REMOTE CONTROL BASICS BATTERY REPLACEMENT:
1.Remove the battery holder as the direction indicated by the arrow.
2.Replace the battery Set a new battery property with (+)side up.
3.Insert the battery holder. Push in the holder to the original position.
NOTE ON BATTERIES:
Old batteries must immediately be removed and disposed.
BATTERY INFORMATION:
Designated Battery: CR 2025 3V
Battery Life: 6 months with normal use (in normal room temperatur)
CAUTION:
Improper use of batteries may cause overheating, explosion or ignition. Resulting in
jury or fire .Battery leakage may cause damage to the unit.
Do not disassemble or short the batteries. Do not throw the batteries into the fire.
To avoid the risk of accident, keep the batteries out of reach of children.
1. LOCAL/DISTANCE BUTTON
If you find the receiving signal is weak and there is the
word LOC displayed on LCD when you tune for distance
station, firstly press the button to disappear the word
LOC on LCD, then tune again for the distance station.
If you find the interference to the receiving signal is very
strong and there is not the word LOC displayed on LCD
when you tune for local station, firstly press the button to
display the word LOC on LCD, then tune again for the local
station.
2. LOUDNESS BUTTON
Press it to enhance the bass sound effect immediately
when the volume level is reduced to below half level.
LEGACY
INSTRUCTION MANUAL
AUTO-LOADING COMPACT DISC PLAYER
AND AM/FM-STEREO DIGITAL PLL TUNING RADIO
ANTI-THEFT FLIP DOWN DETACHABLE FRONT PANEL
WITH INFRA-RED REMOTE CONTROLLER
LCD89DFX
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Legacy LCD89DFX
Summary of Contents for Legacy LCD89DFX
-
Page 1: Instruction Manual
2. LOUDNESS BUTTON Press it to enhance the bass sound effect immediately when the volume level is reduced to below half level. LEGACY LCD89DFX INSTRUCTION MANUAL AUTO-LOADING COMPACT DISC PLAYER AND AM/FM-STEREO DIGITAL PLL TUNING RADIO ANTI-THEFT FLIP DOWN DETACHABLE FRONT PANEL... - Page 2 DEAR CUSTOMER Selecting fine audio equipment such as the unit you have just purchased is only the start of your musical enjoyment. Now it is time to consider how you can maximize the fun and excitement your equipment offers. We want you to get the most out of your equipment by playing it at a safe level.
-
Page 3: Disc Play
DISC PLAY: Cleaning discs Before playing, clean the disc with a clean, lint-free cloth. Wipe the disc in the direction of the arrow. NOTE: . Do not use so solvents such as benzine, thinners. Commercially available cleaners or anti static spray damage the unit. Insert a disc with the label surface down. -
Page 4: Troubleshooting
3. LCD (LIQUID CRYSTAL DISPLAY) 4. UP AND DN BUTTONS 1)In RADIO mode, press ^ or v button shortly and repeatedly to manually tune up or down for the desired radio station with step by step. Press ^ or v button hold for more than 0.5 seconds to auto-matically tune up or down for the radio station of strong signal. - Page 5 SPEAKER CONNECTION ANTENNA PLUG YELLOW MEMORY B+ FUSE BLACK(GND) 0.5 A FUSE RED (B+) BLUE AUTO ANT WHITE FRONT WHITE/BLACK LEFT GREEN REAR GREEN/BLACK NOTE: 1. In spite of having any kinds of speaker system, must use 4 ohms impedance of speaker to reduce the distortion during high volume level. 2.
-
Page 6: Installation
CAUTION: Do not install the detachable panel before connecting the wire. 1. The unit is designed for negative terminal of the battery which is connected to the vehicle metal. Please confirm it before installation. 2. If the car interior is extremely hot, as after being parked in the sun, do not use the player until the car has been driven for a while to cool off the interior.
