WIRING CONNECTION
ANTENNA JACK
RED
R
RCA LINE OUT
L
WHITE
+ +
GREEN
LEFT
SPEAKER
- -
SPECIFICATION
GENERAL
Power Supply Requirements............................DC 12 Volts. Negative Ground
Chassis Dimensions.................................................181(W)X147(D)X53(H)
FM SECTION
Frequency Range...............................................................88MHz-108MHz
AM SECTION
Frequency Range............................................................530KHz-1700KHz
FUSE 0.5A
PINK
B+ MEMORY
FUSE 3A
RED
TO +12V BATTERY
+ +
GREY
- -
BLACK
GROUND
LEGACY
INSTRUCTION MANUAL
RIGHT
SPEAKER
ANTI-THEFT FULL DETACHABLE SYSTEM
WITH AM/FM TUNING RADIO
LR-180D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Legacy LR-180D
Summary of Contents for Legacy LR-180D
-
Page 1: Instruction Manual
LEGACY WIRING CONNECTION ANTENNA JACK LR-180D FUSE 0.5A PINK B+ MEMORY RCA LINE OUT FUSE 3A TO +12V BATTERY INSTRUCTION MANUAL WHITE GREY GREEN RIGHT LEFT SPEAKER SPEAKER BLACK GROUND SPECIFICATION GENERAL Power Supply Requirements......DC 12 Volts. Negative Ground Chassis Dimensions..........181(W)X147(D)X53(H) FM SECTION Frequency Range...............88MHz-108MHz... - Page 2 9.BAND BUTTON LOCATION AND FUNCTION OF CONTROL Press it to select you desired radio band and the word which is selected will be indicated on LCD. 10.CLOCK ADJUSTMENT BUTTON When the time appeared on LCD, press the S button and the H button together at the same time to adjust hour, when adjustment is completed release both buttons.
