, negative ground : Less than 5A : (1) Frequency response 20 Hz-20 kHz (2) S/N Radio...
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power. The car ignition switch is not on. The fuse is blown. Disc cannot be Presence of disc inside the loaded or player...
